- Page 1 VX-GPU2610 L2+ Managed GbE UPoE Switch Quick Installation and Initial Configuration...
-
Page 2: Table Of Contents
Contents Chapter 1 Introduction ............. 1 Overview ..................... 1 Front View of the Switch ................ 1 Rear View of the Switch ................. 1 LED Descriptions ..................2 Mode/Reset Button ................3 Chapter 2 Installing the Switch ........5 Package Contents ................... 5 Mounting the Switch on Wall ............... -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction Overview This user guide describes how to install, configure, and troubleshoot the VX- GPU2610, 10 Ports L2+ Managed GbE UPoE Switch. By reading this user guide, users can perform the following tasks: To check the switch status by reading the LED behavior •... -
Page 4: Led Descriptions
LED Descriptions The LEDs on the front panel provide users with switch status checking and monitoring. There are three types of LEDs as follows: System LED: Indicates if the switch is powered up correctly or not. • Mode LEDs: Indicates the mode of all ports on the switch. Users can press the •... -
Page 5: Mode/Reset Button
Table 3: Port Status LEDs When Link/Act/Speed Mode LED Lit Color State Description The port is enabled and established a link to connected device, Green and the connection speed is 1000Mbps. Blinking The port is transmitting/receiving packets, and the connection Green speed is 1000Mbps. - Page 6 Restore the Switch to Factory Defaults: To restore the original factory default • settings back to the switch. Note According to the table below, users can easily judge which task is being performed by reading the LED behaviors while pressing the Mode/Reset button. Once the LED behaviors are correctly displayed, users may just release the button.
-
Page 7: Chapter 2 Installing The Switch
Chapter 2 Installing the Switch Package Contents The Switch • AC Power cord (Optional) • Four adhesive rubber feet • Installation Guide • Note The switch is an indoor device. If it is to be used with outdoor devices such as outdoor IP cameras or outdoor WiFi APs, then users are strongly suggested to install a surge protector or surge suppressor in order to protect the switch. -
Page 8: Mounting The Switch On Desk Or Shelf
Figure 4: Attaching switch to the wall Mounting the Switch on Desk or Shelf Step 1: Verify that the workbench is sturdy and reliably grounded. Step 2: Attach the four adhesive rubber feet to the bottom of the switch. Figure 5: Attaching the Rubber Feet Connecting the AC Power Cord Step 1: Connect the AC power cord to the AC power receptacle of switch. -
Page 9: Installing Sfp Modules
Figure 6: Connecting AC power cord Installing SFP Modules You can install or remove a mini-GBIC SFP module from a SFP port without having to power off the switch. Step 1: Insert the module into the SFP port. Step 2: Press firmly to ensure that the module seats into the connector. -
Page 10: Chapter 3 Initial Configuration Of Switch
Chapter 3 Initial Configuration of Switch Initial Switch Configuration Using Web Browsers After powering up the switch for the first time, you can perform the initial switch configuration using a web browser. For managing other switch features, please refer to the Web interface user guide for details. To begin with the initial configuration stage, you need to reconfigure your PC’s IP address and subnet mask so as to make sure the PC can communicate with the switch. - Page 11 Step 4: Right-click on your local adapter and select Properties Step 5: In the Local Area Connection Properties window highlight Internet Protocol Version 4 (TCP/IPv4) then click the Properties button. Note Be sure to record all your PC’s current IP settings to be able to restore them later.
- Page 12 6. Enter the factory default username and password in login page. Click “Login” to log into the switch. Note: The factory default username and password is admin/admin.
-
Page 13: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting The following table provides information for users to easily troubleshoot problems by taking actions based on the suggested solutions within. Table 5: Troubleshooting Table Possible Symptoms Suggested Solutions Causes 1. Check if correct power cord is connected firmly to the switch and to the AC outlet socket.
