Page 1: System Specifications
2-WIRE INTERCOM SYSTEM EXES-2OOO System Specifications Exchange EX-200 EX-200... - Page 2 Programming Station (No.24) without changing wiring. System Composition The system is composed of three basic blocks: (1) Exchange EX-200 (2) Power transformer unit PU-200 and (3) Stations and Associated equipment. 1) Exchange 1 EX-200 (Basic system) consisting of one Central unit CC-20 and two Line modem units LM-20.
- Page 3 Examples of System Configuration Notes (1) The basic EX-200 exchange consists of one (1) central control unit and 2 line modem units. “option” or additional LM units used according to the user’s requirements. (2) When shown as A or can be selected.
- Page 4 FM carrier band: 15k--35k Hz -40 dBm or less (idle mode) -60 dB or less (1.5k Hz) 20V AC ± 10% 2.5A (EX-200 full system) 24V DC±10% 2.2A (EX-200 full system) 130w (Max.)(EX-200 plus FC-210 Full system) 0° to 40°C (32° to 104°F) 420(w) x 290(h) x 160(d)mm (16.5"(w) x 11.4"(h) x 6.3"(d))
