7.3 Stream RTSP

7.3.1 RTSP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen of
any tab.
(2) Verify Output Resolution is set to Follow Input to output a HD stream. If a lower resolution output is
desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTSP in the Output Format dropdown menu.
Note: By default, a limited selection of video encoding settings are available in the user interface. See Section
9.2, "Advanced Settings Mode", for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the fields
above will appear in dark grey.
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
(2) Verify is
"Follow Input"
(3) Note value
(1) If necessary, click "Stop"
Figure 15
CH1 Tab Configuration – RTSP
23
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
HE2K-MINI-RPS User Guide
DOC-USR-0232-02
(4) Change
to "RTSP"
(5) Click "Start"
