Page 1: Triple Undersink Water Filtration System
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 WARNING: For correct operation & installation, it is essential to observe these instructions TRIPLE UNDERSINK WATER FILTRATION SYSTEM Page 1 of 19... -
Page 2: Table Of Contents
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 CONTENTS Triple Undersink Water Filtration System ............................1 Installation and Operation Manual ..............................3 AquaCo Customer Service ................................3 Operation ......................................3 Installation ...................................... 4 Installation requirements ................................4 System Dimensions ..................................4 Typical Installation .................................. -
Page 3: Installation And Operation Manual
AQUACO CUSTOMER SERVICE Thank you for purchasing an AquaCo undersink water filter system. Your system is a proven performer manufactured from only quality materials and components and will give years of ‘spring fresh’ water free of impurities if maintained properly. -
Page 4: Installation
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 INSTALLATION This system comes complete with an installation kit enabling it to be connected to 15mm (½”) copper pipe (cold supply only - hot water should be filtered prior to heating). Included is a control valve incorporating backflow prevention, anti hammer, flow control and pressure limiting capabilities in full compliance with the relevant laws. -
Page 5: Typical Installation
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 TYPICAL INSTALLATION Figure 1 COMPONENTS 9. Elbow Connector 1/4" Tube to 1/4" Male Angle stop valve (Not included) 10. Straight Adaptor 1/4" Male to 1/4" Tube 1/2" Tee with 1/4" Push-in Tube Connector 11. -
Page 6: Installation Procedure
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 INSTALLATION PROCEDURE Find a convenient location: The System dimensions are 390 W x 370 H x 130 D (mm), and the tap dimensions are 80 W x 130 D x 292 H (mm). -
Page 7: Cartridge Installation/Maintenance
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 CARTRIDGE INSTALLATION/MAINTENANCE To change the filter cartridges, adhere to the following procedure. 1. CLOSE ISOLATING VALVE - Locate 6. CHECK O-RING & FILTER - Lubricate with food grade silicone your isolating valve connected to your lubricant or similar if needed. - Page 8 Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 11. RESET LED INDICATOR - Reset LED 16. FINAL CHECK - Once you have addressed any issues, turn the indicator by following instructions on water supply back on and page 12.
-
Page 9: Fluoride Filter Pre-Flush
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 FLUORIDE FILTER PRE -FLUSH To change the filter cartridges, adhere to the following procedure. 1. CLOSE ISOLATING VALVE - Locate 6. CHECK O-RING & FILTER - Lubricate with food grade silicone your isolating valve connected to your lubricant or similar if needed. - Page 10 Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 11. OPEN THE SECOND HOUSING - 17. RESET LED INDICATOR - Reset LED indicator by following Loosen the second housing, using the instructions on page 12. spanner supplied and unscrew the filter housing sump.
-
Page 11: Faucet Installation Procedure
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 FAUCET INSTALLATION PROCEDURE Figure 5 – Faucet Installation Diagram Page 11 of 19... -
Page 12: Battery Installation
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 BATTERY INSTALLATION BATTERY REPLACEMENT & RESET 1. AFTER ONE YEAR - 1. Remove the black When the light flashes battery seat from the RED indicates your faucet lever handle. cartridges are due to be... -
Page 13: Led Light Indicator
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 LED LIGHT INDICATOR After the battery is installed, the light will flash Blue during operation. The light will flash red after 1 year. When the light flashes RED indicates your cartridges are due to be changed (usage has exceeded 3,000 minutes or 12 months). -
Page 14: Use Guidelines
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 USE GUIDELINES • Minimum operating pressure 200 kPa. • Maximum operating pressure 620 kPa. • Do not allow exposure to temperatures below 2°C. • Maximum operating temperature 38°C. • Nominal flow rate 3 Lpm. -
Page 15: Cartridge Replacement Guide
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 CARTRIDGE REPLACEMENT GUIDE You can obtain replacements from your local AquaCo dealer. To maintain performance, warranty and standards use genuine AquaCo replacements. AquaCo 9” x 2.5” Sediment, Fluoride and Aragon Replacement Filters... -
Page 16: Performance Data Sheet
Triple Undersink Water Filtration System Installation Product Code: SYS-925-3 PERFORMANCE DATA SHEET PRODUCT CODE: PP-925-1 SEDIMENT FILTER Micron Rating Triple Gradient: 10 μm outer (nominal), 5 μm middle (nominal), 1 μm inner (nominal) Filter Dimensions 9” x 2.5” Media Type... -
Page 17: Notes
WARRANTY Any contract of sale, order, or quotation made or accepted by or on behalf of Water Filters Pty Ltd (trading as AquaCo Filters) is subject to these terms and conditions of sale. -
Page 18: Price
The date and time AquaCo Filters was first notified of the Product malfunction. • A failure by the Buyer to submit the said Statement within 28 days, after such request is made by AquaCo Filters, will automatically void the Warranty. -
Page 19: Default
• In the case of the Buyer being a natural person, the Buyer commits an act of bankruptcy; then AquaCo Filters may at its option exercise all or any of the following rights (notwithstanding any prior failure to exercise such rights): demand payment of the whole of the monies owing from the Buyer to AquaCo Filters and the Buyer agrees to pay the same immediately.
