EXES-6000 CP-62
For
TOA EXES-6000 INTERCOM SYSTEM
Central Processing Unit for Single Exchange
CP-62
INSTALLATION HAND BOOK
TOA ELECTRIC CO., LTD.
KOBE, JAPAN
133-21-079-2
