Summary of Contents for TRENDnet TE100-MP1U

  • Page 2: Table Of Contents

    4.4.4 Using the Control Center for Raw TCP/JetDirect Printing ...31 4.4.5 Using Standard Windows Methods for SMB/CIFS Printing ...33 4.4.6 Using the Control Center for SMB/CIFS Printing ...34 4.4.7 Using Standard Windows Method for IPP Printing...36 CHAPTER5 PRINT SERVER IN UNIX/LINUX ...38 Table of Contents...
  • Page 3 Configuring Host File...38 Printing by LPD/LPR ...38 Using the Server on BSD UNIX/Linux...38 Using the Server on RedHat Linux (Fedora Core)...39 CHAPTER6 FILE SERVER...46 Preliminary ...46 Storage Names ...46 Connecting USB Mass Storage to the Server ...46 Supported Codepages ...47 Adding Your USB Mass Storages to Network with Security ...49 6.5.1 Setting up File Server Using the Control Center...49 6.5.2 Setting up File Server Using Web Pages ...51...
  • Page 4 CHAPTER14 UPGRADE FIRMWARE...86 CHAPTER15 THE INIT BUTTON ...89...

  • Page 5: Chapter1 Introduction

    TE100-MP1U and TEW-MP2U. Similarly, almost all of the configuration and operations are the same for TE100-MP1U and TEW-MP2U except that only one USB device can be connected to TE100-MP1U while at most two USB devices can be connected to TE100-MP2U.

  • Page 6: Chapter2 Product Overview

    Link Status (only for TE100-MP2U and TEW-MP2U) is lit while network is applied. If it is not lit, it indicates that this server does not connect to the network. Status Indicator (only for TE100-MP1U and TE100-MP2U) blinks to indicate network activity. LAN Indicator (TEW-MP2U only) blinks to indicate wired network activity.

  • Page 7: Installation Procedures

    2.4.1 Installation and Integration Please refer to the table below to select the appropriate installation method. The Control Center Utility can be found in the CD-ROM or download from TRENDnet’s Website. Note: 1. A computer using LRP Printing and a computer using NetUSB Printing can not print documents to the same printer simultaneously.

  • Page 8: Features And Benefits

    Features and Benefits This Server provides the following features and benefits: 1. Reliability: The Server provides high performance and reliability combined with low power consumption. 2. Flexibility: The Server supports print/File/Scan sharing in all major computer systems and environments. 3. Easy to Install: The Server installs, operates, and is managed in a reliable and easy fashion.

  • Page 9: Chapter3 Basic Installation

    5. Connect the Power Adapter to the Server. The power indicator will light up and USB1 and USB2 indicators will flash in turn. (For TE100-MP1U, only USB1 indicator will flash.) When the Link indicator lights up, the Server is correctly connected to the network.
  • Page 10 If the wireless parameters are not correct or not set yet, you have to use LAN to access MFP Server Control Center. 3. If the tool finds MFP Servers in your local area network, then you have to select a MFP Server from the server list. 4.
  • Page 11 8. If the wireless network is secured by WPA-PSK/TKIP, the shared key must be set correctly.

  • Page 12: Set Wireless Configuration Using Server's Web

    9. Click Apply to save your settings. And the server will reboot. 10. You have now finished the procedure of setting the wireless parameters. In infrastructure mode, TEW-MP2U searches all channels to join the matched wireless service set. In ad-hoc mode, TEW-MP2U searches all channels to join the matched wireless ad-hoc service set too, however, if none are found, TEW-MP2U creates that service set in the assigned channel.
  • Page 13 If the wireless parameters are not correct or not set yet, you have to use LAN to access Web Pages. If the TCP/IP parameters of TEW-MP2U are not correct, you have to use MFP Server Control Center to set the TCP/IP parameters first. 2.
  • Page 14 5. In order to join an existing wireless network, you have to set the correct network type (infrastructure or ad-hoc), SSID, and the correct security method with the correct key information. 6. If the wireless network is secured by WEP64 or WEP128, key index and WEP key must be set correctly.
  • Page 15 7. If the wireless network is secured by WPA-PSK/TKIP, the shared key must be set correctly.

  • Page 16: Assigning An Ip Address To The Server

    8. Click Submit to save your settings. And the server will reboot. 9. You have now finished the procedure of setting the wireless parameters. In infrastructure mode, TEW-MP2U searches all channels to join the matched wireless service set. In ad-hoc mode, TEW-MP2U searches all channels to join the matched wireless ad-hoc service set too, however, if none are found, TEW-MP2U creates that service set in the assigned channel.

