Unit Illustration
Display
Blood Pressure
Bluetooth Indicator
Indicator
AM
Bluetooth
Time/Date
PM
BP OK
Group1
1
Group2 AVG
2
Last 3 Tests
Average
No.
Irregular Heartbeat Indicator
Pulse Rate
Heart Rate Indicator
Contents
1.Monitor Unit
3.Arm Cuff

Quick Start

1. Install batteries . (See Figure A )
2. Insert cuff air plug into the behind side of monitor unit. (See Figure B)
Figure A
3. Remove thick clothing from the arm area.
4. Rest for several minutes prior to testing. Sit down in a quietplace comfortably ,
back and arm support on a desk or table ,withyour legs uncrossed ,your arm
resting on a firm and your feet flat on the floor. (See Figure C )
Figure C
5. Apply cuff to your left arm and middle of the cuff at the level of your heart. Bottom
of cuff should be placed approximately 1-2cm (1/2'') above elbow joint. (See Figures D&E)
Figure D
6. Press " START/STOP " Button to start testing.
Arm Shake Indicator
Cuff Loose Indicator
Low Battery Indicator
SMART
SYS
Systolic
Blood
Pressure
mmHg kPa
IHB
Diastolic
Blood
Pressure
WHO Blood Pressure
Classification Indicator
Owner's Manual
Arm-type Fully Automatic
Digital Blood Pressure Monitor
DBP-6275B
Model
Arm Type
2.Owner's Manual
4.Storage Bag
5.2MOPPMedical AC Adapter(DC5.0 V,1000mA)
(recommended, not provided)
Figure B
Figure E

Important Testing Guidelines

7
1. Avoid eating, exercising, and bathing for 30 minutes prior to testing.
2. Sit in a calm environment for at least 5 minutes prior to testing.
3 . Do not stand while testing. Sit in a relaxed position while keeping your arm level with
your heart.
4. Avoid speaking or moving body parts while testing.
5. While testing, avoid strong electromagnetic interference such as microwave ovens and
cell phones.
6 . Wait 3 minutes or longer before re-testing.
7 . Try to measure your blood pressure at the same time each day for consistency.
8 . Test comparisons should only be made when monitor is used on the same arm, in the
same position, and at the same time of day.
9. This blood pressure monitor is not recommended for people with severe arrhythmia.
10. Do not use this blood pressure monitor if the device is damaged.
Any blood pressure recording can be affected by the following factors:
1. The position of the subject, his or her physiologic condition;
2. The performance and accuracy of the device;
3. Cuff size: too small cuff (bladder) will produce a higher blood pressure value than usual,
too big cuff (bladder) will produce a lower blood pressure value;
4. Measuring position does not keep level with your heart;
5. Speaking or moving body parts while testing;
6. Not relaxing for about 5 minutes before taking the measurement.
9

Unit Operation

Battery Installation

Slide battery cover off as indicated by arrow.
Install 4 new AA alkaline batteries according to polarity.
Close battery cover.
AC Adapter jack is on the back side of the monitor. Medical AC adapter(DC 5.0 V,1000mA)
can be used with the device (recommended, not provided). The adapter connect pin should
be positive inside and negtive outside with a 2.1mm coaxial joint.
Do not use any other type of AC adaptor as it may harm the unit.
USB Adapter Jack
Note:Power supply is specified as part of ME EQUIPMENT.
