Using the DefiMonitor XD
7.10.3

Triggering defibrillation

Note
The DefiMonitor XD carries out automatic impedance measurement. If it doesn't de-
tect the patient, the electrodes and the adhesive contact on the skin need to be
checked. Defibrillation can only be carried out if the DefiMonitor XD detects the pa-
tient.
Note
Triggering defibrillation can temporarily disrupt the ECG and SpO2 measurement.
7.10.3.1 MAN (manual mode)
After switching the device on and successfully carrying out the self-test, all DefiMonitor XD models will
automatically go into manual mode (MAN).
"MAN" mode will be shown in information area 2 of the monitor.
Shock via paddles
•
Select energy level and charge up as described in chapter 7.10.1 and 7.10.2.
•
Press the paddles on to the patient's chest with at least 60 N (6 kg) of force.
•
Wait until the ECG is visible on the monitor.
•
Press the two paddle buttons simultaneously to trigger defibrillation, which occurs immediately af-
ter the button is pressed.
•
Hold the buttons down until the shock has been administered.
•
Avoid contact with the sockets on the device during defibrillation.
➢ The number of shocks applied is shown in information area 3 of the monitor for 8 seconds.
Shock via SavePads
•
Select energy level and charge up as described in chapter 7.10.1 and 7.10.2.
•
Press the lit-up, green shock button, Fig. 7 (17) to trigger defibrillation, which occurs immediately
after the button is pressed.
•
Hold the button down until the shock has been administered.
•
Avoid contact with the sockets on the device during defibrillation.
➢ The number of shocks applied is shown in information area 3 of the monitor for 8 seconds,
Fig. 9.
If the defibrillation energy is not delivered to the patient, the corresponding message will be
shown in display area 3. (see Fig. 9)
DefiMonitor XD | 24050 | GB | I 59 / 108
