Summary of Contents for Grundig GNV4P5A0WC
- Page 1 Dishwasher User’s Manual GNV4P5A0WC 150 0064 0100_GRUNDIG_E9_EN/ 02-02-22.(15:54)
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
CONTENTS 1 INSTRUCTIONS FOR SAFETY Lower basket multipurpose / height adjustable service rack ..... 23 AND ENVIRONMENT Lower basket bottle wire ....24 General safety ........4 Upper basket height adjustable rack 24 Intended use ..........4 Upper basket multipurpose service Children’s safety ........5 rack ............ -
Page 4: Instructions For Safety And Environment
instructions for safety and environment This section contains safety Never touch the plug with • instructions that will help to get wet hands! Never unplug by protected from risk of personal pulling on the cable, always injury or property damage. Failure pull out by grabbing the plug. -
Page 5: Children's Safety
instructions for safety and environment Children’s safety This appliance is intended • to be used in household and Electrical products are • similar applications such as: dangerous for the children. - Staff kitchen areas in shops, Keep children away from the offices and other working product when it is in use. -
Page 6: Compliance With Weee Directive And Disposing Of The Waste Product
instructions for safety and environment Package information 1. Unplug the product before transporting it. Packaging materials of the 2. Remove water drainage and product are manufactured from water supply connections. recyclable materials in accordance with our National Environment 3. Drain the remaining water in Regulations. -
Page 7: Dishwasher Overview
Dishwasher Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Silverware basket (depends on model) 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid 12. Upper basket rail 13. -
Page 8: Fan Drying System
Dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see rating label) -
Page 9: Installation
Installation Appropriate installation Refer to the nearest Authorised Service Agent for installation of your product. To location make the product ready for use, make sure Place the product on a solid and flat • that the electricity, tap water supply and floor that has sufficient load carrying water drainage systems are appropriate capacity! The product must be installed... -
Page 10: Connection To The Drain
Installation Permitted water temperature: drainage. The length of this connection must up to 25°C ( 60°C for products be min. 50 cm and max. 100 cm from the equipped with WaterProtect+; floor. A discharge hose longer than 4 meters please refer toWaterProtect+ causes dirty washing. -
Page 11: Waterprotect
Installation WaterProtect+ The voltage and allowed fuse or • breaker protection are specified in the (depends on model) “Technical specifications” section. If the The WaterProtect+ system protects against current value of the fuse or breaker in water leaks that may occur at the hose the house is less than 16 Amps, have inlet.Water contact with the valve box of a qualified electrician install a 16 Amp... -
Page 12: Preparation Tips For Energy Saving
Preparation Tips for energy saving Adjusting the water softening system Following information will help you use the product in an ecological and energy-efficient Cleaning, rinsing and drying performance of manner. your dishwasher will increase when water Wipe away any coarse food remnants on the softening system is adjusted properly. - Page 13 Preparation Remove the test Turn on the tap and Hold the test strip in Remove the test Wait for 1 minute. The test strip shows strip from the let the water run for the water for about strip from the water you the hardness packet.
-
Page 14: Adding Salt
Preparation If the hardness level of the supply water Salt reservoir will be filled with is above 90 °dF or if you are using well water when you start the water, then it is recommended to use water product. For this reason, add salt purification devices and special filters. -
Page 15: Detergent
Preparation Put the detergent into the detergent You need to add salt right before dispenser just before operating the machine starting the machine. Thus, the as illustrated below. overflowing salty water will be Push the latch to right to open the flushed immediately, preventing detergent dispenser lid (A). -
Page 16: Tablet Detergents
Preparation show their effects up to a certain water 3. Push the lid of the detergent dispenser hardness level (21°dH). Water softening salt to close it. A “click” will be heard when and rinse aid must also be used together the lid is closed. -
Page 17: Rinse Aid
Preparation Rinse aid 4. If there are stains on tableware items after washing, level must be increased The rinse aid used in and if there is a blue trace after wiping dishwashers is a special them by hand, it must be decreased. combination that aims to This is set to position 3 as factory increase drying efficiency and... -
Page 18: Placing The Dishes Into The Dishwasher
Preparation Placing the dishes into the dishwasher You can use your dishwasher in the optimum way with respect to energy consumption and washing and drying performance only if you place the dishes in an orderly way. Wipe away any coarse food remnants •... - Page 19 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware Dishwasher / User’s Manual 19 / 47 EN...
