Key Digital KD-IP922ENC-II Manual page 43

1. It is recommended to reset the switch to factory defaults before configuring for multicast operation. Power
up the device, wait for about 2 minutes, using a paper clip press and hold a reset button for more than 10
seconds and then release. After device is rebooted power down and then power up the device. Wait while
the device is restarted and ready to use.
2. Connect your PC to the switch directly using a network cable.
3. Configure your PC's IP address to the same range as the switch (default 192.168.0.xxx).
4. Enter the switch's IP address (default is 192.168.0.239) in your browser and press ENTER.
5. Enter user name and password (default is "admin" and "password"). Then click Log In.
Back to top
IGMP Setup Guide: Engenius
1080p Systems (KD-IP1080, KD-IP120)
43 | P a g e