  • Page 17: Server Names And Server Name Rules

    3.3.5 Server Names and Server Name Rules The default server name of the Server is “TE100-MP1U” or “TE100-MP2U” or “TEW-MP2U”. If you put two or more Servers in your local area network, to avoid using the same server names you have to change the server names by using the Control Center or the Server’s web pages.
  • Page 18 14. Double click the highlight list and enter the Server’s administrator (default: admin) and password (default: admin). 15. After you have logged in successfully, select TCP/IP from the Server’s menu. The Set IP Address dialog appears.

  • Page 19: Setting The Ip Address Using The Server's Web

    16. Click the button corresponding to your choice of IP setting method (static or dynamic using DHCP). When assigning a static IP address you also have to define Subnet Mask and Default Gateway. If you choose Automatically get IP by DHCP, you can use desired DNS by clicking the Manual DNS button and manually assigning a DNS.
  • Page 20 4. Enter administrator (default: admin) and password (default: admin). 5. Click TCP/IP icon. 6. Click the button corresponding to your choice of IP setting methods (static or...

  • Page 21: Name Of Usb Device

    dynamic using DHCP). When assigning a static IP address you also have to define Subnet Mask and Default Gateway. 7. Click Submit to save your settings. And the Server will reboot. You have now finished the procedure of setting the IP address. Name of USB Device 3.4.1 Printer Names...

  • Page 22: Chapter4 Print Server In Windows

    Chapter4 Print Server in Windows Overview of Installation Methods This chapter describes how to add network printers. Table List for Installing Network Printer Windows Printing Platform Protocols Windows 98, ME, SMB/CIFS Printing 2000,XP and 2003 IPP Printing Windows 2000, LPR Printing...

  • Page 23: The Server And Windows Pc On Same Lan

    4.2.1 The Server and Windows PC on Same LAN 4.2.2 The Server and Windows PC on Different LANs Example: Wired Windows PC across Internet Setting up Local Windows Printer Driver You are advised to install your Windows printer driver in advance. For most printers, you can install the printer drivers with the following procedure: 1.

  • Page 24: Adding Network Printers In Windows

    5. Choose whether you want to share the printer with other network users. Do you want to print a test page? Select the appropriate radio button and click Next and Finish. Adding Network Printers in Windows Follow the instructions below to use the standard Windows Add Printer Wizard and the Control Center for adding a network printer in Windows 98 SE, ME, 2000, XP and 2003.
  • Page 25 5. In the Printer Name or IP Address box, enter the Server Name of the Server or IP address of the Server. In the Port Name box, enter your desired names or USB1_LPR or USB2_LPR for printer connected to USB1 port and USB2 port, respectively.
  • Page 26 Address box. 6. Click Next. 7. Click Custom/settings. 8. Click Settings and confirm that the settings are as below. The queue names are USB1_LQ, USB2_LQ for USB1 port 1 and USB2 port, respectively. Click OK.
  • Page 27 9. Click Finish...

  • Page 28: Using The Control Center For Lpr Printing

    4.4.2 Using the Control Center for LPR Printing Windows Platform: Windows 2000, XP and 2003 1. Start the Control Center, right-click on your Server and select Set Printer. 2. Select USB1 Port or USB2 Port to add the printer in Set printer in box, choose to use Server Name or IP address to represent the Server in Select IP address or Host Name in printer port box, and select the network printing protocol of Printing with LPR (Line Printer Remote).

  • Page 29: Using Standard Windows Method For Raw Tcp Printing

    If your Server is running on a different LAN than your Windows PC such as Internet PC, you must choose IP address in Select IP address or Host Name in printer port box. 3. Click Apply. 4. Select the desired printer driver and click Set Port to Printer. 5.
  • Page 30 Number values are 9100, 9101 for USB port 1 and USB port 2, respectively. Refer to the Server’s web pages or the Control Center, you can get exact values. Click OK. 9. Click Finish.

