Toa SM-60 Instruction Manual

TOA PROFESSIONAL SOUND SPEAKER SYSTEM

General Description

The SM-60 is a full-range, small monitor speaker system with a rated input of 70W and an
input impedance of 16 ohms. Its sealed box enclosure houses two full-range cone speakers
(5-inch, 12cm) with high efficiency and durability. The enclosure is made of cast aluminum,
so that it can withstand the roughest use. With an accessory bracket, the SM-60 is mountable
on microphone stands (Fig.1), microphone stand shafts (1.10" MAX)(Fig.2), plates(Fig.3)
and walls (Fig.4).
TOA ELECTRIC CO., LTD.
1 When carrying out the installation of Fig. 4 first
take off the bracket No. 2 and install
the bracket No. 1 on the wall with the
wooden screws.
2 Bracket No.2 will change in position by 90 degrees
when these mounting holes are used.
KOBE, JAPAN
Instruction Manual
model SM-60
