StarTech.com 5G4AINDRM-USB-A-HUB Quick Start Manual

4-Port Managed Industrial USB Hub - USB 3.2 Gen 1 5Gbps, ESD Protection
Product ID
5G4AINDRM-USB-A-HUB
Product Diagram
7
4
1 2 3
USB Hub Management Software
To utilize the management features of this USB Hub, it is necessary to download and
install the software. To download the USB Hub Management Software, as well as the
accompanying documentation, please visit:
www.StarTech.com/5G4AINDRM-USB-A-HUB
Requirements
Host Computer
•
USB-A Port
•
7-48V DC Power Source
•
Flat head Screwdriver
•
(Optional) Phillips head Screwdriver (for DIN Rail Mounting)
•
For the latest drivers, manuals, product information, technical specifications, and
declarations of conformance, please visit:
www.StarTech.com/5G4AINDRM-USB-A-HUB
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
5
6 6
Component
DC 2-Wire Terminal Block Power
1
7 Input
2
Power LED
3
USB-B Host Port
4
3x USB-A Data/Charge Ports
5
USB-A Data Port
6
4x USB Port Status LEDs
7
Mounting Brackets
Package Contents
USB Hub x 1
•
6 ft [1.8 m] USB-A to USB-B Cable x 1
•
Terminal Block Connector (Attached) x 1
•
DIN Rail Mounting Bracket (with Mounting Screws) x 1
•
Quick-Start Guide x 1
•
Quick-Start Guide
Function
• Connect a +7~48 V DC Power Source
• 30W or Higher Recommended for Maximum
Power Performance
• Indicates if the USB Hub is receiving power
• Solid Green - Receiving Power
• Off - Not Receiving Power
• Connect to a USB-A Port on a Host Computer
• USB 3.2 Gen 1 (5 Gbps)
• Connect USB Peripherals
• USB 3.2 Gen 1 (5 Gbps)
• Backward compatible with USB 2.0 (480Mbps)
• BC 1.2 for up to 5 V/1.5 A (7.5 W) Charging
• Connect USB Peripherals
• USB 3.2 Gen 1 (5 Gbps)
• Not Compatible with USB 2.0 (480Mbps)
• Supports up to 5 V/0.9 A (4.5 W) Charging
• Indicates if the Corresponding USB-A Data/Charge
Port is Enabled or Disabled
• Solid Green - USB-A Data/Charge Port Enabled
• Off - USB-A Data/Charge Port Disabled
• Enable/Disable USB-A Data/Charge Ports within the
USB Hub Management Software
• Mount the USB Hub to a wall or the side/underside of
a Desk
Manual Revision: June 22, 2023 2:54 PM