  • Page 31: Using The Control Center For Raw Tcp/Jetdirect Printing

    4.4.4 Using the Control Center for Raw TCP/JetDirect Printing Windows Platform: Windows 2000, XP and 2003 1. Start the Control Center, right-click on your Server and select Set Printer. 2. Select USB1 Port or USB2 Port to add the printer in Set printer in box, choose to use or IP address to represent the Server in Select IP Address or Host Name in printer port box, and select the network printing protocol of Print with Raw TCP Mode.
  • Page 32 If your Server is running on a different LAN than your Windows PC such as Internet PC, you must choose IP address in Select IP Address or Host Name in printer port box. 3. Click Apply. 4. Select the desired printer driver and click Set Port to Printer.

  • Page 33: Using Standard Windows Methods For Smb/Cifs Printing

    5. If you cannot find any printer driver in Printer List, please install your printer driver first or click Add New Printer to install the printer driver. 4.4.5 Using Standard Windows Methods for SMB/CIFS Printing Before using SMB/CIFS printing, you have to login the SMB/CIF Print/File server in advance and then you may use it;...

  • Page 34: Using The Control Center For Smb/Cifs Printing

    If your Server is running on a different LAN than your windows PC such as Internet PC, you must enter IP address in Port Name box. 6. Click OK, and then select a Windows driver for your printer. If you already have the printer’s driver installed, you will be asked whether to keep it or to replace it.
  • Page 35 If your Server is running on a different LAN than your Windows PC such as Internet PC, you must choose IP address in Select IP address or Host Name in printer port box. 3. Click Apply. 4. Select the desired printer driver and click Set Port to Printer.

  • Page 36: Using Standard Windows Method For Ipp Printing

    5. If you cannot find any printer driver in Printer List, please install your printer driver first or click Add New Printer to install the printer driver. 4.4.7 Using Standard Windows Method for IPP Printing Windows Platform: Windows 98 SE, ME, 2000, XP and 2003 1.
  • Page 37 5. Click Next and then continue Windows Add Printer Wizard.

  • Page 38: Chapter5 Print Server In Unix/Linux

    Chapter5 Print Server in Unix/Linux This chapter describes how to add network printers to Unix/Linux PC. Configuring Host File If using IP administration system like DNS, manually registering the Server Name and IP address may be not required. Otherwise, you have to edit hosts file and contact your network administrator.

  • Page 39: Using The Server On Redhat Linux (Fedora Core)

    :sd=/var/spool/lpd/Printer1:\ ---(C) :lf=/var/spool/lpd/Printer1/Printer1_errs: ---(D) where (A) Describes the printer name. (B) lp: Device file name to connect printer. No name designation required on the network. rm: Server Name for the remote printer. Enter the Server Name registered to /etc/hosts file. rp: Remote printer name.
  • Page 40 2. Click on the New button in the Printer configuration window. 3. Click on the Forward button in the Add a new print queue window.
  • Page 41 4. Fill in your desired printer name and description (optional) in Queue name window and then click on the Forward button. 5. In Queue type window, you will now be asked to specify which Printer Queue type you are using, select the one option form Networked Unix (LPD), Networked CUPS (IPP), Networked Windows (SMB) and Networked JetDirect options.
  • Page 42 192.168.1.100 and it connects to HP PSC 1300 MFP via USB1 port. You can enter IP address in the Server box as 192.168.1.100 and Queue name in Queue box as USB1_LQ. Networked JetDirect: Fill in the Server’s IP address and protocol’s TCP port and then click the Forward button.
  • Page 43 C. Networked Windows (SMB): Click on the Specify button to specify SMB server Authentication. Fill in the Workgroup, Server Name, User name and Password in Authentication window and then click on the OK button. iii. Click on the Forward button.
  • Page 44 Networked CUPS (IPP): Fill in the Server’s IP address and printer name then click the Forward button. Example: If your Server’s IP address is 192.168.1.100 and its printer name is psc 1300 ser. You can enter IP address in Server box as 192.168.1.100 and printer name in Path box as psc 1300 ser.
  • Page 45 8. Click Finish button.

  • Page 46: Chapter6 File Server

    “write” operation on NTFS is only supported in NetUSB mode. Please refer to the Storage Access Mode. 2. TRENDnet is not responsible for the loss or corruption of data in memory devices, including hard disk; TRENDnet is not responsible for the leak, manipulation, loss, or corruption of data in memory devices connected to the Server after unauthorized access.

