Quick start proceDure

Connect a clean ±15V power supply to the turret posts at
the top of the DC752A board. Connect J1 to a DC590 USB
serial controller using the supplied 14-conductor ribbon
cable. Connect DC590 to a host PC with a standard USB
A/B cable. Run the QuikEval™ evaluation software supplied
with DC590 or download it from www.linear.com/software.
The correct control panel will be loaded automatically. The
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
software automatically sets the LTC2704 outputs according
to the entries in the control panel. A square wave option
is available to test settling time.
Additional software documentation may be available from
the Help menu item, as features may be added periodically.
Figure 2. Software Screenshot
