Subaru Forester 2.5X Specification Sheet

Exterior
Satin White Pearl Spark Silver Metallic Steel Silver Metallic
Paprika Red Pearl Camellia Red Pearl Dark Gray Metallic
Upholstery
Aurora Platinum Cloth (APC) Aurora Black Cloth (ABC) Platinum Dune Cloth (PDC)
Black Dune Cloth (BDC) Platinum Leather (PL) Black Leather (BL)
Forester Color Combinations
2.5X and 2.5X Premium
PAINT
Satin White Pearl
APC
Spark Silver Metallic ABC
Steel Silver Metallic APC
Sage Green Metallic
APC
Newport Blue Pearl
APC
Paprika Red Pearl
ABC
Camellia Red Pearl APC
Dark Gray Metallic APC
Obsidian Black Pearl ABC
Paint
Sage Green Metallic Newport Blue Pearl
Obsidian Black Pearl
2.5X Limited
2.5XT Premium and 2.5XT Limited
PDC PL
BDC BL
PDC PL
PDC PL
PDC PL
BDC BL
PDC PL
PDC PL
BDC BL
Forester ® Specifications
ENGINE AND DRIVETRAIN 2.5X, 2.5X Premium and 2.5X Limited
2.5-liter SOHC aluminum-alloy 16-valve horizontally opposed
Engine
SUBARU BOXER ® engine with i-Active Valve Lift System.
Power 170 hp @ 6,000 rpm
Torque 170 lb-ft @ 4,400 rpm
Fully synchronized 5-speed manual with Incline Start Assist.
Manual transmission
2.5X and 2.5X Premium: Standard. 2.5X Limited, 2.5XT Premium and 2.5XT Limited: Not available.
4-speed electronic direct-control automatic with SPORTSHIFT
Automatic transmission
2.5X and 2.5X Premium: Optional. 2.5X Limited, 2.5XT Premium and 2.5XT Limited: Standard.
CA Emissions SULEV (PZEV) and LEV2
Towing capacity 2,400 lbs
FUEL
Fuel economy (city/highway) 2 20/26 mpg
Fuel requirement Unleaded gasoline (87 octane)
SYMMETRICAL AWD
Models equipped with 5-speed manual transmission utilize a viscous-type locking center differential with torque distribution normally
Continuous All-Wheel Drive configured at a 50/50-split front-to-rear. If wheel speed differs between front and rear axles, the system helps distribute power to the
wheels with the most traction.
Models equipped with 4-speed automatic transmission utilize an electronically controlled variable transfer clutch to distribute power to
Active All-Wheel Drive where traction is needed. Sensors monitor parameters such as wheel slippage, throttle position and braking, to help determine torque
distribution and direct it to the wheels with optimum traction.
STABILITY AND TRACTION
Standard VDC electronic stability control utilizes sensors which constantly monitor wheel speeds, steering angle, brake pressure, vehicle
Vehicle Dynamics Control (VDC) yaw rate and lateral g-forces. If VDC detects a difference between the driver's intended path and the one the vehicle is actually taking,
VDC applies braking power and/or reduces engine torque to help correct vehicle path.
VDC also incorporates an all-wheel, all-speed traction control system which senses a loss of traction and applies braking force to the
Traction Control System (TCS)
slipping wheel or wheels as necessary to maintain vehicle motion.
CHASSIS
Steering Engine-speed-sensing variable power-assisted rack-and-pinion. Turning circle: 34.4 feet.
Suspension 4-wheel independent suspension. Front: Strut-type with lower L-arm. Stabilizer bar. Rear: Double wishbone. Stabilizer bar.
Brakes 4-wheel disc, ventilated front. 4-channel, 4-sensor ABS with Electronic Brake-force Distribution (EBD).
Brake Assist When emergency braking is detected by how quickly the brake pedal is pressed, maximum brake pressure is immediately applied.
WHEELS AND TIRES
2.5X: 16 x 6.5-inch steel with wheel covers
Wheels 2.5X Premium and 2.5X Limited: 17 x 7.0-inch
5-spoke aluminum alloy
2.5X: 215/65 R16 96H all-season
Tires
2.5X Premium and 2.5X Limited: 225/55 R17 95H all-season
EXTERIOR DIMENSIONS
Length 179.5 inches
Width 70.1 inches
Height 66.9 inches with roof rails (65.9 inches without roof rails)
Wheelbase 103.0 inches
Track (front/rear) 60.2 inches/60.2 inches
2.5X: 3,250 lbs/3,300 lbs I 2.5X Premium: 3,300 lbs/3,340 lbs
Base curb weight (manual/automatic)
2.5X Limited: /3,360 lbs
N/A
Ground clearance (at base curb weight) 8.7 inches
INTERIOR DIMENSIONS
Headroom (front/rear) 41.6 inches/40.4 inches (with moonroof: 40.0 inches/37.7 inches)
Legroom (front/rear) 43.1 inches/38.0 inches
Shoulder room (front/rear) 56.1 inches/55.6 inches
Passenger volume 107.6 cubic feet (with moonroof: 102.1 cubic feet)
Cargo volume 33.5 cubic feet (with moonroof: 30.8 cubic feet)
Maximum cargo volume 68.3 cubic feet with rear seat lowered (with moonroof: 63.0 cubic feet)
2.5XT Premium and 2.5XT Limited
2.5-liter DOHC intercooled, turbocharged aluminum-alloy 16-valve
4-cylinder horizontally opposed SUBARU BOXER engine with Active
Valve Control System.
224 hp @ 5,200 rpm
226 lb-ft @ 2,800 rpm
® manual control.
19/24 mpg
Premium unleaded gasoline (91 octane)
17 x 7.0-inch 5-spoke aluminum alloy
225/55 R17 95H all-season
179.5 inches
70.1 inches
66.9 inches with roof rails
103.0 inches
60.2 inches/60.2 inches
2.5XT Premium: N/A /3,440 lbs I 2.5XT Limited: N/A /3,460 lbs
8.9 inches
40.0 inches/37.7 inches
43.1 inches/38.0 inches
56.1 inches/55.6 inches
102.1 cubic feet
30.8 cubic feet
63.0 cubic feet with rear seat lowered
