PEAKTOP F40276AA Instructions

--------------------------------------------------------------------------------------------------------------------------------------
Questions, Problems, Missing Parts? Before returning to your retailer, CALL OUR CUSTOMER SERVICE
DEPARTMENT at 1(866)728-6187 9 a.m. – 5 p.m. EST, Monday – Friday or e-mail us at
P ARTS LIST:
Part# Description
01. Basin
02. Bulb (present)
03. Pump
04. Rubber Tube
05. Upper Frame
06. Upper Tube
07. Lower Tube with Adapter
08 Lower Tube

TOOLS REQUIRED FOR ASSEMBLY:

Flat Head Screw Driver (not included)
Phillips Head Screw Driver (not included)
Adjustable Wrench (not included)

FOUNTAIN ASSEMBLY INSTRUCTIONS:

1. Unpack the contents of the box and check to make sure that all items are accounted for and in good condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. Place the Basin in the desired location and route the Pump power cord from the underside of the Basin through the notch provided as shown in Figure 1.
4. Adjust the Flow Control on the Pump to the "Maximum (+)" setting.
5. Assemble the copper frame by joining the Upper Tubes to the Upper Frame and then screw the Lower Tubes to the Upper Tubes. Once the entire frame is
assembled, insert the Lower Tubes through the Base Plate and secure by tightening the large nuts and washers (See fig.2).
6. Insert the one end of the Rubber Hose on to the Adapter on the Lower Tube. Insert the other end of the Rubber Hose onto the outlet of the Pump.
Position the Frame Assembly with the attached Base Plate onto the Basin. Align the holes in the corners of the Base Plate with the holes in the Basin
and secure using the (4) small Screws (See fig.3).
7. Assemble the Slate Panels together by overlapping the Panels from the top of one to the bottom of the next one (Note: the Slate Panel with (2) Holes
should be at the bottom end of the group of assembled Panels) Use the Long Screws, Washers and Cap Nuts to secure the Panels.
8. Hang the Panels from the top of the copper frame using the (2) Copper Clips, (2) Long Screws, (2) Washers and (2) Cap Nuts (See fig.4).
9. Attach the lights into the sockets on the Lampshade and route the Cord Assembly to secure each end into the clips provided as shown in Figure 5.
10. Attach the Lampshade to the Upper Frame using the (2) Short Screws, Washers and Cap Nuts. (Note: Route the power cord out through the back
clearance and plug the end of the power cord into the Transformer - see fig.5)
11. Place the decorative pebbles on the Base Plate and fill the Basin with clean water to within 2" of the top of the Basin.
12. In order to better stabilize the fountain in your garden during bad whether, please attach the fountain to something nearby that strong enough to stand the
blow. The chain on the back of the fountain is used to better secure the fountain from tilting.
13. Plug the power cords from the Pump and the Transformer into a properly grounded, grounding type receptacle (GFCI). The fountain will begin to flow
(see HINTS & TROUBLESHOOTING" for additional information.
14. To eliminate the possibility of water damage to areas around your fountain, check for leaks and excessive splashing after the initial setup of your fountain.
It is highly recommended that this fountain be placed in an area that will not be damaged should the area come in contact with liquid.
15. Do not leave your fountain running for extended periods of time when no one is present to observe the performance.
16. Check the area around your fountain on a regular basis to ensure that there is no leakage.

MAINTENANCE OF YOUR FOUNTAIN:

1. Keep water clean - using clean water will reduce mineral deposits and improve water clarity.
2. Clean the fountain periodically to prevent mineral deposits and contamination. Use warm soapy water and a stiff brush for heavily stained surfaces.
Do not use harsh chemicals as this will damage the finished surface and void the warranty.
3. Add clean water periodically to ensure that the pump is fully submersed in water.
4. Disconnect the power and empty the basin if the fountain will not be used for an extended time.
5. If installed outdoors and in a freeze-area of the country, ensure that all water is removed and the unit is completely dry. This product is NOT to be
operated below 41°F (5°C) freeze damage may occur.
Item Description: Slate Fountain
customerservice@srg-usa.com
Quantity Part# Description
1 09. Base Plate
2 10. Large Washer
1 11. Large nut
1 12. Slate panel with (2) Holes
1 13. Slate Panel with (4) Holes
2 14. Screw
1 15. Nut
1 16 Cap Nut
INSTRUCTIONS
Vendor Item # F40276AA
Quantity
1
2
2
1
3
8
2
10
Part# Description
17. Copper clip
18. Lights with Cord Assembly
19. Lampshade
20. Screw - Short
21. Transformer
22. Pebbles
23. Screw – Small
24. Glass Tube (present)
Quantity
2
1
1
2
1
1.5kgs
4
2
