Summary of Contents for Grundig GNF 41810 W
- Page 1 DISHWASHER USER'S MANUAL GNF 41810 W GNF 41810 X FOR A GOOD REASON Document Number 17 9878 0100_AA/14-08-13...
- Page 2 Please read this user manual first! Dear Customer, Thank you for preferring a Grundig product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
CONTENTS 1 INSTRUCTIONS FOR SAFETY Lower basket multipurpose / height adjustable service rack .......23 AND ENVIRONMENT Upper cutlery basket ........24 General safety ..........4 Intended use ........... 4 5 OPERATING THE Children’s safety ..........5 PRODUCT Disposing of packaging material ....5 Keys ...............26 Transportation of the product ....... -
Page 4: Instructions For Safety And Environment
INSTRUCTIONS FOR SAFETY AND ENVIRONMENT This section contains safety instructions • Never use chemical solvents in the that will help to give protection from risk of product. They bring forth the risk of explosion. personal injury or property damage. Failure •... -
Page 5: Children's Safety
instructions for safety and environment Children’s safety Compliance with WEEE Directive and Disposing of the • Electrical products are dangerous for the children. Keep children away from Waste Product the product when it is in use. Do not let This product complies with EU WEEE them to tamper with the product. -
Page 6: Dishwasher
DISHWASHER Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Cutlery basket 5. Door 6. Control panel 7. Detergent dispenser 8. Lower basket 9. Filters 10. Salt reservoir lid 11. Upper basket rail 12. Upper cutlery basket 13. Ceiling impeller 14. -
Page 7: Technical Specifications
dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2006/95/EC, 89/336/EC, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see type plate) -
Page 8: Installation
INSTALLATION To make the product ready for use, make capacity! The product must be installed on a flat surface in order for the door to sure that the electricity, tap water supply and be closed comfortably and securely. water drainage systems are appropriate •... -
Page 9: Waterprotect
Installation floor. A discharge hose longer than 4 meters WaterProtect+ will cause washing performance to be (depends on model) affected.Attach the water discharge hose to The WaterProtect+ system protects against the drainpipe without bending it. Tightly fix water leaks that may occur at the hose inlet. the water discharge hose to the drainpipe Water contact with the valve box of the in order to prevent any dislocation of the... -
Page 10: Adjusting The Feet
Installation Adjusting the feet This appliance must be If the door of the product cannot be closed earthed properly or if the product swings when If the fitted moulded plug is not you push it slightly, then you need to adjust suitable for your socket, then the the feet of the product. -
Page 11: Initial Use
Installation Connect the brown (live) wire to the terminal in the plug marked ‘L’ or coloured red. Green and yellow or green Blue or Brown or red black With the alternative plugs a 13A fuse must be fitted either in the plug or adaptor or in the main fuse box. -
Page 12: Preparation
PREPARATION Tips for energy saving Following information will help you use the product in an ecological and energy-efficient manner. Wipe away any coarse food remnants on the dishes before putting them in the product. Try to only operate the product when full. When selecting a programme, consider the table of "Programme data and average consumption values". -
Page 13: Adding Salt
Preparation Adding salt 4. Replace the lid and tighten it securely when the reservoir is full. Water softening system needs to be 5. If you will not start a washing programme regenerated in order for the product immediately after adding the salt, run the to operate with the same performance machine empty in the shortest programme to continuously. -
Page 14: Water Hardness Level Adjustment Table
Preparation Water hardness & regeneration settings The dishwasher requires lime free water. Hard water leaves watermarks on your dishes. Your dishwasher has a special water softening system to remove the hardness of the tap water. Setting this system correctly will increase the washing effectiveness. To find out the water hardness level of water in your area, contact your local Water Board or determine water hardness level by the help of test strip provided. -
Page 15: Detergent
Preparation Press «Start/Pause/Cancel» key for once Do not put solvents into the to store the level you have selected. detergent dispenser. There is the Start / Stop icon will light continuously risk of explosion! when the new water hardness level is Put the detergent into the detergent dispenser stored. -
Page 16: Tablet Detergents
Preparation 3. Close the detergent dispenser lid by pressing on it lightly. A "click" will be heard when the lid is closed. In programmes with pre-washing and high temperature, in which you may use tablet detergents, make sure that the detergent dispenser lid is closed firmly. -
Page 17: Rinse Aid
Preparation detergent from tablet detergent: 1. Make sure that salt and rinse aid reservoirs are full. 2. Set the water hardness to the highest level and perform an empty run. 3. After the empty washing cycle, review the user manual and readjust the water hardness level so as to suit the water supply. - Page 18 Preparation Items not suitable for washing in the the upper basket. dishwasher • Place the hollowed dishes such as bowls, • Never wash dishes soiled by cigarette glasses and pans upside down in the ash, candle remnants, polish, dyestuff, dishwasher to prevent accumulation of chemicals, etc.
- Page 19 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware DISHWASHER / USER'S MANUAL 19 / 44 EN...
