Operating Guide Termix VMTD MIX Compact 28
6.1.7 Circulator pump
The UPML, UPMXL circulator pumps are designed for circulating
liquids in heating systems with variable flows, internally controlled
with three proportional pressure curves and three constant
pressure/power curves to be selected via user interface.
EuP 2015 Ready.
The MAGNA3 circulator pumps are designed for circulating liquids
in heating systems with variable flows where you want to optimise
the setting of the pump duty point, thus reducing energy costs.
EuP 2015 Ready.
6.1.8 Grundfos UPML / UPMXL instructions
PP = Proportional pressure (fast flash)
CP = Constant pressure (slow flash)
