Quick Installation Guide Overview The Managed Ethernet Switch solutions are designed for supporting standard industrial applications. Managed switches are easier to prioritize, partition, and organize a user’s network, providing a more reliable and better quality services. Package Checklist Please verify the box contains the following items: Item Quantity Management Ethernet switch...
● Damage to eyes from accidental exposure to a beam emitted by a laser source. ● Damage to eyes from viewing the connector that attaches to a broken fiber or an energized fiber. Technical Specifications Model VX-IGP-1204F Ethernet Copper RJ45 Ports 10/100/1000 Mbps speed auto-negotiation MDI/MDIX Auto-crossover...
Quick Installation Guide DIN-Rail Mounting Mounting steps: 1. Screw the din-clip with screws in the accessory kit. 2. Hook the unit onto the din-rail. 3. Push the bottom of the unit towards the din-rail until it locks in place. Wall Mounting Mounting steps: 1.
Page 6
Quick Installation Guide Ethernet Interface (RJ45 Ethernet) The switch provides two types of Ethernet interfaces: electrical (RJ45) and optical (SFP) interfaces. Connecting the Ethernet interface via RJ45: ● To connect the switch to a PC, use straight-through or cross-over Ethernet cables, ●...
V+ and V- contacts on the terminal block respectively and tighten the wire-clamp screws to prevent the wires from being loosened. Note: 1. The DC power should be connected to a well-fused power supply. VX-IGP-1204F Second Power Supply First Power Supply Alarm Relay and Ground The alarm relay output contacts are in the middle of the DC terminal block connector as shown in the figure below.
Quick Installation Guide Ground Connector Console Connection The Console port is for local management by using a terminal emulator or a computer with terminal emulation software. ● DB9 connector connect to computer COM port ● Baud rate: 115200bps ● 8 data bits, 1 stop bit ●...
(female) connector cable is required. The RJ45 connector of the cable is connected to the CID port of VX-IGP-1204F; the DB9 connector of the cable is connected to the PC COM port. The pin assignment of the console cable is shown below: Connect &...
Quick Installation Guide LED STATUS INDICATIONS LED Name Indicator /color Condition On Green P1/P2 power line has power P1/P2 P1/P2 power line disconnect or does not have power supplied On Red Ethernet link fails, alarm or power failure alarm occurs Alarm No Ethernet link fails and no power failure alarm On Green...