-
Page 20: Cutlery Basket
Preparation Grab one of the upper basket wires (right or Cutlery basket left) and lift it up (A). (depends on model) Repeat the same process to raise the other Cutlery basket is designed to wash your side of the basket. dishes such as knife, fork, spoon, etc. -
Page 21: Collapsable Upper Basket Tines
Preparation Collapsable upper basket tines Upper basket height adjustable rack (depends on model) Upper basket of the machine is equipped (depends on model) with tines with gradual folding system (A) Use the lower and upper parts of the height that you can lay down when you need a adjustable racks in the upper basket of larger space for large dishes. -
Page 22: Collapsable Lower Basket Tines
Preparation Collapsable lower basket tines Bringing the tines to the horizontal position by holding (depends on model) them from the tips may cause The six piece foldable tines (A) located them to bend. Therefore, it will at the lower basket of the machine are be appropriate to bring the tines designed for an easier placement of large in the middle to horizontal or... -
Page 23: Lower Basket Multipurpose / Height Adjustable Service Rack
Preparation Lower basket multipurpose / Make sure that the impeller does height adjustable service rack not touch the dishes you placed on the racks. (depends on model) This accessory located at the lower basket To close the racks: of your machine allows you to easily wash 1. -
Page 24: Upper Cutlery Basket
Preparation Upper cutlery basket (depends on model) The upper cutlery basket is designed for small dishes, or long dishes that cannot fit into the lower cutlery basket. After taking out the basket by lifting it up, remove the carrier part from the rails by pulling it towards yourself (C). -
Page 25: Operating The Product
OPERATING THE PRODUCT 1. On / Off key 4. Time Delay key 2. Programme Selection keys 5. Start / Pause / Cancel key 3. Function keys 6. Display a) Tablet (Child Lock) key 7. Programme indicator b) Half Load (Volume Adjustment) 8. -
Page 26: Keys
Operating the product Keys Same function keys are used for Child (Key) Lock and Volume On / Off key Level Setting. It is used to turn on or off the machine. Press the On / Off key for 1 second to turn Time Delay key on. -
Page 27: Auxiliary Functions
Operating the product Number of the programmes Tablet Detergent indicator lights on the machine may change when the Tablet function is depending on the model you selected. have purchased. Tablet detergent function may cause change in the programme Auxiliary functions duration. -
Page 28: Programming The Washing Time
Operating the product 3. Selection will be cancelled when you Changing the settings while Time press the function key again. Delay function is enabled. While the Time Delay function is activated, Unlike other functions, the Tablet you cannot make changes in the washing function will remain selected programme, auxiliary functions or the unless you cancel this function by... -
Page 29: Programme Follow-Up
Operating the product d) End of Programme indicator Your machine performs water Indicators for Washing / Rinsing / Drying softening depending on the will light respectively on the display hardness level of the supply throughout the washing programme. water. Remaining time displayed Indicator of a finished step will not go off, towards the end in some but they will light additionally to each other. -
Page 30: Cancelling A Programme
Operating the product Volume setting If you turn your machine off by using On/Off key at the Your machine is equipped with a Buzzer to end of the programme, the inform warnings audibly. Child Lock will be deactivated When the Volume Level key (same as the automatically. -
Page 31: End Of Programme
Operating the product Make sure that the water is not cut-off and the tap is not closed when the Water Cut-off warning light is illuminated. Call Authorised Service Agent if water is not cut-off and the tap is open. End of programme End of Programme indicator will light up once the washing programme is over. - Page 32 Operating the product /44 EN DISHWASHER / USER'S MANUAL...
-
Page 33: Maintenance And Cleaning
MAINTENANCE AND CLEANING (2) assembly counterclockwise and pull Service life of the product extends and it out from its seating (A). frequently faced problems decrease if it is cleaned at regular intervals. Unplug the product and turn off the tap before attempting any cleaning procedures. -
Page 34: Cleaning The Impellers
Maintenance and cleaning Cleaning the impellers 6. Place the coarse filter into the microfilter. Make sure that it is properly seated. Turn Clean the impellers at least once a week in the coarse filter clockwise until a “click” order for the machine operates efficiently. sound is heard. -
Page 35: Upper Impeller
Maintenance and cleaning Upper impeller Top Impeller Check if the holes on the upper impeller (1) Check if the holes on the top impeller (1) are clogged. If they are clogged, remove of your machine are clogged. If they are and clean the impeller. -
Page 36: Troubleshooting
TROUBLESHOOTING Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 37 Troubleshooting Dishes are not dry at the end of cycle • Dishes are not placed orderly in the machine. >>> Place your dishes in a way that no water will accumulate in them. • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary.
- Page 38 Troubleshooting Lime traces remain on dishes and glassware gains a misty appearance • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine.
- Page 39 Troubleshooting Rust, discoloration or surface deterioration occurs on dishes • Salt leakage exists. >>> Salt may cause deterioration and oxidation on metal surfaces. Pay attention not to spill salt around the salt filling hole while adding salt. Make sure that the salt reservoir lid is tightly closed after finishing the filling process. Run the prewash programme to remove the salt that spilled inside the machine.
- Page 40 Troubleshooting Decorations and ornaments on kitchen utensils are being erased. Decorated glasses and decorated luster porcelains are not suitable for washing in the dishwasher. Manufacturers of some glassware and porcelain tableware items do not recommend washing such kitchen utensils in the dishwashers either. Dishes are scratched.
- Page 41 Troubleshooting Foam forms in the machine. • Dishes are washed with hand-wash detergent by hand but not rinsed before placing them into the machine. >>> Hand-wash detergents do not contain antifoam. There is no need to hand-wash the dishes before placing them into the machine. Removing the coarse soil on the dishes under tap water, with a tissue paper or fork will be sufficient.
-
Page 42: Important Notes
Troubleshooting Important notes. • Your Grundig product is designed and built for domestic household use only. Guarantee for Refrigeration, • The guarantee will be void if the Cooking Appliances, Washing product is installed or used in Machines & Dishwashers. commercial or non-residential domestic household premises. - Page 43 If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee agreement document. Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Grundig Customer Help-Line. Tel: 0845 6004911 e-mail: service@Grundig.co.uk...
- Page 44 FOR A GOOD REASON...
