Foreword
TM
Congratulations on choosing a SUBARU vehicle equipped with EyeSight
.
EyeSight incorporates the latest driver assistance features available from
SUBARU, including such features as Adaptive Cruise Control, a Lead Vehicle Start
Alert and a Lane Departure and Lane Sway Warning, all of which are designed to
assist the driver in making decisions and increase driver comfort and
convenience. Initially, the operation and use of the various EyeSight features may
be unfamiliar to you. That is why we urge you to read this manual carefully before
using EyeSight. We also recommend that you first take the time to test EyeSight in
order to experience its features for yourself so that you can become familiar with
their operation.
Please keep in mind that it is the responsibility of drivers to operate their vehicles
safely at all times. Drivers should always remain alert and should never become
complacent while operating their vehicles because of the presence of EyeSight.
EyeSight is never a substitute for active driver involvement and it may not operate
optimally under all driving conditions.
This booklet is a supplement to the Owner's Manual for your SUBARU vehicle and
contains a detailed description of EyeSight. It should be read in conjunction with
your Owner's Manual so that you will gain a thorough understanding of the proper
operation of your vehicle.
The information, specifications and illustrations found in this booklet are those in
effect at the time of printing. SUBARU CORPORATION reserves the right to
change specifications and designs at any time without prior notice and without
incurring any obligation to make the same or similar changes on vehicles
previously sold.
Please keep this booklet together with your Owner's Manual and leave it in the
vehicle at the time of resale. The next owner will need the information it contains.
SUBARU CORPORATION, TOKYO, JAPAN
is a registered trademark of SUBARU CORPORATION.
© Copyright 2017 SUBARU CORPORATION

Advertisement

Table of Contents
loading

Related Manuals for Subaru Forester 2018

Summary of Contents for Subaru Forester 2018

  • Page 1 EyeSight is never a substitute for active driver involvement and it may not operate optimally under all driving conditions. This booklet is a supplement to the Owner’s Manual for your SUBARU vehicle and contains a detailed description of EyeSight. It should be read in conjunction with your Owner’s Manual so that you will gain a thorough understanding of the proper...

  • Page 2: Table Of Contents

    EyeSight About EyeSight ..............2 Pre-Collision Braking System........... 24 Adaptive Cruise Control ........... 36 Lane Keep Assist ............. 56 Pre-Collision Throttle Management........64 Lane Departure Warning..........70 Lane Sway Warning ............73 Lead Vehicle Start Alert ........... 76 Conventional Cruise Control ..........77 List of buzzer sounds ............

