Compressor Assembly Parts.

Noted below and on the following page are listings of the major components used in the Compressor Assemblies.

Please pay close attention to the model numbers of the Units to ensure that you choose the correct components.

1 to 3 HP Compressor Units.

Description:

Pump Assembly

Intake Filter Assembly

Intake Filter Element

Beltguard Assembly

Motor Pulley – 1 Phase

Motor Pulley – 3 Phase

Belt

Tank

Pressure Switch

Pressure Gauge

Tank Safety Valve

Tank Drain Ball Valve

Tank Ball Valve

Check Valve

Maintenance Kits:

The appropriate Maintenance Kit for the 1 to 3 HP Units noted above having the 'DEV-20', 'DEV-30', DEV-30-1'

and 'DEV-40' Pumps is:

MK-40 Maintenance Kit

Each kit consists of:

(3)

PB-21177012

(1)

PR-31-4
