PEAKTOP F40995GA Quick Start Manual

Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged parts.
If any parts are missing or damaged, do not attempt to assemble or use the product. Please contact customer service for replacement.

CARTON CONTENTS:

Part# Description
01. Top fountain panel
02. Top fountain frame
03. Cover
04. Mesh rack
05. Pump
06. Washer
07. Screw 1
08 Connector
09. Screw 2
10. Basin

TOOLS REQUIRED FOR ASSEMBLY:

Screwdriver (Not included)

FOUNTAIN ASSEMBLY INSTRUCTIONS:

1. Unpack the contents of the box and check to make sure that
all items are accounted for and in good condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. Align the four tabs of the top fountain panel with the four fillisters on the back of the top fountain frame and then place the panel of top fountain into the
framework with the spigot facing forward. Attach the panel in the top fountain frame with four washers and screws. (Fig1)
4. Place the basin on a flat, level surface and then place the pump into the pump housing of the basin. Align the two wedges on the underside of the top
fountain with the two holes on top of the basin and then place the top fountain onto the basin. Note: Draw the pump power cord out through the cord slot at
the back of the basin and then insert the water supply tube into the notch. From the back of the fountain use the connector brackets and two screws and
washers to secure the top fountain to the basin. (Fig 2)
5. Insert the water supply tube at the bottom of top fountain into the pump outlet and then place the cover of pump housing to hide the pump Finally place the
mesh rack in the basin. Please make sure the water falls down from the spigot and right onto the mesh surface which will minimize water splashing (Fig
3).
6. Add clean water into the basin. The water level should be approx. 30mm below the top edge of the basin. (Fig 4)
7. Connect the pump power cord to a GFCI outlet. Turn on the spigot on the panel of top fountain and the product will begin to function as intended. (Fig 4)
8. To eliminate the possibility of water damage around your fountain, check for leaks and excessive splashing after the initial setup of your fountain. It is
highly recommended that this fountain be placed in an area that will not be damaged should the area come in contact with liquid.
9. Do not leave your fountain running for extended periods of time when no one is present to observe the performance.
10. Check the area around your fountain on a regular basis to ensure that there is no leakage.
NOTE:
The diagrams shown are for illustrative purposes only and are not to scale.
Vendor Item # F40995GA
Target DPCI #: 084 09 3478
Description: Stained Glass Fountain
Questions, Problems, Missing Parts? Before returning to your retailer,
PLEASE CALL CUSTOMER SERVICE at (866) 728-6187
9am – 5pm EST, Mon – Fri or e-mail customerservice@srg-usa.com.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Quantity
1
1
1
1
1
4
4
2
4
1