  • Page 3: About Eyesight

    Making use of images created by stereo camera specially designed by SUBARU, EyeSight detects the vehicle in front, obstacles, traffic lanes and other items. WARNING Drivers are responsible for driving safely.
  • Page 4 *2: If the brake system warning light does not turn off, immediately pull the vehicle over in a safe place and contact a SUBARU dealer to have the system inspected. For details, refer to the Owner’s Manual for your vehicle.
  • Page 5 About EyeSight CAUTION • The characteristics of the stereo camera are similar to those of human eyes. For this reason, conditions that make it difficult for the driver to see in the for- ward direction have the same effect on the stereo camera. They also make it difficult for the system to detect vehicles, obstacles and traffic lanes.
  • Page 6 34) and the Lane Departure Warning ⇒ refer to page 72), and stop using the Adaptive Cruise Control and Con- ventional Cruise Control. Contact a SUBARU dealer and have the system inspected. • When the Vehicle Dynamics Control warning light is illuminated, the Pre- Collision Braking System may not operate properly.
  • Page 7 - Data related to ABS, Vehicle Dynamics Control and Traction Control Function SUBARU and third parties contracted by SUBARU may acquire and use the recorded data for the purpose of vehicle research and development. SUBARU and third parties contracted by SUBARU will not disclose or provide the acquired data to any other third party except under the fol- lowing conditions.
  • Page 8 - Never touch the stereo camera lenses, and do not attempt to wipe or clean the lenses. Doing so could damage or soil the lens, and lead to improper system performance. If you ever touch a lens for any reason, be sure to contact a SUBARU dealer. Continued on next page ⇒...
  • Page 9 - Do not change the positions where the stereo camera is installed or modify any of the surrounding structures. • Do not install an interior rearview mirror other than a genuine SUBARU rearview mirror (such as a wide-type mirror) and the sun visor. Also, use the rearview mirror so that it does not obstruct the stereo camera.
  • Page 10 About EyeSight • Do not install any accessories other than the ones designated by SUBARU on the prohibited areas shown in the illustrations (grey zones). Even if some accessories are installed on the outside of the prohibited areas, abnormal operation of EyeSight may occur due to the reflection of the light or any objects.
  • Page 11 • Do not install any film or an additional layer of glass on the windshield. The system may not operate correctly. • If there are scratches or cracks on the windshield, contact a SUBARU dealer. • To have the windshield replaced or repaired, contact a SUBARU dealer.
  • Page 12 About EyeSight EyeSight Functions EyeSight includes the following functions. ■ Pre-Collision Braking System This function uses a following distance warning feature to warn the driver to take evasive action when there is the possibility of a collision with a vehicle or obstacle in front of you. If the driver does not take evasive action, the brakes are applied automatically to help reduce vehicle collision damage or, if possible, help prevent a collision.
  • Page 13 About EyeSight ■ Lead Vehicle Start Alert This function notifies the driver when the vehicle stopped in front starts moving but the driver’s vehicle remains stationary. ⇒ Refer to page 76. ■ Conventional Cruise Control In this mode, the system maintains a constant vehicle speed. It does not follow the vehicle in front.
  • Page 14 About EyeSight Instrument panel display layout (17) (16) (15) (14) km/h (12) (13) (11) (10) (22) (18) (19) (20) (21) S02678 * Display units can be changed in the Screen Settings. For details, refer to the Owner’s Manual for your vehicle. EyeSight display area (12) EyeSight temporary stop indicator (White)
  • Page 15 About EyeSight ■ CRUISE indicator • This indicator illuminates when the main cruise control is on. : Adaptive Cruise Control (Adaptive Cruise Control indicator) : Conventional Cruise Control (Conventional Cruise Control indicator) ⇒ Refer to pages 42 and 77. • When Adaptive Cruise Control is set and the vehicle detects a car in front, this indicator (white) turns green.
  • Page 16 About EyeSight ■ Set vehicle speed display Displays the set vehicle speed. ⇒ Refer to pages 42 and 79. ■ Lane Keep Assist indicator • This indicator illuminates when Lane Keep Assist is turned on by pressing the (Lane Keep Assist) switch. •...
  • Page 17 If the brake system warning light does not turn off, immediately pull the vehicle over in a safe place and contact a SUBARU dealer to have the system inspected. *Refer to the Owner’s Manual for details.
  • Page 18 About EyeSight ■ Vehicle Dynamics Control OFF indicator light • This indicator light illuminates when the ignition switch is turned to the “ON” position, and it turns off after approximately 2 seconds. • This indicator light illuminates when the Vehicle Dynamics Control OFF switch is pressed and Vehicle Dynamics Control is off.
  • Page 19 About EyeSight Switch layout (10) S02222 (Following distance setting) switch S#/I switch RES/+ switch (Lane Keep Assist) switch SET/- switch switch (CRUISE) switch (Info)/SET switch S/I switch (10) switch...
  • Page 20 About EyeSight ■ (CRUISE) switch • Switches cruise control on/off. • When the (CRUISE) switch is pressed, “ ” appears on the EyeSight display area in the combination meter display, and then appears by pressing and holding (following distance setting) switch for approximately 2 seconds. When “ ”...
  • Page 21 Selects the following characteristics linked with the SI-DRIVE (only when adaptive cruise control is set). * SI-DRIVE refers to SUBARU Intelligent Drive. • S/I switch - Switches between I (Intelligent mode) and S (Sports mode) every time it is pressed.
  • Page 22 About EyeSight ■ (Info)/SET switch This switch is used in the following situations. • When displaying the message that appeared in the warning screen area again. ⇒ Refer to page 95. • When changing the Warning Volume settings, etc. ⇒ Refer to page 93.
  • Page 23 About EyeSight ■ X-mode switch This turns the X-mode on/off. S02677...
  • Page 24 About EyeSight ■ Multi-function display Set vehicle speed display Lead vehicle indicator Lead vehicle distance indicator Your own vehicle indicator Your own vehicle speed indicator S02307 ● Your own vehicle speed indicator Indicates your own vehicle speed with a red indicator. ●...

