Primedic DefiMonitor XD Operating Instructions Manual page 101

Appendix
Guidelines and manufacturer's declaration on resistance to electromagnetic interference
The DefiMonitor XD is designed for operation in an electromagnetic environment like the one de-
scribed below. The customer or user of the DefiMonitor XD should ensure that it is used in an envi-
ronment of this kind.
Test for interference
resistance
Electrostatic discharge
(ESD) as per IEC
61000-4-2
Rapid transient electri-
cal disturbance varia-
bles / bursts as per
IEC61000-4-4
Surge voltages
(surges) as per IEC
61000-4-5
Voltage dips, short
breaks and fluctua-
tions in the supply volt-
age as per IEC 61000-
4-11
DefiMonitor XD | 24050 | GB | I
IEC 60601-1-2: 2014
test level
± 8 kV contact dis-
charge
± 2 kV, ± 4 kV, ± 8 kV,
± 15 kV air discharge
± 2 kV (wire to wire) @
100 kHz refresh rate
for power cables
± 0,5 kV, ± 1 kV (wire
to wire) for power ca-
bles
0 % U (100 % dip in
T
U ) for ½ period @ 0°,
T
45°, 90°, 135°, 180°,
225°, 270° and 315°
0 % U ; (see above)
T
for 1 period and 70 %
U for (25 periods at
T
50 Hz / 30 periods at
60 Hz) @ 0°
0 % U (see above) for
T
250 periods at 50 Hz /
300 periods at 60 Hz
Compliance level
± 8 kV contact dis-
charge
± 2 kV, ± 4 kV, ± 8 kV,
± 15 kV air discharge
± 2 kV (wire to wire) @
100 kHz refresh rate
for power cables;
power supply is pro-
tection class II
The device has no sig-
nal from input and out-
put sections.
Cannot be used when
run off battery
± 0,5 kV, ± 1 kV (wire
to wire) for power ca-
bles
power supply is pro-
tection class II
The device has no sig-
nal from input and out-
put sections.
Cannot be used when
run off battery
0 % U (100 % dip in
T
U ) for ½ period @ 0°,
T
45°, 90°, 135°, 180°,
225°, 270° and 315°
0 % U ; (see above)
T
for 1 period and 70 %
U for (25 periods at
T
50 Hz / 30 periods at
60 Hz) @ 0°
0 % U (see above) for
T
250 periods at 50 Hz /
300 periods at 60 Hz
Cannot be used when
run off battery
Guidance for the elec-
tromagnetic environ-
ment
Corridor floors should
be made of wood or
concrete or be covered
with ceramic tiles. If
the floor is covered
with a synthetic mate-
rial, the relative air hu-
midity should be at
least 30%.
The quality of the volt-
age supply should cor-
respond to that of a
typical residential,
business or hospital
environment.
The quality of the volt-
age supply should cor-
respond to that of a
typical residential,
business or hospital
environment.
The quality of the volt-
age supply should cor-
respond to that of a
typical residential,
business or hospital
environment. The Defi-
Monitor XD can con-
tinue to function within
the limits of its battery
capacity without any
interruptions thanks to
its rechargeable bat-
tery. If the permissible
duration of use is ex-
ceeded, it is recom-
mended that a spare
battery or an uninter-
rupted power supply is
used.
101 / 108
