CONTENTS 1. IMPORTANT SAFETY INSTRUCTINS................3 2. RECYCLING........................6 3. INSTALLATION........................ 8 4. TECHNICAL SPECIFICATIONS..................9 4.1. General Appearance...................... 9 4.2.Technical Specifications....................9 5. BEFORE USING THE APPLIANCE................10 5.1. Preparing Your Dishwasher For First Use..............10 5.2. Setting the Water Softener.....................11 5.3. Filling the Dishwasher Salt Dispenser................13 5.4.
Page 4
Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
Page 5
INTRODUCTION Please read this user manual and particularly the safety instructions completely and carefully. They will save you time and effort and help to ensure optimum dishwasher performance. Be sure to observe all listed warnings and cautions. Look particularly for the icons with exclamation marks inside. The information icon will also provide important references.
1. IMPORTANT SAFETY INSTRUCTIONS WARNING: When using the dishwasher, follow basic precations. Read all instructions before using the dishwasher! Save these operating instructions and pass them on to any future user. • Use the dishwasher only for its intended purpose as described in this user manual.
Page 7
• The cup racks are designed to support cups, glasses and kitchen utensils. When the cup racks are in the dishwasher do not lean on or use the cup racks to support your body weight. • This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
Page 8
• Do not drink and play with the water in the appliance. Harmful residues could be present. • To reduce the risk of injury, do not allow children to play in or on a dishwasher. • When children become old enough to operate the appliance, it is the responsibility of the parents/legal guardians to ensure the children are instructed in safe practices by qualified persons.
• Do not store or use flammable liquids or vapors in the area of the dishwasher, near or on the appliance. • Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.
Page 10
WARNING!: Risk of injury or suffocation! Ensure that any plastic wrappings, bags, small pieces etc. are disposed of safely and kept out of the reach of children. SAVE THESE INSTRUCTIONS USA-CAN - 7...
3. INSTALLATION WARNING: When installing the dishwasher, follow basic precau-tions, including the following: Please check the standards and local codes for placement of machine. • Installation, maintenance and repair should be performed by a qualified installer. Work by unqualified persons could be danger-ous and may void the warranty.
4. TECHNICAL SPECIFICATIONS 4.2 Technical Specifications Load 8 place Capacity settings Permissible 43.5-145psi water (0.3 - 10 pressure bars) 120 V (volts), 12 Electrical A (amps), connection 60Hz (hertz) Total power 1400 (W) Heater power 1100 (W) NOTICE: Because we continually strive to improve our products, we may change our specifications and design without prior notice.
5.BEFORE USING THE 5.2. Setting the Water Softener ( Model Depending ) APPLIANCE Dishwasher needs soft water for good 5.1 Preparing Your Dishwasher For cleaning results. Hard water results in a First Use build-up of calcium deposits on dishware • Make sure the electricity and supply water and in the dishwasher.
Page 14
Test Strip ( For Models With Water Softener ) The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available).
Page 15
Water Hardness Table Level German °dH French °f British °E Indicator L1 is shown on the display. 6-11 10-20 7-14 L2 is shown on the display. 12-17 21-30 15-21 L3 is shown on the display. 18-22 31-40 22-28 L4 is shown on the display. 23-31 41-55 29-39...
5.3 Filling The Dishwasher Salt WARNING: Starting the machine with Dispenser ( Model Depending) any wash program is recommended after filling the salt container, in case of any spilled salt solutions. This prevents damage WARNING: Culinary and table salts to the machine. do not dissolve in water easily, using these NOTE: Fill the salt compartment with kind of salts will damage water softener...
5.5. Detergent Usage Should you need more information concerning the detergent you will use, contact detergent manufacturers directly. WARNING: Use a detergent specifically designed for use in Check that the detergent dispenser is domestic dishwashers. empty after the completion of each wash program You can find powder, gel,and tablet detergents in the market that have been...
• They produce good results for certain WARNING: Amounts may vary if you types of usage only. If you are using this use liquid or concentrated powder type of detergents, you need to contact the detergent. Tablet detergents should be manufacturers and find out about the placed in detergent container.