  • Page 25: Pre-Collision Braking System

    Pre-Collision Braking System When there is the risk of a rear-end collision with an obstacle in front, the EyeSight system helps to prevent or minimize a collision by warning the driver. If the driver still does not take evasive action to avoid a collision, the brakes can be automatically applied just before the collision in order to reduce impact damage, or if possible, prevent the collision.
  • Page 26 Pre-Collision Braking System - When the detected object is something other than a vehicle, motorcycle, bicycle or pedestrian • A domestic animal or other animal (a dog or deer, etc.) • A guardrail, telephone pole, tree, fence or wall, etc. - Even if the obstacle is a motorcycle, bicycle or pedestrian, depending on the brightness of the surroundings as well as the relative movement, and aspect or angle of the object, there may be cases when the system can-...
  • Page 27 Pre-Collision Braking System ⇒ Continued from previous page • When the rear aspect of the vehicle in front is low, small or irregular (the system may recog- nize another part of the vehicle as its rear and will determine operation from that) - When there is an empty truck or trailer...
  • Page 28 *2: If the brake system warning light does not turn off, immediately pull the vehicle over in a safe place and contact a SUBARU dealer to have the system inspected. For details, refer to the Owner’s Manual for your vehicle.
  • Page 29 Pre-Collision Braking System CAUTION • In the following situations, turn off the Pre-Collision Braking System. Other- wise the Pre-Collision Braking System may activate unexpectedly. - When the vehicle is being towed - When loading the vehicle onto a carrier - When a chassis dynamometer, free-rollers or similar equipment is used - When a mechanic lifts up the vehicle, starts the engine and spins the wheels freely - When passing hanging banners, flags or branches, or when thick/tall...
  • Page 30 Pre-Collision Braking System - When the exhaust gas emitted by the vehicle in front is clearly visible in cold weather, etc. S00652 - When there is an obstacle on a curve or intersection - When narrowly passing vehicle or an object - When stopping very close to a wall or a vehicle in front - When passing through water...
  • Page 31 Pre-Collision Braking System NOTE Some unusual noises may be audible during automatic braking. This is caused by the braking control and is normal. ■ Detection of pedestrians EyeSight system also detect pedestrians. The EyeSight system detects pedestrians from their size, shape and movement.
  • Page 32 Pre-Collision Braking System Pre-Collision Braking System operation When there is an obstacle in front of you during driving, the system activates in the following sequence in order to warn the driver, activate braking control, and active the brake lights. Following Distance Warning: When the system determines that there is a risk of collision, a buzzer sounds repeated short beeps and the indicators on the combination meter display illuminate to warn the driver.
  • Page 33 Pre-Collision Braking System Obstacle Following distance First braking Secondary braking & warning & warning warning Possible collision area Highly possible Extremely highly possible collision area collision area Indication on the combination Warning Strength of Operating meter display buzzer type Automatic Braking system Following Repeated...
  • Page 34 Pre-Collision Braking System Pre-Collision Braking Assist operation When the Pre-Collision Braking System is activated (when the system determines that there is a high risk of collision with an obstacle in front), if the driver depresses the brake pedal, the system determines that this is emergency braking and activates braking assist automat- ically.
  • Page 35 Pre-Collision Braking System Turning off the Pre-Collision Braking System Press and hold the Pre-Collision Braking System OFF switch for approximately 2 seconds (or longer) to turn off the Pre-Collision Braking System (including Pre-Collision Brake Assist). When 1 short beep sound emits, this control is turned off and the Pre-Collision Braking System OFF indicator light on the instrument panel illuminates.
  • Page 36 Pre-Collision Braking System ■ Pre-Collision Braking System OFF indicator light This indicator light illuminates when the igni- tion switch is turned to the ON position, and remains illuminated for approximately 7 sec- onds after the engine starts. It turns on when the Pre-Collision Braking System is turned off.

