Toa XRS-101SCS Specifications

TOA INSTITUTIONAL COMMUNICATION SYSTEM
CORRECTIONAL/SECURITY SUB-STATION
DESCRIPTION
The XRS-101 SCS security loudspeaking station
is designed to withstand damage caused by abuse,
moisture, corrosion, dust, vibration, and temperature
extremes from +150 to -30 degrees F. The station is
available in a (1) watt configuration, with a call origination
pushbutton, and a faceplate with an attached cone
speaker. The (8) ohm speaker is water and fungus
resistant and also functions as a microphone to provide
remote station communication, when included in a
centrally located master control system. The heavy-
duty call origination switch is momentary action with
contacts that are rated at (3) amps., and is mounted
semi-flush to the plate for added security. The station is
available with (1) watt speakers, 25 volt transformers,
and 4-1/2" SQ faceplates.
XRS-101SCS
FEATURES
1. Damage resistant intercom and paging
loudspeakers for indoor or outdoor installation,
providing protected high intelligibility communication.
Durable mar-resistant 11 gauge stainless steel faceplate.
2.
3. Vandal-resistant, weather-resistant call switch.
4. Environmentally resistant cone speaker.
5. Mounting hardware (included).
