PRE-RACE
CHECKS
WARNING
• Please do not use power tools for assembly as over tightening can damage your frame.
• If you require further support, consult the installation video or contact us at support@nextlevelracing.com
• Please ensure T-Nuts are correctly placed within the extrusion.
• Lay out and build on a level surface.
• Beware of sharp edges on extrusion pieces.
• Do not force parts together.
• Avoid cross threading bolts.
If you require any support with
your product please contact our friendly team at:
support@nextlevelracing.com
WARNING
CHOKING HAZARD - Small parts not for children under 3 years
or any individuals who have a tendency to place inedible objects
in their mouths.
ASSEMBLY
VIDEO
bit.ly/nlrbuild
4
IN THE
BOX
*NOT TO SCALE
SHIFTER ARM
SHIFTER PLATE 2x CORNER BRACKETS
22 x M8 FULL WIDTH T-NUTS 6 x M8 REGULAR T-NUTS
22 x M8 WASHERS 3 x END CAPS (40 x 40 ANGLED)
Video Instruction: bit.ly/nlrbuild
SHIFTER SUPPORT
SHIFTER ARM SUPPORT CONNECTING PLATE
SHIFTER ARM SUPPORT SHIFTER ARM SUPPORT
BRACKET (LEFT) BRACKET (RIGHT)
18 x M8 16mm BOLTS 6 x M8 20mm BOLTS
NOTE: Some Items Come with
3 x END CAPS (40 x 80 ANGLED)
Rust Resistant Coating
5