  • Page 37: Adaptive Cruise Control

    *2: If the brake system warning light does not turn off, immediately pull the vehicle over in a safe place and contact a SUBARU dealer to have the system inspected. For details, refer to the Owner’s Manual for your vehicle.
  • Page 38 Adaptive Cruise Control • Adaptive Cruise Control is designed for use on expressways, freeways, toll roads, interstate highways and similar limited access roads. It is not intended to be used in city traffic. In the following conditions, do not use Adaptive Cruise Control.
  • Page 39 Adaptive Cruise Control ⇒ Continued from previous page S02636 - When the windshield has become fogged, scratched, or snow, dirt, dust or frost has adhered to it, or it is otherwise affected. - When water droplets from rain or the window washer, or dirt has not been fully wiped off the windshield It may not be possible to detect the vehicle in front, making correct control impossible.
  • Page 40 Adaptive Cruise Control Detection of the vehicle in front by the EyeSight stereo camera* • Under the following road conditions or conditions of your vehicle, detection of the vehicle in front may not be possible. Vehicles in neighboring traffic lanes or roadside objects may also be incorrectly detected. Under condi- tions such as these, do not use Adaptive Cruise Control.
  • Page 41 Adaptive Cruise Control ⇒ Continued from previous page - When the vehicle in front is not directly ahead of your vehicle and is shifted to one side S01977 - When there is an obstacle at the side of the road - When the relative speed difference compared to the vehicle in front is large...
  • Page 42 Adaptive Cruise Control CAUTION • After Adaptive Cruise Control has started, it maintains control continuously according to the behavior of the vehicle in front. When your vehicle comes to a stop because the vehicle in front has stopped, the automatic braking function will be canceled immediately after stopping and the vehicle will start creeping forward gradually (at the same time three short beeps and a single long beep will sound).
  • Page 43 Adaptive Cruise Control How to use Adaptive Cruise Control Adaptive Cruise Control is available when the engine is turned on. ■ Setting Adaptive Cruise Control (1) Setting Adaptive Cruise Control to standby status Press the (CRUISE) switch. At this time, “ ”...
  • Page 44 • If the (Adaptive Cruise Control indicator) does not illuminate, even when the (CRUISE) switch is pressed and this occurs frequently, there may be a malfunction in the system. Contact a SUBARU dealer and have the system inspected.
  • Page 45 Adaptive Cruise Control When a vehicle in front is detected, a buzzer sounds 1 short beep and the lead vehicle indicator will illuminate. (white) will turn green. The vehicle follows the lead vehicle in front Lead and maintains the selected following distance. vehicle At this time, the cruise speed is adjusted to indicator...
  • Page 46 Adaptive Cruise Control • If your vehicle no longer detects the vehicle in front The vehicle gradually accelerates back to the set target vehicle speed and will drive at that constant speed. If a vehicle in front is detected while accelerating to the set target vehicle speed, vehicle following will be started again.
  • Page 47 Adaptive Cruise Control ■ Increasing the set vehicle target speed ● Using the RES/SET switch While driving with Adaptive Cruise Control on, operate the RES/SET switch as follows. • Push to the “RES/+” side briefly. Every time the switch is pushed, the set vehicle target speed will increase to the next 5 MPH (5 km/h) increment.
  • Page 48 Adaptive Cruise Control ■ Decreasing the set vehicle target speed ● Using the RES/SET switch While driving with Adaptive Cruise Control on, operate the RES/SET switch as follows. • Push to the “SET/-” side briefly. Every time the switch is pushed, the set vehicle target speed will decrease in to the next 5 MPH (5 km/h) decrement.
  • Page 49 Adaptive Cruise Control ■ Decelerating temporarily Depress the brake pedal to decelerate tempo- rarily. When the brake pedal is depressed, Adaptive Cruise Control will be canceled. The will be turned off while the set vehicle tar- get speed remains displayed on the EyeSight display area.
  • Page 50 Adaptive Cruise Control ■ Changing the following distance from the vehicle in front The following distance from the vehicle in front setting can be changed in 3 stages. S02085 NOTE • The following distance changes corresponding with the vehicle speed. The faster the vehicle travels, the greater the following distance.
  • Page 51 Adaptive Cruise Control ■ Canceling Adaptive Cruise Control ● Canceling by driver operation Either of the following operations will cancel Adaptive Cruise Control. • Depress the brake pedal. will be turned off while the set vehicle target speed remains displayed on the EyeSight display area.
  • Page 52 Adaptive Cruise Control ● Automatic cancellation by the system When the vehicle stops because the lead vehicle stops, a buzzer will sound 3 short beeps and 1 long beep and Adaptive Cruise Control is automatically canceled. CAUTION The automatic braking function is released gradually after stopping and the vehicle starts creeping forward.
  • Page 53 If the Adaptive Cruise Control function cannot be set even after the condition has been corrected, EyeSight may be malfunctioning. This will not interfere with ordinary driving; however contact a SUBARU dealer and have the system inspected.
  • Page 54 Adaptive Cruise Control ■ Returning to a vehicle speed that was previously set The vehicle speed which was previously set is stored in memory.* To return to set that vehi- cle speed, press the RES/SET switch to the RES/+. ( on the EyeSight display area illu- minates again to indicate that the system has returned to the set status again.) SET indicator...
  • Page 55 Adaptive Cruise Control Other functions ■ “Obstacle Detected” warning The “Obstacle Detected” warning is activated while Adaptive Cruise Control is following a lead vehicle. This function warns the driver when it determines that the current level of deceleration by automatic braking control is insufficient. •...
  • Page 56 Adaptive Cruise Control CAUTION The automatic braking function is released gradually approximately 2 seconds after stopping and the vehicle starts creeping forward. Be sure to depress the brake pedal and stop the vehicle completely. NOTE • Vehicles in front in the same traffic lane are detected by the stereo camera within a distance of approximately 360 ft (110 m) in the forward direction.

