Summary of Contents for Briteq BT-THEATRE 150EZ
-
Page 3: Before Use
• The incredible light output easily outperforms traditional 2kW halogen theatre projectors!!! • BT-THEATRE 150EZ: 150watt LED, warm white 3200K with high CRI-factor (>97) for natural colors. • BT-THEATRE 250EZ: 250watt LED, warm white 3200K with high CRI-factor (>92) for natural colors. -
Page 4: Safety Instructions
• Due to safety reasons it is prohibited to make unauthorized modifications to the unit. Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy. BRITEQ 2/12 BT-THEATRE 150EZ/250EZ ®... - Page 5 Fresnel lens from spilling into areas where it is not wanted, such as the eyes of audience members. Just rotate the barndoor leafs in the desired position. BRITEQ 3/12 BT-THEATRE 150EZ/250EZ ®...
-
Page 6: Overhead Rigging
• [3CH D+S+F 8bit] : 3 channel mode with 8bit dimmer, strobe and focus. • [2CH DIM 16bit] : 2 channel mode with 16bit dimmer. You can set a fixed beam angle with the function [FOCUS PRESET] of the setup menu. BRITEQ 4/12 BT-THEATRE 150EZ/250EZ ®... - Page 7 LED Temp. xxx °C / °F INFORMATION ERROR info xxxxxxxx Model Name BT-THEATRE 150EZ (BT-THEATRE 250EZ) Firmware V. V x.xx [SET CONFIG > FIXTURE Set] – Used to configure different parameters if the projector. [NO DMX Mode] Used to set how the projector reacts when the DMX-signal disappears.
- Page 8 • [High]: the LED will be well cooled so maximum light output can be guaranteed under all conditions. However this means that fan noise will be higher than usual. • Press the [ENTER] button to confirm. BRITEQ 6/12 BT-THEATRE 150EZ/250EZ ®...
- Page 9 • Press the [ENTER] button and use ▲/▼ buttons to confirm YES / NO • Press the [ENTER] button to confirm. • [SAVE] was selected: the current settings of the setup menu are saved to memory. • [LOAD] was selected: the previously saved settings are loaded. BRITEQ 7/12 BT-THEATRE 150EZ/250EZ ®...
- Page 10 • Press the [ENTER] button: the display shows the firmware version. Note: The firmware of this unit can be upgraded using our special “Firmware Updater 2” (separately available from Briteq). More information about this can be found in the user manual of the firmware updater or our website: https://briteq-lighting.com/firmware-updater-2...
-
Page 11: Other Setup Functions
• Make sure that all units are connected to the mains. • Each unit in the chain needs to have its proper starting address so it knows which commands from the controller it has to decode. BRITEQ 9/12 BT-THEATRE 150EZ/250EZ ®... - Page 12 • The DMX-controller sends out a “discovery command”, all RDM devices respond and send their unique device ID. • The DMX-controller asks each RDM device for some basic data so it knows which devices are connected. The projector will respond: • Device name: BT-THEATRE 150EZ (or BT-THEATRE 250EZ) • Manufacturer: ® Briteq • Category: LED Dimmer •...
-
Page 13: Maintenance
• Clean with a soft cloth using normal glass cleaning products. • Always dry the parts carefully. Attention: We strongly recommend internal cleaning to be carried out by qualified personnel! BRITEQ 11/12 BT-THEATRE 150EZ/250EZ ®... -
Page 14: Specifications
10° ~ 50° IP-Rating: IP20 Size: See drawing Weight: 9 kg The information might be modified without prior notice You can download the latest version of this user manual on our website: www.briteq-lighting.com BRITEQ 12/12 BT-THEATRE 150EZ/250EZ ®...
