PEAKTOP Sean Conway Tier Fountain Instructions

Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged parts.
If any parts are missing or damaged, do not attempt to assemble or use the product. Please contact customer service for replacement.

CARTON CONTENTS:

Part# Description
01. Top fountain
02. Middle basin
03. Middle pedestal
04. Pump
05. Basin
06. Plug
07. Pedestal

TOOLS REQUIRED FOR ASSEMBLY:

No tools required

ASSEMBLY INSTRUCTIONS:

1. Unpack the contents of the box and check to make sure that all items are accounted for and
in good condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. Place the pedestal on a flat, level surface. Lower the basin over the pedestal aligning the
tabs on the wedge and turning clockwise to lock the basin onto the pedestal. Place the pump
in the basin and run the pump power cord down through the cord tube and draw it out from
the cord slot at the bottom of the pedestal. Then seal the cord tube from the top with the plug..
(Note: clip the pump power cord into the cord slot of plastic plug). (Fig 1)
4. Run the water supply tube of middle basin out through the middle pedestal and then connect
them by aligning the tabs on the wedge and turning clockwise to lock them together (Fig 2).
5. Insert the water supply tube from the middle pedestal into the pump outlet and connect the middle pedestal and basin by locking the wedge plate. Place
the top fountain onto the middle basin making surt to align the notch of the top fountain with the wedge of the middle basin. (Fig 3).
6. Add clean water into the basin. The water level should be approx 30mm below the top edge of the basin. (Fig 4)
7. Connect the pump power cord to a GFCI outlet. The product will begin to function as intended. (Fig 4)
8. To eliminate the possibility of water damage around your fountain, check for leaks and excessive splashing after the initial setup of your fountain. It is
highly recommended that this fountain be placed in an area that will not be damaged should the area come in contact with liquid.
9. Do not leave your fountain running for extended periods of time when no one is present to observe the performance.
10. Check the area around your fountain on a regular basis to ensure that there is no leakage.
NOTE:
The diagrams shown are for illustrative purposes only and are not to scale.
Vendor Item # FB0218AA
Target DPCI #: 084 09 3817
Description: Sean Conway Tier Fountain
Questions, Problems, Missing Parts? Before returning to your retailer,
PLEASE CALL CUSTOMER SERVICE at (866) 728-6187
9am – 5pm EST, Mon – Fri or e-mail customerservice@srg-usa.com.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Quantity
1
1
1
1
1
1
1