  • Page 57: Lane Keep Assist

    - The wheels are out of alignment. - Flat tires that have been fixed temporarily with a tire repair kit. - The suspension has been modified (including genuine SUBARU parts). - Any object that obstructs the stereo camera’s view is installed on the...
  • Page 58 *2: If the brake system warning light does not turn off, immediately pull the vehi- cle over in a safe place and contact a SUBARU dealer to have the system inspected. For details, refer to the Owner’s Manual for your vehicle.
  • Page 59 Lane Keep Assist ⇒ Continued from previous page - Frozen roads, snow-covered roads or other slippery road surfaces The tires may spin, causing loss of control of the vehicle. - When entering a sharp curve into an interchange or junction, or a service area, parking area, toll booth or other facilities.
  • Page 60 - Immediately after the repair or replacement of the suspension or steering system - A winter tire or a tire other than a genuine SUBARU tire is used. - The vehicle is in a crosswind. - The road grade abruptly changes (uphill or downhill).
  • Page 61 Lane Keep Assist Lane Departure Prevention Function The system detects lane markings in order to help prevent departure from the lane. If you drive on expressways, freeways or interstate highways at speeds above approximately 37 MPH (60 km/h) and the vehicle is about to depart from the lane, the system assists the steering operation by turning it to the direction that will help prevent the lane departure.
  • Page 62 Lane Keep Assist Press the (Lane Keep Assist) switch once again to turn it off, and “ ” (Lane Keep Assist indicator) is turned off on the EyeSight display area. The Lane Departure Prevention Function goes into the standby status, and the lane indica- tor illuminates when all of the following conditions are met.
  • Page 63 Lane Keep Assist ■ Canceling Lane Departure Prevention Function ● Cancellation by the operation of a driver (In case no beep sounds) The following operation cancels Lane Departure Prevention Function. If the function is canceled, “ ” (Lane Keep Assist indicator) and the lane indicator are turned off on the EyeSight display area.
  • Page 64 Lane Keep Assist • When the system determines that the steering assistance is difficult to continue due to the road condition. • When the system determines that the steering assistance is difficult to operate due to another system. • When the EyeSight system is temporarily stopped. (“ ”...

