PEAKTOP Vendor F40991AA Instructions

--------------------------------------------------------------------------------------------------------------------------------------
Questions, Problems, Missing Parts? Before returning to your retailer, CALL OUR CUSTOMER SERVICE
DEPARTMENT at 1(866)728-6187 8 a.m.– 6 p.m. EST, Monday – Friday or e-mail us at
P ARTS LIST:
Part# Description
01. Fountain basin
02. Pump
03. Pillar
04. Top Fountain

TOOLS REQUIRED FOR ASSEMBLY:

No tools required

FOUNTAIN ASSEMBLY INSTRUCTIONS:

1. Unpack the contents of the box and check to make sure that all items are accounted for and in good condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
Locate the Water Pump and adjust the flow control to the "Maximum (+)" setting. Position the Pillar over the Basin and connect the Water Supply Tube
3.
from the bottom of the Pillar, into the outlet of the Water Pump at the basin as shown in Fig. 2.
Place the Pillar flat in the Basin and make sure that the corners of the Pillar are fitted into the corners provided in the Basin (see Fig.3).
4.
Place the Top Fountain onto the Pillar as shown in Fig.4.
5.
Fill the basin with clean water. The water level should be approximately 1"(25mm) below the rim of the Basin.
6.
7. Plug the Water Pump power-cord into a properly grounded, grounding type receptacle (GFCI). The fountain will begin to flow. See the "HINTS &
TROUBLESHOOTING" section for additional details.
8. To eliminate the possibility of water damage to areas around your fountain, check for leaks and excessive splashing after the initial setup of your fountain.
It is highly recommended that this fountain be placed in an area that will not be damaged should the area come in contact with liquid.
9. Do not leave your fountain running for extended periods of time when no one is present to observe the performance.
10. Check the area around your fountain on a regular basis to ensure that there is no leakage.

MAINTENANCE OF YOUR FOUNTAIN:

1. Keep water clean - using clean water will reduce mineral deposits and improve water clarity.
2. Clean the fountain periodically to prevent mineral deposits and contamination. Use warm soapy water and a stiff brush for heavily stained surfaces.
Do not use harsh chemicals as this will damage the finished surface and void the warranty.
3. Add clean water periodically to ensure that the pump is fully submersed in water.
4. Disconnect the power and empty the basin if the fountain will not be used for an extended time.
5. If installed outdoors and in a freeze-area of the country, ensure that all water is removed and the unit is completely dry. This product is NOT to be
operated below 41°F (5°C) freeze damage may occur.

PUMP INSTRUCTIONS:

SPECIAL WARNINGS & CAUTIONS:
WARNINGS:
1. To reduce the risk of electric shock, connect only to a properly grounded, grounding type receptacle (GFCI).
2. Do not exceed the voltage shown on the pump.
3. Always disconnect the pump from the power source prior to beginning any maintenance or work on the pump or fountain.
4. Inspect the power cord for damage before installation and/or maintenance. Replace the entire pump if damage is found.
5. For pumps with a 3-prong, grounded type plug, do not remove the grounding pin from the plug on the power cord.
CAUTIONS:
1. The fountain shall not be installed within 10 feet (3.05m) of a pool or spa. When the pump is connected to a GFCI protected circuit, the fountain unit has
the option of being installed no less than 5 feet (1.52m) from a pool or spa.
2. Use only with portable, self contained fountains no larger than 5'(1.52m) in any direction.
3. Use a proper power source as indicated on the pump label. Keep the cord away from high temperature and/or heat sources.
4. Do not lift the pump by its power cord.
5. Keep the fountain out of reach of children.
6. Do not let the pump run dry. Pump must be completely submerged for proper operation and cooling.
7. Do not pump heated liquids.
8. Operate in freshwater only. Avoid heavily chlorinated water and water with high PH levels.
Item Description: Pedestal Fountain with Ball
customerservice@srg-usa.com
Quantity
1
1
1
1
INSTRUCTIONS
Vendor Item # F40991AA
