Thank you for purchasing TOA's Speaker System.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
................................................................................. 2
........................................................................................................... 3
......................................................................................... 4
..................................................................................... 5
.................................................................................................. 5
................................................................................................................... 6
............................................................................................ 12
OPERATING INSTRUCTIONS
SR-F09,
SR-F09-V2, SR-F09-V3
SR-L09,
.............................................................................. 3
.............................................................................. 4
............................................................. 7
SR-F09-V1
SR-L05
.................................. 8
........................... 9
Advertisement
Table of Contents
Related Manuals for Toa SR-F09
Summary of Contents for Toa SR-F09
-
Page 1: Table Of Contents
..................5 7. CONNECTIONS ....................5 8. FLYING ........................6 9. DIGITAL PROCESSOR SETTINGS ............. 7 10. SPEAKER STAND FOR SR-F09 AND SR-F09-V1 ........8 11. CHANGE FROM SINGLE- TO BI-AMPLIFIER DRIVE ......9 12. SPECIFICATIONS .................... 12 Accessory ........................ 12 Thank you for purchasing TOA's Speaker System. -
Page 2: Safety Precautions
When the Unit is in Use • Flying Precautions (SR-F09, SR-F09-V1, SR-F09- V2, SR-F09-V3) • Do not stand or sit on, nor hang down from the unit Be sure to follow the instructions below. -
Page 3: General Description
60° horizontal by 40° vertical, while the CD horn tweeter in the SR-F09-V1 and SR-F09-V3 covers an angle of 90° horizontal by 60° vertical. • The SR-F09 and SR-F09-V1 have flying hardware on their top and bottom panels. The bottom panel is also provided with nuts for installing an optional stand. -
Page 4: Dimensional Diagram
16-W3/8'' Nut Center of gravity Center of gravity 2-M8 Nut Flying fitting (4 places) [SR-L09] [SR-L05] Unit: mm 5. WIRING DIAGRAMS [SR-F09, SR-F09-V1, SR-F09-V2, SR-F09-V3] [SR-L09] [SR-L05] Screw terminal 4P Screw terminal 4P Screw terminal 2P (LEFT) (RIGHT) NL4MP NL4MP... -
Page 5: Input Connectors
DP-0206 Digital Processor Power amplifier MAIN OUT INPUT BASS OUT SR-L09, SR-L05 7.2. Singular System of SR-F09, SR-F09-V1, SR-F09-V2 and SR-F09-V3 DP-0206 Digital Processor SR-F09, SR-F09-V1, SR-F09-V2, SR-F09-V3 Power amplifier INPUT MAIN OUT 7.3. About the Power Amplifier to Connect It is recommended that you use a power amplifier with output of over 400 W (per channel when an 8Ω... -
Page 6: Flying
8. FLYING Be sure to refer flying construction work to the dealer from whom WARNING the speaker was purchased. 8.1. SR-F09 and SR-F09-V1 Shown below are the general flying methods: Never suspend as illustrated below: • Flying through only • Vertical suspension of one suspension point more than 3 speakers. -
Page 7: Digital Processor Settings
9. DIGITAL PROCESSOR SETTINGS [Bi-amplifier drive for SR-F09+SR-L09/L05] X-over Combination Filter Gain Delay Channel Polarity (dB) (msec) HPF/LPF TYPE Freq. (Hz) TYPE Freq. (Hz) Gain (dB) HPF (24dB) LinkwitzRiley NORMAL LPF (24dB) 0.667 SR-L09 +5.0 LinkwitzRiley +2.5 4.318 HPF (24dB) -
Page 8: Speaker Stand For Sr-F09 And Sr-F09-V1
10. SPEAKER STAND FOR SR-F09 AND SR-F09-V1 The speaker stand manufactured by Köning & Meyer GmbH (K & M) of Germany is made available for use with TOA's SR-F09 and SR-F09-V1 speakers. The speaker stand consists of a Stand and a Stand Bracket, which are sold separately. -
Page 9: Change From Single- To Bi-Amplifier Drive
11. CHANGE FROM SINGLE- TO BI-AMPLIFIER DRIVE The SR-F09, SR-F09-V1, SR-F09-V2, and SR-F09-V3 can be driven by bi-amplifiers if wiring of their internal connectors is changed. When using these speakers in combination with the SR-L09, its internal wiring must also be changed. - Page 10 6. Replace the front grille using the front grille fixing screws. Connector Woofer removed. 11.2. Input Connector Connections Change each speaker's input connectors as follows. Also, attach the supplied marker (seal) to change the indication. Seal supplied with SR-F09, SR-F09-V1, SR-F09-V2, and SR-F09-V3 Seal supplied with SR-L09...
-
Page 11: Connection Diagram
• Pins of the Neutrik connector are connected as shown in the table below. Pin No. SR-F09, SR-F09-V1, SR-F09-V2, SR-F09-V3 SR-L09 LOW + Left* + * The "left" and the "right" LOW - Left are the directions as viewed from the front. -
Page 12: Specifications
Note : The design and specifications are subject to change without notice for improvement. Traceability Information for Europe Manufacturer: Authorized representative: TOA Corporation TOA Electronics Europe GmbH 7-2-1, Minatojima-Nakamachi, Chuo-ku, Kobe, Hyogo, Suederstrasse 282, 20537 Hamburg, Japan Germany URL: http://www.toa.jp/...
