PEAKTOP FA0394EC Quick Start Manual

Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged parts.
If any parts are missing or damaged, do not attempt to assemble or use the product. Please contact customer service for replacement.

CARTON CONTENTS:

Part# Description
01. Top fountain
02. Oil lamp
03. Light socket
04. Water supply tube
05. Cover
06. Basin
07. Connector
08. Screw
09. Pump

TOOLS REQUIRED FOR ASSEMBLY:

Screwdriver (Not included)

ASSEMBLY INSTRUCTIONS:

1. Unpack the contents of the box and check to make sure that all items
are accounted for and in good condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. Place the basin on a flat, level surface and the pump in the pump housing of the basin. Draw the pump power cord out from the back of the basin. (Fig 1)
4. Align the wedges on the underside of the top fountain with the notches on the basin top and place the top fountain onto the basin. From the back of the
fountain use the connector brackets and two screws and washers to secure the top fountain to the basin (Fig 2).
5. Insert the water supply tube from the underside of the top fountain into the pump outlet and then place the cover over the pump housing. Place the lamp
sockets into their matching holes at the both sides of basin and place the oil lamps into them. If desired, you may choose to ignite the oil lamps. Read all
of the oil lamp instructions prior to igniting the oil lamps. (Fig 3)
6. Add clean water into the basin. The water level should be approx 30mm below the top edge of the basin. (Fig 4)
7. Connect the pump power cord to a GFCI outlet. The product will begin to function as intended. (Fig 4)
8. To eliminate the possibility of water damage around your fountain, check for leaks and excessive splashing after the initial setup of your fountain. It is
highly recommended that this fountain be placed in an area that will not be damaged should the area come in contact with liquid.
9. Do not leave your fountain running for extended periods of time when no one is present to observe the performance.
10. Check the area around your fountain on a regular basis to ensure that there is no leakage.
NOTE:
The diagrams shown are for illustrative purposes only and are not to scale.
Vendor Item #: FA0394EC
Target DPCI #: 084 09 3660
Description: Lion Head and Lamp Fountain
Questions, Problems, Missing Parts? Before returning to your retailer,
PLEASE CALL CUSTOMER SERVICE at (866) 728-6187
9am – 5pm EST, Mon – Fri or e-mail customerservice@srg-usa.com.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Quantity
1
2
2
1
1
1
2
4
1
