ApeosPro C810
ApeosPro C750
ApeosPro C650
User's Manual
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
Parts of this manual is subject to change without prior notice.
The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending on the
model, the software, or the OS.
Control Panel
„ Features of Control Panel
Pressing the Home button displays the Home
screen.
1.
Power/Power Saving button
The power switches on.
Note
When "Please wait..." is displayed, the machine
is warming up. The use of machine is not avail-
able during this time.
If the power does not switch on, confirm that
the power plug is connected.
2.
NFC touch area
This is an area for you to hold up your NFC-supported
mobile devices over. To communicate interactively, the
NFC function of this machine needs to be enabled.
3.
Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine or the fax is stored in a local folder.
4.
Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
5.
Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping on the authentication
information display area logs out the user, and the state
becomes as unauthenticated.
6.
Opening menu
Tap this to open the menu for change and check of the
settings of the machine.
Tap on [<] to close the menu.
[Apps]
5
1
6
Home Button
[Pause]
2
3
4
7.
Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]: You can tap on any of the application icons
and use its functions.
• [Pins]: You can execute a job again using Job Direc-
tion History and the job direction history of which pin
is created with [Create Pin] by user. If you create a
pin of the job direction history, you can also directly
activate a job without opening an application.
• [Address]: You can register addresses and other
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
September 2023 GM1517E5-5 Edition 1
[Pins] [Address]
7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ApeosPro C810 and is the answer not in the manual?

Questions and answers

Summary of Contents for FujiFilm ApeosPro C810

  • Page 1 ApeosPro C810 ApeosPro C750 ApeosPro C650 User's Manual Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference. This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
  • Page 2: Loading Paper

    „ Switching the Power Off Executing the Job from the Pinned Job Direction History When the power is switched off, all the machine functions are stopped. On the [Pins] screen, tap on at the right side Important of the pinned job and tap on [Start Now]. Do not switch the power off when the machine is in the following states.
  • Page 3 When loading paper whose size is JIS B4 or When you have changed the paper type, set larger, pinch the knob and lift the paper rear the Paper Tray on the Device screen. end guide, and set the guide into the hole Tap on >...
  • Page 4: Document Glass

    Copy/Fax/Scan Document Glass Loadable paper Set the document. Paper size (mm) Width: Up to 297 Multiple Length: Up to 432 1 sheet sheets Open the Document Cover, and wipe off any dirt from the Document Glass. Document Feeder Loadable paper Paper size (mm) Width: 84 to 297 Length: 140 to 432...
  • Page 5 On the [Apps] screen, tap on the desired Application icon. Copy Scan Copy As needed, configure the setting items. Enter by the keyboard or by tapping on the Address Book ( ) or Redial ( ) to specify the recipient. Tap on [Start].
  • Page 6: Safety Notes

    Safety Notes „ Electrical Safety WARNING Before using this product, read “Safety Notes” carefully for safety use. This product shall be operated by the power source as indicated This product and recommended supplies have been tested on the product's data plate. Consult your local power company to check if your power source meets the requirements.
  • Page 7: Minimum Configuration

    „ Machine Installation „ Operational Safety WARNING WARNING Do not locate this product where people might step on The operator’s product maintenance procedures are de- or trip over the power cord. Friction or excessive pres- scribed in the manuals supplied with this product. Do not sure may generate heat and eventually cause electric carry out any other maintenance procedures not de- shock or a fire accident.
  • Page 8 Check that the RESET button is turned OFF and in the “O” CAUTION state. Always follow all warning instructions marked on or sup- plied with this product. To avoid the risk of burn injuries RESET button and electric shock, never touch the area with the “Heated surface”...
  • Page 9 „ Consumable „ Regulation Radio Frequency Emissions (Class A digital WARNING device) (European Union) Store all consumables in accordance with the instruc- WARNING: This is a Class A product. In a domestic environment tions given on its package or container. this product may cause radio interference in which case the user may be required to take adequate measures.
  • Page 10 „ Environment Disposal of Electrical and Electronic Equip- ment in Professional/Business Equipment (European Union) In the European Union: This symbol on the product, or in the manual and in the warranty, and/or on its pack- aging indicates that this product shall not be treated as household waste.
  • Page 12: Read Before Using

    Read Before Using Before using the machine, please read “License Agreement” (terms for using the Adobe Inc. software) provided in the “Reference Guide Main Unit”. Reference Guide is available on the official site of our company. Use the software only after you agree with all applicable terms and conditions. By using the software, you are agreeing to be bound by the terms and conditions.
