MIDI channel 1 has been selected. Simply continue
to press the CH 1 button to get to the channel you
desire. As you press the button you will notice the
other Channel LEDs and Bright LED turn on as you
increase the MIDI channel number. Once you reach
the channel you desire, press the STORE button to
save it to memory.
Simply continue to press the CH 1 button to get to the
channel you desire. As you press the button you will
notice the other Channel LEDs turn on as you increase
the MIDI channel number. Once you reach the channel
you desire, press the STORE button to save it to
memory.
Note: Only 4 LEDs are used, so the MIDI channel
count will be done in values of 4. MIDI channel 1 will be
signified by CH1 CLEAN LED flashing, & as you increase
in number, MIDI channel 4 will be signified by all three
channel LEDS and the bright LED flashing, but once
MIDI channel 5 is selected, only the CH1 CLEAN LED
will flash again. Every time you reach MIDI channel 5, 9,
or 13, the LED cycle will once again start from the CH1
CLEAN LED. So keep count as you select the channel
you desire. If you go past MIDI channel 16, the count
will start at channel 1 again. Once saved to memory,
the Channel LEDs and bright LED will flash very quickly
several times to verify the change has been made &
completed.

MIDI PROGRAM CHANGE

This amplifier can remember up to 128 program settings
of the MIDI controllable functions. To set a program (i.e.
amplifier configuration) to be controlled via MIDI:
1. Set the amplifier to the configuration you intend to
save to a program number. (Ex: Ch: 3, Aggression
level: 2, Fat: ON, Master Volume: 2, FX Loop: OFF,
etc)
2. Once the amplifier is configured as you would like,
press the store button. The Store LED will flash &
the amplifier will wait now for a command through
its MIDI IN jack.
3. Send a program change command from your MIDI
Pedal or other equipment with the correct channel
& program number you intend to have the amplifier.
save the current configuration to.
4. Once the command is received, the amplifier will
save the current amp configuration to that program
number. The Store LED will flash 3 times & turn off
verifying that the command has been received &
saved.
Now, anytime you send that program number to the amplifier
from your MIDI pedal or other external equipment, the amplifier
will switch to that saved configuration. This will allow for any
configuration of your settings to be recalled with any MIDI device.

MIDI CONTROLLABLE FUNCTIONS

The amplifier functions that can be controlled via MIDI
are as follows:
Channel Selection (1-3)
Wide Mode (Ch1
3 Drive Levels (Ch2)
3 Aggression Levels (Channel 3)
Bright function (All Channels)
Cut function (Channel 3)
Fat function (Channel 3)
FX Loop in/out
Master Volume 1 & 2
Reverb
Noise Gate
Pre-Post
40 Mute
Two Notes Embedded Functions
These functions can be set & controlled in a MIDI
program change setting, where one program change
command will call up a configuration of the above
settings, or continuous controller commands, where
a CC command will switch any one of the functions
listed above, independent from any of the others. The
CC command functions are great for things like instant
access buttons on foot pedals etc.

CONTINUOUS CONTROLLER (CC)

To use CC commands, the amplifier Functions have
all been given a designated number & on or off
setting. When using & selecting a function the number
associated with the function must be used & then the
setting of the function (on or off) must also be sent.
Most MIDI equipment (pedals etc) allows you to select