5.8.Rinse - aid Usage In order to change the rinse aid level, follow the below steps before turning on the machine Rinse-aid makes dishes sparkle and helps them to dry without spotting. Rinse-aid is In order to add rinse aid to the machine, required for stain-free utensils and clear glasses.
6. LOADING YOUR DISHWASHER which are appropriate for use in a dishwasher. Only with suitable dishes (mentioned in section 5) will you obtain If you properly place your dishes into the optimal washing results with a sensible use machine, you will be using it in the best way of energy.
6.1. Lower Rack Loading cutlery basket ( Model Depending ) You can load into the lower basket such round and deep items as pots with long handles, pot lids, plates, salad plates, cutlery sets. The lower rack should not be used for small items such as cups, wine glasses.
6.2. Alternative Basket Loads 6.3. Incorrect Loads USA-CAN - 19...
Page 23
Top Basket Rack with height adjustment These racks are designed to increase the capacity of top basket. You can place your cups and glasses on these racks. Thanks to adjustable feature of the racks, you can place glasses of different sizes under the racks.
Page 24
Height Setting ( Model Depending ) 3. Place the rack into the tracks again at the desired height C. 1) Height setting - when basket is empty ( model depending ) In certain models, the height setting of the upper rack may be changed using the wheels which are present at two height levels.
Page 25
2) Height setting - when basket is filled Lower Basket Folding Racks ( model depending ) Folding racks consisting of four parts that The upper basket includes a mechanism are located on the lower basket of your which enables the height of the basket machine are designed in order to let you to be adjusted up (1) or down (2) without place big items easier such as pots, pans,...
Page 26
Upper Cutlery Basket ( Model Depending ) The upper cutlery basket is designed for the placement of large and small cutlery and utensils. It is easily removed from the dishwasher, therefore allows ease of use when removing your items, along with the basket, after washing.
7. PROGRAMS AND OPTIONS TABLE Duration Programs Descriptions (min) Dirty Standard program for daily, regular or typical use to completely Regular wash a load of normally soiled dishes. Clean Dirty This program automatically adjusts the temperature and the quantity Auto of water, the energy consumption and the program duration.
8. OPERATING THE PRODUCT NOTE: The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. NOTE: The energy-usage label is based on the “Regular” program. This program is the most efficient in terms of its 1.
Delay Timer Key If the door stays open for more than 4 seconds, Start/Pause key must be pressed It should be pressed to make the time delay and the door of the diswasher must be settings. closed within 4 seconds after the Start/Pause key is pressed.
Page 30
Hi-Temp Options be pressed and the door of the dishwasher must be closed within 4 seconds. When this option is selected, both the water temperature and the washing time are increased. NOTE: The use of Delay Timer has a special case. Extra Dry Options The machine changes the water a.
Page 31
8.10. Rinse Aid Indicator i. Your machine performs water softening depends on model hardness level of the supply water (Model depending). Please check the rinse aid indicator Remaining time displayed towards the end on the control panel to see whether there in some programs can be different from the is adequate amount of rinse aid in the time indicated at the beginning due to this...
9. MAINTENANCE AND CLEANING Filter a. Micro Filter b. Coarse Filter WARNING : Before cleaning or carrying c. Metal/Plastic out maintenance, switch off the appliance, disconnect the mains plug and turn off the water tap. Your dishwasher can only be repaired by an authorized service agent.
Page 33
9.2. Cleaning The Impellers UPPER IMPELLER Check if the holes on the upper impeller Clean the impellers at least once a week in order for the machine operates efficiently. 1 are clogged. If they are clogged, remove LOWER IMPELLER and clean the impeller. Turn its nut to left to Check if the holes on the lower impeller (1 re-move the upper impeller (A, B) are clogged.
Page 34
WHAT SHOULD NOT BE WASHED IN YOUR DISHWASHER? • All items to be placed in the dishwasher should be dishwasher safe. • Plastics with “dishwasher safe” or equivalent label can only be used in dishwashers. Plastics may lose their shape or color. Check with manufacturer for recommendations. •...
10. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your dishwasher is not plugged in. Plug your dishwasher in. Switch your dishwasher on by pressing Your dishwasher is not switched on. the On/Off key. Fuse blown. Check your indoor fuses. The program does not start.
AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
