CONTENTS 1. IMPORTANT SAFETY INSTRUCTINS................3 2. RECYCLING........................6 3. INSTALLATION........................ 8 4. TECHNICAL SPECIFICATIONS..................9 4.1. General Appearance...................... 9 4.2.Technical Specifications....................9 5. BEFORE USING THE APPLIANCE................10 5.1. Preparing Your Dishwasher For First Use..............10 5.2. Setting the Water Softener....................10 5.3. Filling the Dishwasher Salt Dispenser................12 5.4.
Page 4
Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
Page 5
INTRODUCTION Please read this user manual and particularly the safety instructions completely and carefully. They will save you time and effort and help to ensure optimum dishwasher performance. Be sure to observe all listed warnings and cautions. Look particularly for the icons with exclamation marks inside. The information icon will also provide important references.
1. IMPORTANT SAFETY INSTRUCTIONS WARNING: When using the dishwasher, follow basic precations. Read all instructions before using the dishwasher! Save these operating instructions and pass them on to any future user. • Use the dishwasher only for its intended purpose as described in this user manual.
Page 7
• The cup racks are designed to support cups, glasses and kitchen utensils. When the cup racks are in the dishwasher do not lean on or use the cup racks to support your body weight. • This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
Page 8
• Do not drink and play with the water in the appliance. harmful residues could be present. • To reduce the risk of injury, do not allow children to play in or on a dishwasher. • When children become old enough to operate the appliance, it is the responsibility of the parents/legal guardians to ensure the children are instructed in safe practices by qualified persons.
• Do not store or use flammable liquids or vapors in the area of the dishwasher, near or on the appliance. • Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.
Page 10
WARNING!: Risk of injury or suffocation! Ensure that any plastic wrappings, bags, small pieces etc. are disposed of safely and kept out of the reach of children. SAVE THESE INSTRUCTIONS USA-CAN - 7...
3. INSTALLATION WARNING: When installing the dishwasher, follow basic precau-tions, including the following: Please check the standards and local codes for placement of machine. • Installation, maintenance and repair should be performed by a qualified installer. Work by unqualified persons could be danger-ous and may void the warranty.
4. TECHNICAL SPECIFICATIONS 4.2 Technical Specifications Permissible 43.5-145psi water (0.3 - 10 pressure bars) 120 V (volts), 12 Electrical A (amps), connection 60Hz (hertz) Total power 1400 (W) Heater power 1100 (W) NOTICE: Because we continually strive to improve our products, we may change our specifications and design without prior notice.
5.BEFORE USING THE 5.2. Setting the Water Softener (Model Depending) APPLIANCE Dishwasher needs soft water for good 5.1 Preparing Your Dishwasher For cleaning results. Hard water results in a First Use build-up of calcium deposits on dishware • Make sure the electricity and supply water and in the dishwasher.
Page 14
ness level by using the test strip(if available). Follow step in the image when use the test strip. Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite...
1. Open the door of the machine, 2. Press and hold “Start/Pause + On/Off” key for 3 seconds, 3. The machine gives an audible warning when it is ON, 4. Then, press and hold “Program Selection + Cancel” key until “SL” is represented on the display, the machine will display the last setting, 5.
5.4. Salt Refill Indicator WARNING: Do not use too much (Model Depending) detergent if your water supply is soft. WARNING: Keep your detergents in WARNING: If the salt indicator light cool, dry places out of reach of children. comes on during a program you need to See the detergent manufacturer’s wait until the end of the program to fill the instructions for further information.
Points to consider when using this type the dishwasher detergent and pour into the larger compartment 25 cm³ if your dishes of products: are heavily soiled or 15 cm³ if they are less soiled. You may have to add more •...
1) To fill the rinse aid compartment, open WARNING: Should any problem, which the rinse-aid compartment cap (Fig.A) you have not encountered before, arise with 2) Fill the compartment with rinse aid to the MAX level and then close the cap.Be use of this type of detergents, contact the careful not to overfill the rinse aid detergent manufacturers directly.
6. LOADING YOUR DISHWASHER which are appropriate for use in a dishwasher. Only with suitable dishes (mentioned in section 5) will you obtain If you properly place your dishes into the optimal washing results with a sensible use machine, you will be using it in the best way of energy.
