Owner's Manual & Assembly Instructions
QO01
BASE KIT
Model No. FDN477
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
717110311
NOTE: THIS KIT IS NOT SELF
SUPPORTING. SEE IMPORTANT
INSTRUCTIONS ON BACK COVER
Advertisement
Related Manuals for Arrow FDN477
Summary of Contents for Arrow FDN477
- Page 1 Owner's Manual & Assembly Instructions QO01 BASE KIT Model No. FDN477 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE NOTE: THIS KIT IS NOT SELF MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ SUPPORTING.
-
Page 2: Parts List
10. Separate contents of the carton by the part number while reviewing parts list. Check to be sure that you have all the necessary parts for your kit. If you find a part missing, include the model number of your kit and contact: Arrow Shed, LLC Customer Service Department 1101 North 4th Street Breese, Illinois 62230 1-800-851-1085 or assist@arrowsheds.com... - Page 3 How The Base Kit Works QO03 Assemble Floor Frame. Assemble Base Kit. Attach Floor Frame assembly to Base Kit. Attach decking material inside Floor Frame assembly. DECKING MATERIAL (Not Supplied) FLOOR FRAME of Storage Building BASE KIT (10x9 Illustrated)
- Page 4 4 x 7 QO04 Attach cross channels 9215. Snap side channels 9219 together as shown. Slide channels to match correct overall dimension shown. Bolt together where holes line up. Make two Carefully turn unit over and fasten opposite complete assemblies. side connection with screws.
- Page 5 6 x 5 QO05 Snap side channels 9217 together as shown. Attach cross channels 9215 following Slide channels to match correct overall dimension dimensions. shown. Bolt together where holes line up. Make two complete assemblies. Carefully turn unit over and fasten opposite side connection with screws.
- Page 6 Attach Floor Frame Assembly QO06 Do not fasten decking material at this time! NOTE: FLOOR FRAME MUST BE LEVEL AND SQUARE BEFORE PROCEEDING! If you are using decking material, complete the floor If you are using the base kit as a finished form to pour frame assembly for the storage building as shown in concrete, see next page.
-
Page 7: Finishing Materials
LAY EXTERIOR PLYWOOD OR ANY SUITABLE DECK MATERIAL (5/8" 15,5 MM MINIMUM THICK- NESS) NOTE: Pressure Treated Lumber must not be used where it will make contact with your Arrow Products. The properties of Pressure Treated Lumber will cause accelerated corrosion. If Pressure Treated Lumber comes in contact with your Arrow Models your warranty will be voided.