  • Page 47: 6.4 Supported Codepages

    6.4 Supported Codepages What is codepage? Used by the system to encode and interpret string characters. Codepage formats are not the same for each language. multibyte characters, while others, such as English and German, need only one byte to represent each character. Filename Encoding of FAT File System This is known as an 8.3 file name, a short file name using codepage encoding.
  • Page 48 5. Select your codepage form File Server Codepage box and click Apply. Using Server’s Web Pages 1. Go to the web page, click CONFIG 2. Login your administrator (default: admin) and password (default: admin). 3. After you have logged in successfully, setting General Configuration dialog appears.

  • Page 49: 6.5 Adding Your Usb Mass Storages To Network With Security

    4. Select your codepage form File Server Codepage box and click Apply. 6.5 Adding Your USB Mass Storages to Network with Security You can use the following protocols to share your USB Mass Storages with user level security in network: SMB/CIFS: NetBIOS over TCP/IP The protocols are shown in Supported Protocols box of the Control Center or the Server’s web pages.
  • Page 50 5. Set up File Server Configuration: Set SMB/CIFS Print/File Server Enable SMB/CIFS Print/File Server: select the item, if you want to support SMB/CIFS print/File server. Enable Internet Access: clear the item, if you do not allow that users can access your SMB/CIFS server via Internet. If you select the item, you allow Internet users can access your storage using the SMB/CIFS protocol.

  • Page 51: Setting Up File Server Using Web

    number. Enable Passive Mode: select the item, if you want to allow that your FTP server can accept passive mode command. Enable Server Authentication: select the item, if you want to share your storage with user level security which requires user name and password to login.

  • Page 52: Using Shared Storages By Smb/Cifs Method For Windows

    4. Set up File Server Configuration: A. Set SMB/CIFS Print/File Server Enable SMB/CIFS Print/File Server: select the item, if you want to support SMB/CIFS print/File server. Enable Internet Access: clear the item, if you do not allow that users can access your SMB/CIFS server via Internet. If you select the item, you allow Internet users can access your storage using the SMB/CIFS protocol.

  • Page 53: Using Shared Storage By Ftp Methods For Windows

    3. Click Display the Computers of Workgroup 4. Double click Microsoft Windows Network icon. 5. Double click the Workgroup that the Server belongs to. The default Workgroup name is “WORKGROUP”. You can refer to Control Center or the Server’s web pages to get it. You will see that the Server is displayed as its server name.
  • Page 54 1. Open Microsoft IE 2. In Web Address List, enter command: “ftp://Server’s Server Name“ or “ftp://Server’s IP address”. If you have changed the default FTP port : 21 to the new value, you have to add the new port number in the tail of command as “ftp://Server’s Server Name: ftp port”...

  • Page 55: Chapter7 The Netusb Technology

    Connect & Disconnect “NetUSB” allows you to use USB printers or USB MFPs as if they were connected directly to your PC although they are actually connected to the TE100-MP1U /TE100-MP2U/TEW-MP2U USB MFP Server. The “connect” operation is a software operation that simulates an actual USB device plug-in.

  • Page 56: How To Use

    The steps to do remote installation for USB devices, like MFPs: Turn on the TE100-MP1U/TE100-MP2U/TEW-MP2U and the USB device. Connect the USB device to TE100-MP1U/TE100-MP2U/TEW-MP2U. The LED of the USB port will light-on. Run the Control Center. In the “USB MFP Server List” window, you can see the server names and IP addresses all of the TE100-MP1U/TE100-MP2U/TEW-MP2U Servers (in blue) on the network, as the following figure.
  • Page 57 Click the server. Then all USB devices attached on the server will be shown. Please follow the user manual of the USB device to do the driver installation. For example, you may put the driver CD of the USB device in the CDROM to install the driver.

  • Page 58: Netusb Printing

    PC will automatically detect the plug-in of the USB device. On the right side of Windows Task Bar, you can see the information of the new device. Continue to follow the user manual of the USB device to do the rest jobs of installation, until the driver installation finished.
  • Page 59 D. Choose the desired printer. The desired printer must be the Windows printer (this is a logical printer) that matches the printer attached on the MFP Server (this is a physical printer). Then click the “Apply” button. E. Then, the printer will be marked as an “Auto-Connected Printer” in red. If you choose “Auto-Connected Printer List”...

  • Page 60: Netusb Scanning

    Then try to issue a print job to the desired printer. You will see the Control Center will automatically do a connect operation. Then, the print job will be issued to that printer. This is so-called “Auto Connect Print” operation. G.
  • Page 61 E. Then the “Scanner Wizard” will run. Set the options as your need. Then submit the scan job. After the scanning finished, click the “Disconnect” button in the Control Center to release the ownership of the scanner (or MFP). The steps described above require manual “connect” and “disconnect” operations...

