Owner's Manual & Assembly Instructions
QP01
BASE KIT
Model No. FDN54
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
717100311
NOTE: THIS KIT IS NOT SELF
SUPPORTING. SEE IMPORTANT
INSTRUCTIONS ON BACK COVER
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Arrow FDN54
Summary of Contents for Arrow FDN54
- Page 1 Owner's Manual & Assembly Instructions QP01 BASE KIT Model No. FDN54 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE NOTE: THIS KIT IS NOT SELF MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ SUPPORTING.
-
Page 2: Parts List
10. Separate contents of the carton by the part number while reviewing parts list. Check to be sure that you have all the necessary parts for your kit. If you find a part missing, include the model number of your kit and contact: Arrow Shed, LLC Customer Service Department 1101 North 4th Street Breese, Illinois 62230 1-800-851-1085 or assist@arrowsheds.com... - Page 3 How The Base Kit Works QO03 Assemble Floor Frame. Assemble Base Kit. Attach Floor Frame assembly to Base Kit. Attach decking material inside Floor Frame assembly. DECKING MATERIAL (Not Supplied) FLOOR FRAME of Storage Building BASE KIT (10x9 Illustrated)
- Page 4 5 x 4 QP04 Carefully turn unit over and fasten opposite side Fasten two side channels 9784 to two side channels 9783 using screws on the top flanges to connections using screws. form a rectangle. Attach the two remaining side channels 9784 at the dimensions shown, with flanges Fasten three corner angles 0572 to corners of facing direction shown, using screws.
- Page 5 Attach Floor Frame Assembly QP05 Do not fasten decking material at this time! NOTE: FLOOR FRAME MUST BE LEVEL AND SQUARE BEFORE PROCEEDING! If you are using decking material, complete the floor If you are using the base kit as a finished form to pour frame assembly for the storage building as shown in concrete, see next page.
-
Page 6: Finishing Materials
LAY EXTERIOR PLYWOOD OR ANY SUITABLE DECK MATERIAL (5/8" 15,5 MM MINIMUM THICK- NESS) NOTE: Pressure Treated Lumber must not be used where it will make contact with your Arrow Products. The properties of Pressure Treated Lumber will cause accelerated corrosion. If Pressure Treated Lumber comes in contact with your Arrow Models your warranty will be voided.