  • Page 65: Pre-Collision Throttle Management

    Pre-Collision Throttle Management When an obstacle is detected in front of the vehicle, and the vehicle is stopped or traveling very slowly, if the system determines that the accelerator pedal has been depressed by more than the necessary amount (due to driver error), it greatly restricts engine output and ensures that vehicle forward movement is slower than normal in order to give the driver...
  • Page 66 Pre-Collision Throttle Management • If your vehicle is trapped on a railroad crossing and you are trying to escape by driving through the crossing gate, the stereo camera may rec- ognize the crossing gate as an obstacle and Pre-Collision Throttle Management system may activate.
  • Page 67 Pre-Collision Throttle Management ⇒ Continued from previous page • When there is a fence or wall, etc., with a uniform pattern (striped pattern, brick, etc.) or with no pat- tern in front • When there is a wall or door made of glass or a mirror in front •...
  • Page 68 Pre-Collision Throttle Management CAUTION • In the following situations, turn off Pre-Collision Throttle Management. Other- wise Pre-Collision Throttle Management may activate unexpectedly. - When the vehicle is being towed - When loading the vehicle onto a carrier - When a chassis dynamometer, free-rollers or similar equipment is used - When a mechanic lifts up the vehicle, starts the engine and allows the wheels to spin freely - When passing hanging banners, flags or branches, or when thick/tall...
  • Page 69 Pre-Collision Throttle Management ⇒ Continued from previous page - When there is an obstacle on a curve or intersection - When narrowly passing a vehicle or object - When stopping very close to a wall or a vehicle in front S01973 NOTE •...
  • Page 70 Pre-Collision Throttle Management Turning off Pre-Collision Throttle Management Press and hold the Pre-Collision Braking System OFF switch for approximately 2 seconds or longer to turn off the Pre-Collision Throttle Management System. When 1 short beep sound emits, this function is turned off and the Pre-Collision Braking System OFF indicator light on the instrument panel illuminates.

  • Page 71: Lane Departure Warning

    Lane Departure Warning When vehicle speed is approximately 30 MPH (50 km/h) or more, this function warns the driver if the system detects that the vehicle is likely to depart the traffic lane. When Lane Departure Warning activates, a buzzer sounds 6 short beeps, and the steering wheel indicator and right/left lane indicator on the combination meter display all flash at the same time.
  • Page 72 Lane Departure Warning CAUTION In the following situations, the Lane Departure Warning may not activate: • Vehicle speed is approximately 30 MPH (50 km/h) or less. • When the steering wheel is turned significantly to either side • When the vehicle is driving around a curve whose radius is 0.18 miles (300 m) or smaller.
  • Page 73 Lane Departure Warning Turning off Lane Departure Warning Press and hold the Lane Departure Warning OFF switch for approximately 2 seconds or longer to turn off the Lane Departure Warning. When 1 short beep sound emits, this function is turned off and the Lane Departure Warning OFF indicator light on the instrument panel will illuminate.

  • Page 74: Lane Sway Warning

    Lane Sway Warning Lane Sway Warning This function detects swaying or drifting within a lane, and warns the driver. When the Lane Sway Warning activates, a buzzer sounds 6 short beeps, the steering wheel indicator light blinks and the lane indicator lights on the combination meter display blink alternately left and right.
  • Page 75 Lane Sway Warning NOTE • Swaying detection is based on several minutes of prior driving data. Sway- ing will not be detected immediately after the vehicle starts to sway. In addition, the warning may continue for some time even after swaying stops.
  • Page 76 Lane Sway Warning Turning off Lane Sway Warning Press and hold the Lane Departure Warning OFF switch for approximately 2 seconds or longer to turn off the Lane Sway Warning. When 1 short beep sound emits, this function is turned off and the Lane Departure Warning OFF indicator light on the instrument panel illu- minates.

  • Page 77: Lead Vehicle Start Alert

    Lead Vehicle Start Alert When the vehicle stopped in front starts to move, the Lead Vehicle Start Alert notifies the driver by indicator on the combination meter display and buzzer. When the vehicle in front remains stopped continuously (within a following distance of approximately 32 ft (10 m) and the driver’s vehicle remains stopped for several seconds or longer), the system continues to detect the vehicle in front and this alarm activates if the vehicle in front advances approxi- mately 10 ft (3 m) or more while the driver’s vehicle remains stationary.

