- Page 1 MANUAL ENGLISH Parcan 64 Short Incl.Terminal Ordercode: 30426/30427 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Lamp housing ................................8 Installation ................................... 8 Installing the Lamp ................................ 8 Set Up and Operation ..............................10 Filter frame retaining clip ............................10 Maintenance ..................................10 Changing the Lamp ..............................11 Troubleshooting ................................11 No Light ..................................11 Product Specifications ..............................12 Dimensions ..................................13 Notes ....................................14 Ordercode: 30426/30427... -
Page 3: Warning
Your shipment includes: ● Showtec Parcan 64 Short with 0,8m Schuko power cable ● 1x Filter frame ● User manual... - Page 4 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
The installation must always be secured with a safety attachment, e.g. an appropriate safety net or safety-cable. When rigging, derigging or servicing the Parcan 64 Short, always make sure, that the area below the installation place is blocked and staying in the area is forbidden. Ordercode: 30426/30427... -
Page 6: Connection With The Mains
UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK SILVER NEUTRAL YELLOW/GREEN GREEN GREEN PROTECTIVE GROUND Make sure that the device is always connected properly to the earth! Improper installation can cause serious damage to people and property! Ordercode: 30426/30427... -
Page 7: Return Procedure
After this period, complaints will not be handled anymore. Complaints will only be considered if the client has so far complied with all parts of the agreement, regardless of the agreement of which the obligation is resulting. Ordercode: 30426/30427... -
Page 8: Description Of The Device
Parcan 64 Short, Incl. Terminal and socket Description of the device Features The Showtec Parcan 64 Short is a parcan with high output and great effects. • Lamp: PAR 64 • Lamp socket: GX16D (max 230V) • Capacity: max 1000W •... -
Page 9: Lamp Housing
Damages caused by non-observance are not subject to warranty. Installing the Lamp The Showtec Parcan 64 Short uses the GX16D (ordercode 80107) as manufactured by all popular manufacturers. Use only the appropriate lamp for your unit. Note that, product versions that use other lamps, may be offered in the future. Check your product specification label for information. - Page 10 07) Replace the rear cover of the lamp (Fig. 07). Make sure that the screw at the bottom of the rear cover fits in the hole at the bottom of the front cover. 08) The Parcan 64 Short is now ready to use. Fig. 03 Fig. 04 Fig. 05 Fig. 06 Fig. 07 Ordercode: 30426/30427...
-
Page 11: Set Up And Operation
Do not immerse in liquid. Wipe lens clean with glass cleaner and a soft cloth. Do not use alcohol or solvents. The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light- output very quickly. Ordercode: 30426/30427... -
Page 12: Changing The Lamp
04) If you are unable to determine the cause of the problem, do not modify the Parcan 64 Short, as this may damage the unit and the warranty will become void. 05) Return the device to your Showtec dealer. Problem... -
Page 13: Product Specifications
Parcan 64 Short, Incl. Terminal and socket Product Specifications Model: Showtec Parcan 64 Short Input voltage: 230V, 50Hz Capacity: max 1000W Lamp socket: GX16D (max 230V) Housing: Die-cast aluminum Cooling: Convection IP rating: IP20 Power cable 0,8m with Schuko connector... -
Page 14: Dimensions
Parcan 64 Short, Incl. Terminal and socket Dimensions Ordercode: 30426/30427... -
Page 15: Notes
Parcan 64 Short, Incl. Terminal and socket Notes Ordercode: 30426/30427... - Page 16 ©2017 Showtec...