  • Page 62: Netusb Scanning Using Network Scan

    before and after the scanning, respectively. We will introduce “auto-connect scanning” in the following section. 7.3.4 NetUSB Scanning using Network Scan For NetUSB scanning, we recommend you use Network Scan as the following steps. A. In the Control Center, click the MFP Server that has the desired MFP attached. B.

  • Page 63: Accessing Usb Storage Using Netusb Technology

    E. Follow the usual steps to do scanning. After the scanning, close the “Auto-Connect Scanner” window. 7.3.5 Accessing USB Storage using NetUSB Technology Before you use NetUSB technology to access USB storage, please make sure the storage access mode is in NetUSB mode. A.

  • Page 64: Limitations

    C. Click the “Connect” button to manually connect the USB storage device. D. Now your PC will have a new disk. For example, if you connect a flash drive, your PC will have a new “removable disk”. You can see the storage icon in the system tray, as the following figure.

  • Page 65: Chapter8 The Control Center

    Chapter8 The Control Center This chapter describes how to use the Control Center. Installing Control Center 1. Insert the included CD into the personal computer. The Autorun screen as in the following should appear. 2. Click Install Utility button. 3. Click Next, if you see any Next button in installation windows. 4.

  • Page 66: Displaying Server Status

    Note 1: You can also right-click the mouse button on the highlighted MFP Server to get the “Configure Server”, “Goto Homepage”, “Set Printer”, and “Network Storage” functions. Note2: You can also double-click on the highlighted server to get the “Configure Server”...
  • Page 67 TCP Port 2: set TCP port for the printer of USB2 port (default: 9101) Enable SMB/CIFS Print/File Server: select or clear Enable SMB/CIFS Print/File Server support. It is enabled in Factory Default. Enable Internet Access: select or clear Enable Internet Access support.
  • Page 68 Storage Access Mode 1. Server Mode: In this mode, you can access the USB storage via FTP or SMB/CIFS protocols. FAT16/32 file format is fully supported in this mode. For NTFS, however, only the “read” operation is supported. This is the default mode. 2.
  • Page 69 Retype Password: confirm your previous password typing. User Accounts list User name: add a new user account for accessing the storage attached to the Server. Password: set a password for added user. Permission: select Read-Only or Read-Write permission to access File servers.
  • Page 70 SysLocation: enter some letters for variable of SysLocation that represents the location of system. EnableAuthenTrap: enter 1 or 2 for the variable of EnableAuthenTrap that represents to enable (1) or disable (2) to send Trap packets receiving the wrong Community name. SNMP V3 Enable SNMP V3: select or clear Enable SnmpV3 support User Security name: set user security name of SNMP v3...
  • Page 71 Cc: stands for carbon copy; enter an e-mail address to send that mail to a second person. SMTP Server requires authentication: login to remote SMTP server which requires authentication. Account Name: enter account name for remote SMTP server. Password: enter account’s password for remote SMTP server. Maintenance: If you want to restart the Server, restore the Server to factory defaults, download new firmware file from product’s public website and upgrade new firmware, you can use the Maintenance tool.

  • Page 72: Quitting The Control Center

    Quitting the Control Center The Control Center doesn’t really quit if you click the “X” box (close box) at the top right corner of the window. Instead, it just minimizes itself to the system tray. There are two ways to really close the Control Center. The first way is choosing “Exit” item in the “File”...

  • Page 73: Chapter9 The Server's Web

    Chapter9 The Server’s Web Pages Introduction The Server runs the daemon of http server, httpd on TCP port: 80. Users may use the web pages to see the Server’s system status and configure the Server. Using the Server’s Web Pages 9.2.1 Displaying Server Status You can see the status of Host Information, TCP/IP, Support Protocol and USB devices.