  • Page 78: Conventional Cruise Control

    Conventional Cruise Control Conventional Cruise Control About Conventional Cruise Control Conventional Cruise Control is a driving support system intended to allow more comfortable driving on expressways, freeways and interstate highways. It can be used to travel at a con- stant speed by maintaining the vehicle speed set by the driver. Please remember that you should not exceed posted speed limits.
  • Page 79 Conventional Cruise Control NOTE • When the (CRUISE) switch is first turned on, the Adaptive Cruise Control is set. • To change the Cruise Control mode, press and hold the (following distance setting) switch for approximately 2 seconds or longer. (This is effective only when the main Cruise Control is on and neither Adaptive Cruise Control nor Conventional Cruise Control are set.) •...
  • Page 80 Conventional Cruise Control How to use the Conventional Cruise Control Conventional Cruise Control can be set when the following conditions are met. - The select lever is in the position and the paddle shift is not operated. - The brake pedal is released. - The vehicle speed is between approximately 25 MPH (40 km/h) and 90 MPH (145 km/h).
  • Page 81 Conventional Cruise Control (2) Switch to Conventional Cruise Control. Press and hold the (following distance setting) switch for approximately 2 seconds or longer to switch from Adaptive Cruise Control to Conventional Cruise Control. A buzzer sounds 1 short beep. At this time, the following distance setting indicator on the EyeSight display area of the combination meter display turns off and (Conventional Cruise Control) is displayed.
  • Page 82 Conventional Cruise Control (4) When the vehicle speed is between approximately 25 MPH (40 km/h) and 90 MPH (145 km/h), press the RES/SET switch to the “SET/-”. The vehicle speed at the time when the switch is pressed will become the set vehicle speed, and constant speed driving will initiate.
  • Page 83 Conventional Cruise Control ■ Increasing the set vehicle speed The following two methods can be used to increase the set vehicle speed. ● Using the RES/SET switch • Pressing to the “RES/+” side briefly Every time you press the “RES/+” side, the set vehicle speed will increase to the next 5 MPH (5 km/h) increment.
  • Page 84 Conventional Cruise Control ■ Decreasing the set vehicle speed ● Using the RES/SET switch • Pressing to the “SET/-” side briefly Every time you press the “SET/-” side, the set vehicle speed decreases to the next 5 MPH (5 km/h) decrement. •...
  • Page 85 Conventional Cruise Control ■ Decelerating temporarily Depress the brake pedal to decelerate tempo- rarily. When the brake pedal is depressed, Conventional Cruise Control will be canceled. While the set vehicle target speed remains displayed on the EyeSight display area, will be turned off. Release the brake pedal and press the RES/SET switch for “RES/+”...
  • Page 86 Conventional Cruise Control ● Automatic cancellation by the system In the following cases, a buzzer sounds a single long beep and the Cruise control function is automatically canceled ( is displayed on the EyeSight display area.). After the condi- tions listed below have been resolved, perform the cruise control set operation again to reactivate cruise control.
  • Page 87 If cruise control cannot be set even after the condition has been corrected, EyeSight may be malfunctioning. This will not interfere with ordinary driving; however the system should be inspected by a SUBARU dealer as soon as possible.
  • Page 88 Conventional Cruise Control ■ Resuming a vehicle speed that was previously stored A vehicle speed that has been previously set is stored in memory . To recall and set that vehicle speed, press the RES/SET switch to the “RES/+”. (The EyeSight display area shows the set condition again.) Resume is possible when a vehicle speed was previously set, and the current vehicle speed is approximately 20 MPH (30 km/h) or more.

  • Page 89: List Of Buzzer Sounds

    List of buzzer sounds Buzzer sound Status Reference page ⇒ Single continuous Pre-Collision Braking System: Refer to page 31. beep Secondary Braking is active. Adaptive Cruise Control or Conventional Cruise ⇒ Refer to pages Single long beep Control is canceled. 51 and 85.
  • Page 90 List of buzzer sounds Buzzer sound Status Reference page ⇒ Either of the following occurred while Adaptive Refer to page 44. Cruise Control was set. - A vehicle in front is detected - A vehicle in front is no longer detected ⇒...