6.1 Upper Rack 6.2. Lower Rack Load the upper rack with dessert plates, You can load into the lower basket such cups, glasses etc. round and deep items as pots with long handles, pot lids, plates, salad plates, cutlery sets. The lower rack should not be used for small items such as cups, wine glasses.
6.3. Incorrect Loads Bottom rack load patterns for 12 place settings. NOTE: Place all large and very dirty items in the lower rack. WARNING: Large knives and other utensils with sharp tips and edges must be placed horizontally into the upper rack due to risk of injury.
Page 22
Loading cutlery basket (Model Depending) 1: Salad Fork 2: Teaspoon 3: Dinner fork 4: Knife-solid handle 5: Serving spoon 6: Serving fork Cutlery Basket load pattern for 12 place settings . WARNING: Sharp cutlery may have shifted position during the wash operation and can be also wet and slippery.
Page 23
Top Basket Rack with height adjustment These racks are designed to increase the capacity of top basket. You can place your cups and glasses on these racks. Thanks to adjustable feature of the racks, you can place glasses of different sizes under the racks.
Page 24
Height Setting (Model Depending) 3. Place the rack into the tracks again at the desired height C. 1) Height setting - when basket is empty (model depending) In certain models, the height setting of the upper rack may be changed using the wheels which are present at two height levels.
Page 25
2) Height setting - when basket is filled Lower Basket Folding Racks (model depending) Folding racks consisting of four parts that The upper basket includes a mechanism are located on the lower basket of your which enables the height of the basket machine are designed in order to let you to be adjusted up (1) or down (2) without place big items easier such as pots, pans,...
Page 26
Upper Cutlery Basket Silverware Basket (Model Depending) (Model Depending) Silverware basket is designed to wash your The upper cutlery basket is designed for the dishes such as knife, fork, spoon, etc. in a placement of large and small cutlery and cleaner manner.
7. PROGRAMS AND OPTIONS TABLE Duration Programs Descriptions (min) Dirty Standard program for daily, regular or typical use to completely Regular wash a load of normally soiled dishes. Clean Dirty This program automatically adjusts the temperature and the quantity Auto of water, the energy consumption and the program duration.
Water Temperature 8.1. Keys Hot water is needed for best dishwashing and drying results. Water entering On/Off Key dishwasher should be at least 120°F (49°C) This key is used as On/Off key if the to give satisfactory results. corresponding button is held down for 3 To check water temperature entering seconds.
Page 29
8.3. Program Selection i. Auxiliary functions may cause changes in the program duration. ii. Auxiliary functions are not suitable for all 1. Press the On/Off key to turn on your washing programs. Indicator of the auxiliary machine. Note that the door of the dish- function that is not compatible with the washer is OPEN position.
Page 30
Half Load Option the machine resumes on for the duration of delay timer automatically. If the door of the It is used to operate the machine without machine is not closed within 4 seconds the loading it completely. delay timer will be paused. To resume the delay timer you should open the door again 1.
Page 31
8.11. End of Program machine by pressing Start/Pause key as soon as the door of the machine is opened. In other situation, the machine will stop “00” will be displayed when the washing automatically after 4 seconds when the programme is over. door of the machine is opened and any key is not pressed.
9. MAINTENANCE AND CLEANING 9.1 Filter a. Micro Filter b. Coarse Filter WARNING : Before cleaning or carrying c. Metal/Plastic out maintenance, switch off the appliance, disconnect the mains plug and turn off the water tap. Your dishwasher can only be repaired by an authorized service agent.
9.3. Cleaning The Impellers UPPER IMPELLER Check if the holes on the upper impeller Clean the impellers at least once a week in order for the machine operates efficiently. 1 are clogged. If they are clogged, remove LOWER IMPELLER and clean the impeller. Turn its nut to left to Check if the holes on the lower impeller (1 re-move the upper impeller (A, B) are clogged.
Page 34
WHAT SHOULD NOT BE WASHED IN YOUR DISHWASHER? • All items to be placed in the dishwasher should be dishwasher safe. • Plastics with “dishwasher safe” or equivalent label can only be used in dishwashers. Plastics may lose their shape or color. Check with manufacturer for recommendations. •...
10. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your dishwasher is not plugged in. Plug your dishwasher in. Switch your dishwasher on by pressing Your dishwasher is not switched on. the On/Off key. Fuse blown. Check your indoor fuses. The program does not start.
AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