-
Page 20: Cutlery Basket
Preparation Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash your Cutlery basket is designed to wash your dishes such as knife, fork, spoon, etc. in an dishes such as knife, fork, spoon, etc. in an efficient manner. -
Page 21: Collapsible Lower Basket Tines
Preparation Collapsible lower basket Bringing the tines to the tines horizontal position by holding them from the tips may cause (depends on model) them to bend. Therefore, it will There are foldable tines (A) located at the be appropriate to bring the tines in the middle to horizontal or lower basket of the machine are designed vertical position by holding them... -
Page 22: Tray Wash Supports
Preparation SoftTouch Accessory (depends on model) The SoftTouch Accessory found in the lower basket of your machine enables a safe washing for your fragile glasses. Bringing the tines to the horizontal position by holding them from the tips may cause them to bend. -
Page 23: Lower Basket Multipurpose / Height Adjustable Service Rack
Preparation Lower basket multipurpose Make sure that the impeller does / height adjustable service not touch the dishes you placed rack on the racks. (depends on model) To close the racks: This accessory located at the lower basket Fold the rack (A). of your machine allows you to easily wash 2. -
Page 24: Lower Basket Bottle Wire
Preparation Lower basket bottle wire Upper basket multipurpose service rack (depends on model) The bottle wire is designed for easier (depends on model) washing of long pieces with wide mouths. This accessory located at the upper basket You may take out the bottle wire from the of your machine allows you to easily wash basket when not in use by pulling it out from pieces such as extra long ladles and bread... -
Page 25: Adjusting The Height Of The Upper Basket
Preparation Adjusting the height of the To lower the basket, while it is in the uppermost position; upper basket Hold the upper basket wires with both (depends on model) hands, slightly lift up the basket and The upper basket height adjustment simultaneously push and release the mechanism has been designed for you to latches shown in the figure (B). -
Page 26: Adjusting The Height Of The Upper Basket
Preparation Adjusting the height of the To raise the basket, hold the wires of the basket and pull the basket upwards with upper basket both hands while the basket is at the (depends on model) lowermost position (B) Upper basket height adjustment mechanism 2. -
Page 27: Upper Basket Multi-Function Service Rack
Preparation Upper basket multi-function Tray Washing Support service rack (depends on model) You may use the tray washing supports (depends on model) if you want to wash a tray on your lower Thanks to the upper basket multi-function basket. service rack on the upper basket of your Refer to the Additional Functions section to appliance, you may load and wash long service- select the proper program and function. -
Page 28: Collapsible Upper Basket Wires
Preparation Collapsible upper basket Height setting with empty wires basket (depends on model) (depends on model) You can use collapsible wires when you need In this model, the height setting of the upper a larger space for your dishes in the upper basket may be changed using the wheels basket of your machine. -
Page 29: Ceiling Cutlery Basket
Preparation Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc. -
Page 30: Operating The Product
Operating the product On / Off Key 7. Function Selection Keys 2. Menu Key Hygiene Care function 3. Time Delay Selection Steam Shine Function TrayMaster Function / Menu Direction Selection Keys Express Function 4. Selection / Confirmation Key 5. Display 6. - Page 31 Operating the product Dishwasher / User’s Manual 31 / 47 EN...
-
Page 32: Programme Selection / Programme Cancel Key
Operating the product On/Off Key Programme selection When you press the On/Off key, the indicator Press the On/Off button to turn on your lights illuminate on the display for ON machine. position. The lights turn off in OFF position. 2. Check the Salt and Rinse Aid indicators and add salt and/or rinse aid if needed. - Page 33 Operating the product Floor illumination Steam Shine Function Warning to show that machine is It provides superior drying performance. in washing phase TrayMaster Function (depends on the model) Select Intensive 70°C programme and press Your machine reflects a light to the floor function key to run this function.
- Page 34 Operating the product Functions in Settings Menu Active Self Cleaning Function Off/On (depends on the model) Under the settings menu of your product, there are some additional functions that depend on the model. To access these functions, press and hold the Menu key for 3 seconds.
-
Page 35: Scheduling The Washing Time
Operating the product Scheduling the washing process complete. Draining is completed in 2 minutes and the machine gives an audible time warning when it is completed. Time Delay You can select and start a If an economical electricity tariff is applied new programme following in your region, you can use the Time the cancellation of Time Delay... -
Page 36: Adjusting The Amount Of Rinse Aid
Operating the product Cancelling the programme Selection key. 4. Press On / Off key to save the setting. Open the door of the product Press and hold the Programme Selection / Programme No rinse aid dispensed in P:0 wash position. Cancel keys for 3 seconds. -
Page 37: Water Cut-Off Warning
Operating the product SelfCare Leave your dishes in the machine for about 15 minutes to allow This programme is recommended to be them cool down after they are operated on each 1-2 months for machine washed. Your dishes will dry in a cleaning and necessary hygiene. -
Page 38: Maintenance And Cleaning
Maintenance and cleaning Cleaning the filters Service life of the product extends and frequently faced problems decrease if it is Clean the filters at least once a week in order cleaned at regular intervals. for the machine operates efficiently. Check if Unplug the product and turn off food residues are left on the filters. -
Page 39: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. -
Page 40: Cleaning The Impellers
Maintenance and cleaning Cleaning the impellers Cleaning the impellers Clean the impellers at least once a week in Clean the impellers for the machine to work order for the machine operates efficiently. efficiently. Lower impeller Check if the holes on the lower impeller (1) are clogged. -
Page 41: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 42 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 43 Troubleshooting Since the salt granules that will remain under the lid will dissolve during prewash, causing the lid loosen, check the lid once again at the end of the programme. There is a different odour in the machine A new machine has a peculiar odour. It will fade out after a couple of washes. •...
- Page 44 Troubleshooting Detergent remains in detergent dispenser. • Detergent dispenser was damp when adding detergent. >>> Make sure that the detergent dispenser is dried well prior to filling it with detergent. • Detergent is added long before the washing process. >>> Pay attention to add detergent shortly before start-up of the washing.
- Page 45 Troubleshooting A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. • Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when adding rinse aid.
- Page 46 Troubleshooting ...
- Page 47 Troubleshooting ...
