Specifications for AS-Interface Adapter Module

Type designation: 221-589.24 AS-I MODUL
Technical data: power supply
Designation
Operating voltage U
BUS
No-load current
Rated isolation voltage
AS-i specification
Configuration IO code / ID code / ID2 code
Reverse voltage protection
*Observe the operating current for the 24 V DC interface module!
When using an A/B slave with a version 2.0 ASI master, it must be ensured that parameter P3 =
1 and output DO3 = 0 are set.
Technical data: inputs (I/O matrix)
Bit
DI0
DI1
DI2
DI3
Technical data: outputs (I/O matrix)
Bit
DO0
DO1
DO2
DO3
Technical data: design of I/O module for T.VIS
Designation
Dimensions
Housing material
Connection
Pin strip
Vibration proofness
Shock proofness
Protection class
Specifications for AS-Interface Adapter Module
Description
23.5...31.6 V DC
≤ 22 mA*
≤ 0.5 kV
V3.0 (max. 62 slaves with master V3.0)
7.A.7.E
yes
Feedback
Input 1 "Start"
Input 2 "End"
Input 2 "Main stroke Y3"
Not used
Actuation
Activation of solenoid valve Y1
Activation of solenoid valve Y2
Activation of solenoid valve Y3
Reserved for A/B identification
Description
85 x 61 x 32 mm
PA6-GF30-V0
2-pin, 0.5 ... 1.5 mm
10-pin (without 7 + 8), grid 3.5 mm
55 Hz (1 mm)
15 x g
IP 20
Technical Data