  • Page 91: Eyesight Malfunction And Temporary Stop

    If both the EyeSight warning indicator and the CHECK ENGINE warning light/malfunction indicator light illuminate at the same time while driving, have your vehicle checked/repaired by a SUBARU dealer as soon as possible. EyeSight cannot be used if there is an abnormality with the engine, etc.
  • Page 92 The system will restart once the temperature is within the operational range of the EyeSight system. If the system does not restart, even when the S00701 temperature inside the vehicle is within the operational range, contact your SUBARU dealer for an inspection.
  • Page 93 3 times after the elapsed, contact your engine was started. SUBARU dealer for an • The engine has stopped. inspection. • The electronic power steering system is in the overheating prevention...

  • Page 94: Customizing Functions

    Customizing functions Customizing functions The following settings can be changed on the combination meter display. Item Setting Default setting Warning Volume Max/Mid/Min EyeSight Lead Vehicle Acquisition Sound ON/OFF Lead Vehicle Moving Monitor Function ON/OFF NOTE The following settings can be restored to the factory (default) settings. ⇒...
  • Page 95 Customizing functions ● Warning Volume setting The volume can be set to Max/Mid/Min. When on the Warning Volume settings screen, if the volume is selected with the switch, 3 short beeps will sound. ● Lead Vehicle Acquisition Sound setting The Lead Vehicle Acquisition Sound setting can be activated (ON) or deactivated (OFF). ●...

  • Page 96: Message Screen List

    Message screen list Message screen list If an EyeSight warning or malfunction is detected, a message will be displayed on the combination meter display. Depending on the message, a buzzer will sound at the same time. Normal indicator Message indicator Normal indicator EyeSight Off Check Manual...
  • Page 97 Message screen list ■ Message screen list (precautions and notices) Item Displayed screen mark Action Pre-Collision Braking ⇒ None Refer to page 31. System The “Obstacle Detected” ⇒ None Refer to page 54. warning S00695 Pre-Collision Throttle ⇒ None Refer to page 64. Management ⇒...
  • Page 98 Message screen list ■ Message screen list (malfunction, temporary stop) Item Displayed screen mark Action EyeSight System ⇒ Refer to page 90. Malfunction (yellow) S00699 ⇒ Refer to page 91. (white) S00700 EyeSight system ⇒ Refer to page 91. temporary stop (white) S00701 ⇒...

  • Page 99: Troubleshooting

    Troubleshooting Adaptive Cruise Control cannot be set. Did you remember to press the (CRUISE) switch? If you have not pressed the (CRUISE) switch, (Adaptive Cruise Control) will not be shown. Is EyeSight operation temporarily stopped? When EyeSight is temporarily stopped, is displayed on the combination meter display.
  • Page 100 Troubleshooting A vehicle (in front of your vehicle) is not detected, detection is delayed or detec- tion is lost quickly. Is the vehicle in front stopped, moving slowly relative to your vehicle or moving extremely slowly? Detection of stopped vehicles, vehicle moving slowly relative to your vehicle, and vehicles moving extremely slowly may be difficult.
  • Page 101 Troubleshooting EyeSight does not restart after a temporary stop. Is the X-mode turned on? EyeSight cannot be activated when the X-mode is turned on. Are you parking in an extremely hot or cold condition? In either of these cases, EyeSight may temporarily stop operating until the temperature increases or decreases to a temperature at which the camera is operable.
  • Page 102 Troubleshooting Cruise control is canceled automatically. Did you perform one of the following operations? • Manually depressing the brake pedal • Pressing the (CRUISE) switch - If the (CRUISE) switch is pressed while the cruise control is set, the cruise control will be canceled. •...
  • Page 103 Troubleshooting Lane Keep Assist was unexpectedly canceled. Did you take your hands off the steering wheel? Did you just lightly put your hands on the steering wheel while driving? If the system cannot detect the steering operation of the driver, it will temporarily cancel Lane Keep Assist.
