Important Testing Guidelines; Quick Start - JOYTECH DBP-6282L Owner's Manual

Unit Illustration
Contents
1.Monitor Unit
3.Arm Cuff

Quick Start

1. Install batteries . (See Figure A )
2. Insert cuff air plug into the left side of monitor unit. (See Figure B)
Figure A
3. Remove thick clothing from the arm area.
4. Rest for several minutes prior to testing. Sit down in a quiet place, preferably at a desk
or table, with your arm resting on a firm surface and your feet flat on the floor.
(See Figure C )
Figure C
5. Apply cuff to your left arm and keep level with your heart. Bottom of cuff should be
placed approximately 1-2cm (0.4-0.8'') above elbow joint. (See Figures D&E)
Figure D
6. Press " START/STOP " Button to start testing.
Battery Indicator
Irregular Heartbeat Indicator
Owner's Manual
Arm-type Fully Automatic
Digital Blood Pressure Monitor
DBP-6282L
Model
Arm Type
4.Storage Case
2.Owner's Manual
5.2MOPPMedical AC Adapter(DC5.0 V,1000mA)
(recommended, not provided)
Figure B
Figure E

Important Testing Guidelines

7
1. Avoid eating, exercising, and bathing for 30 minutes prior to testing.
2. Sit in a calm environment for at least 5 minutes prior to testing.
3 . Do not stand while testing. Sit in a relaxed position while keeping your arm level with
your heart.
4. Avoid speaking or moving body parts while testing.
5. While testing, avoid strong electromagnetic interference such as microwave ovens and
cell phones.
6 . Wait 3 minutes or longer before re-testing.
7 . Try to measure your blood pressure at the same time each day for consistency.
8 . Test comparisons should only be made when monitor is used on the same arm, in the
same position, and at the same time of day.
9. This blood pressure monitor is not recommended for people with severe arrhythmia.
10. Do not use this blood pressure monitor if the device is damaged.
Any blood pressure recording can be affected by the following factors:
1. The position of the subject, his or her physiologic condition;
2. The performance and accuracy of the device;
3. Cuff size: too small cuff (bladder) will produce a higher blood pressure value than usual,
too big cuff (bladder) will produce a lower blood pressure value;
4. Measuring position does not keep level with your heart;
5. Speaking or moving body parts while testing;
6. Not relaxing for about 5 minutes before taking the measurement.
9
Lithium Battery Charging
The device has a built-in lithium battery that must be recharged using a specific power adapter.
When low battery indicator icon "
charge. When charging, the screen will be displayed in a cycle from "
Insert the adapter connector into the adapter interface, then insert the adapter into the socket, and
then connect the adapter to the cable endInsert the adapter interface on the device and press the
on/off button to measure normally. (if this model has been packed)When you plug in the adapter,
the screen power display changes, indicating that you are using the adapter for power.
Adapter interface
Adapter connector end
AC Adapter jack is on the back side of the monitor. Medical AC adapter(DC 5.0 V,1000mA)
can be used with the device (Optional,If users want to purchase other adapters, they need to meet the
requirements of IEC 60601-1).
Do not use any other type of AC adapter as it may harm the unit.
USB Adapter Jack
Note:Power supply is specified as part of ME EQUIPMENT. Note:Power supply is specified as part of ME EQUIPMENT.
"appears on the screen Please connect the power adapter to
" to"
The adapter connects
to the cable head
8
