More FAQs are available here:
https://www.foscam.com/faqs/index.html
5.2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
Username and password
Default admin username: admin with a random password
5.3 Specification
Image Sensor
Lens
Video
Network
Sensor
Display Resolution
Min. Illumination
Lens Type
Focal Length
Aperture
Angle of View
Image Compression
Image Frame Rate
Resolution
Stream
Image Adjustment
Flip Image
Infrared Mode
IR Range
Ethernet
Remote Access
Data Rate
Wireless Standard
Network Protocol
High Definition Color CMOS Sensor
4.0MegaPixels
0 Lux (With IR Illuminator)
Glass Lens
f: 2.8-12mm
f: 2.8-12mm
Diagonal : 36° ~126° °
H.264
20fps（2K）/11fps（720P）/, downward adjustable
4M(2560* 1440), 3M(2304*1296),
1080P(1920x1080),720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Dual stream
The hue, brightness, contrast, saturation, sharpness are
adjustable
flip and mirror
Automatic and manual
4pcs IR-LEDs, night vision range up to 20 metres
One 10/100Mbps RJ45 port
P2P
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
IEEE802.11ac: 433Mbps(Max.)
2.4G/5G dual band, IEEE802.11b/g/n/ac
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、
RTSP、ONVIF
110
