Toa MS-900 Worksheet

ESTIMATE WORKSHEET
Project ________________________________________ City ________________________________ State __________ Bid Date __________
c Airport c Correctional
SYSTEM COMPONENTS
Model Description
Exchange mainframe, supports up to (4) MS-900 master stations or telephone masters
and (64) RS Series sub-stations, slots for (2) VS-900MS/VS-900AL, (4) VS-900RS, (1) VS-
VS-900MF 900CO, (1) VS-900AF, (1) VS-900TI, requires (1) PU-200 for (1-32) sub-stations and (2)
PU-200 for (33-64) sub-stations, rack-mount kit included (10 RU), optional wall-mount
bracket (YC-303)
YC-303 Wall-mount bracket for VS-900MF
Power supply for VS-900MF, each mainframe uses (1) PU-200 for (1-32) sub-stations and
PU-200 (2) PU-200 for (33-64) sub-stations, wall-mount brackets included, optional rack-mount
panel (PN-100B)
PN-100B Rack-mount panel (4 RU) for (2) PU-200
Master station line card, supports (2) MS-900, individual record outputs w/control
VS-900MS
activation, removable terminal blocks
Telephone master station line card, supports (2) analog telephones w/caller ID signaling,
VS-900AL
individual record outputs w/control activation, removable terminal blocks
Sub-station line card, 16 ports, supports (16) RS-150, RS-160, RS-170 or RS-180, (2) speech
VS-900RS
links, removable terminal blocks (external amplifier required for station paging)
VS-910RS Four-Wire Sub-station Line Card, supports (16) RS-190
C/O Telephone line interface card, supports (2) outside telephone (C/O) lines, individual
VS-900CO
record outputs w/control activation, removable terminal blocks
Audio function card, (1) paging line output w/ (16) control outputs, (1) external source
VS-900AF
line input w/ (4) trigger inputs, (1) conference link, removable terminal blocks
Tie-line interface card, required in each exchange in a multi-exchange system (16 max.),
VS-900TI
(4) speech paths, (1) data link, removable terminal blocks
Site connector tie-line interface, for remote tie-lined exchange locations, allows stan-
dard media converters (fiber, etc.), required in multi-exchange systems w/ (3) or more
VS-900SC
exchanges, combines four voice links from two VS-900TI, rack-mount kit included (2 RU),
requires PU-200 power supply
STATION EQUIPMENT
MS-900 Desktop Master Station
XWJ-100F Flush-Mount Modular Jack for MS-900 or Telephone Master Station
XWJ-100S Surface-Mount Modular Jack for MS-900 or Telephone Master Station
RS-150 Economy Indoor Sub-station
RS-160 Indoor Sub-station
RS-170 Outdoor Sub-station
RS-180 Panic Sub-station, contact output
RS-190 Four-Wire Indoor Sub-station
RS-191 Optional Four-Wire Handset for RS-190
PERIPHERALS
VS-900DI Direct Select/Master Station Interface Card
VS-910DI Direct Select I/O Card
XPS-24VS Power Supply Supports (1) VS-900DI and (2) VS-910DI
Dealer _________________________________________
City ________________________________ State ______
TOA provides this worksheet as a design aid. The bidding contractor is solely responsible for cost estimates and for meeting specified project requirements.
c Educational c Parking Garage
VS-900 Security Intercom Systems
c Retirement Center c Security
Quantity
Suggested Total $ ___________
c Other
Price Total