  • Page 74: Setting Up Server Configuration

    9.2.2 Setting up Server Configuration To set up the Server configuration, the system will request user to enter administrator (default: admin) and password (default: admin) to login. General Configuration Server Information: You have to set some information for networking using SMB protocol: Server Name: the name to represent the Server for using SMB protocol Workgroup: the name of the SMB workgroup that the Server belongs...
  • Page 75 storage or printer with user level security which requires user name and password to login. If you clear the item, your storage will be shared without security. Enable FTP Server: select or clear Enable FTP Server support. It is enabled in Factory Default and users may set some parameters as follows: FTP Port: enter an integer number to set FTP server’s TCP port (default: 21)
  • Page 76 Storage Access Mode 1. Server Mode: In this mode, you can access the USB storage via FTP or SMB/CIFS protocols. Only FAT16/32 file format is supported in this mode. This is the default mode. 2. NetUSB Mode: In this mode, you can access the USB storage using NetUSB technology.
  • Page 77 Password: set a password for added user. Permission: select Read-Only or Read-Write permission to access File servers. Add: click Add button, after entering the user name, corresponding password, and Permission selection. The account will take effect once shown in the blank below. Delete: delete the existing user account.
  • Page 78 receiving the wrong Community name. SNMP V3 Enable SNMP V3: select or clear Enable SnmpV3 support User Security name: set user security name of SNMP v3 Auth Password: set authentication password of SNMP v3. Privacy Password: set privacy password of SNMP v3. Restart Server: click this button, the Server will restart.
  • Page 79 Maintenance If you want to restore factory default values of the Server and upgrade new firmware, you can use the Maintenance tool. Factory Default: click this button, the Server will restore factory default values. Download New Firmware from Website: click this button to download new firmware or user software from this product’s public website.

  • Page 81: Chapter10 Email Alerting

    Chapter10 This Server emails a notification to the user at these events: 1. Adding or Removing a USB device. 2. System Error. Chapter11 This Server runs an SNMP daemon supporting SNMP v1, v2c, and v3 protocols (Simple Network Management Protocol). Users can use SNMP client software such as HP OpenView to manage the Server.

  • Page 82: Chapter12 Troubleshooting

    Chapter12 This chapter provides useful information to help you resolve difficulties that you may experience with your Server. Fault symptoms, possible causes, and remedial actions are provided within a quick reference table. This Server’s USB ports only support MFPs, printers, scanners, and mass storage. 12.1 LED Indicators Indicators Behavior...

  • Page 83: Chapter13 Restore Factory Defaults

    Server. Finally, the Server will operate using the Factory Default values. 13.4 Default Parameters List Host Information Server Name: TE100-MP1U or TE100-MP2U or TEW-MP2U Workgroup: WORKGROUP Description (Optional): Restore Factory Defaults TE100-MP1U USB MFP Server...
  • Page 84 Password: admin SNMP Authentic Community: Trap Community: public Trap Address: 0.0.0.0 SysContact: sales@trendnet.com SysName: TRENDnet TE100-MP1U (or TE100-MP2U or TEW-MP2U) USB MFP Server SysLocation: www.trendnet.com EnableAuthenTrap: SNMPv3: Disabled - User Security Name: - Auth Password: - Privacy Password: Western European Enabled (Disabled).
  • Page 85 Email SMTP Protocol: Disabled SMTP Server Name: SMTP Port Number: Subject: None From Address: None To Address: None None SMTP Server requires authentication: - Account Name: - Password: None None Disabled None...
  • Page 86 Chapter14 Upgrade Firmware This chapter describes how to upgrade firmware. Please follow one of the following Procedures: Procedure A: Using the Control Center 1. Open Control Center. It will automatically search the existing Servers and display their statuses. 2. Select the Server that you want to upgrade the firmware. Double click the selected Server and enter Administrator (default: admin) and Password (default: admin).
  • Page 87 3. First, run Control Center. It will automatically search for Servers on the LAN. Then Servers’ IP addresses will be shown in Control Center. 4. Run any Web browser, like Microsoft Internet Explorer. Go to “http://Server’s IP address “or “http://Server’s Server Name” to access the Server's home page. 5.
  • Page 88 1. Plug in the power adaptor while pressing the Init button until LED indicators of Power, USB1 and USB2 blink. (For TRENDnet 301, only USB1 LED will blink.) Please note that after that, the Server will operate using the factory default values after restarting, i.e., your Server’s configuration will...
  • Page 89 The Init button is used for maintenance: Simultaneously press Init button and turn on (by plugging in the power adaptor) the Server until USB1 and USB2 LED indicators simultaneously blink. (For TE100-MP1U, only USB1 LED indicator will blink.) After that, the Server will do the following tasks: A.

  • Page 90: Limited Warranty

    TEW0-MP2U – 3 Years Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
