FujiFilm Apeos C7070 Reference Manual

Hide thumbs Also See for Apeos C7070:
Table of Contents

Advertisement

Quick Links

Apeos™ C7070
Apeos C5570
Apeos C3570
Reference Guide
Appendix
September 2021
Apeos C6570
Apeos C4570
Apeos C3070
GM1049E2-3 Edition1
FUJIFILM Business Innovation Corp.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Apeos C7070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FujiFilm Apeos C7070

Summary of Contents for FujiFilm Apeos C7070

  • Page 1 Apeos™ C7070 Apeos C6570 Apeos C5570 Apeos C4570 Apeos C3570 Apeos C3070 Reference Guide Appendix September 2021 GM1049E2-3 Edition1 FUJIFILM Business Innovation Corp.
  • Page 2 Preface A guide describing the emulation mode, direct print, web applications, troubleshooting, etc. This manual may not be edited, modified or copied in whole or part without the written consent  of the publisher. Parts of this manual is subject to change without prior notice. ...
  • Page 3 Appendix Emulation When using the emulation mode, you can get the print results similar to those of other companies' printers. Overview of Emulation Feature This machine is compatible with following emulation mode. Emulation mode Printer to be emulated ESC/P LQ1900K II+ HP-CLJ5500 (color), HP-LJ4200 (black and white) HP-GL 7586B or DJ750C Plus...

  • Page 4: Print Function

    Print function Emulation mode N Pages Form Barcode ESC/P Up to 64 HP-GL, HP-GL/2 N Pages 2 pages are available. Form You can register standard forms and print the registered forms by synthesizing them into print data. Note If you try to register more forms than the maximum number of forms to be registered or if the form ...

  • Page 5: Emulation Mode

    Port Settings Set in > [Device] > [Network Settings] > [Port Settings].  Enable port (USB/LPD/IPP/Port9100/WSD) Launch the port to be used in the emulation mode. Allocate Memory Set in > [Device] > [App Settings] > [Print Settings] > [Allocate Memory]. Note ...

  • Page 6: Printable Area

    HP-GL, HP-GL/2 Emulation-specific Matters Printable area  Margin XR Long side Margin YU (Top right X, Top right Y) Short side (Bottom left X, Bottom left Y) (0,0) Paper size Printable area Paper Paper length Coordinate value (1/7200″) size (1/7200″) Margin Printable area Top right corner...
  • Page 7  Margin YU Short side Margin XR (Top right X, Top right Y) Long side (Bottom left X, Bottom left Y) (0,0) Paper size Printable area Paper Paper length Coordinate value (1/7200″) size (1/7200″) Margin Printable area Top right corner Margin direction direction...

  • Page 8: Auto Layout

    Hard Clip Area determined by coordinates is called Hard Clip area. Hard Clip area is determined by the printable area or paper size.  When the size is A3 and the starting point is the bottom left (16798,11876) Width (16442,11520) Length (0,0) Standard origin (0,0) Paper origin...
  • Page 9 [Zoom Mode] [Paper Size] Document size is determined based on the drawn object area. Sizes to be determined are A sizes (6 types from A0 through A5). [Coordinate Area] Document size is determined based on the starting point of the drawn object area.
  • Page 10 Item combination examples in Auto Layout  [Zoom Mode]: [Paper Size], [Zoom]: ON Image is reduced/enlarged within the printed area and printed. Paper size Printable area Object area determined in “Area Judgement Mode” Drawn object area ( = Print area) ...
  • Page 11  [Zoom Mode]: [Coordinate Area], [Zoom]: ON Image is reduced/enlarged within the printed area and printed. Paper size Printable area Object area determined in “Area Judgement Mode” Drawn object area ( = Print area)  [Zoom Mode]: [Coordinate Area], [Zoom]: OFF Image is printed in the actual size.
  • Page 12  Determination method example If [Auto Layout] = ON, [Original Size] = [Auto Detect], [Zoom Mode] = [Paper Size], [Area Determine Mode] = [IP] and [Paper Margin] = 10 mm, and [Pen Attributes] of [Pen Width] = 0.1 mm IP-8399,-5938,8399,5938; IW-8399,-5938,8399,5938;...
  • Page 13  If [Original Size] is [Auto Detect] and [Zoom Mode] is [Coordinate Area] Reduction rate is determined by the starting point of the drawn object area and paper size. Hard Clip area is [Normal]. Maximum scale value is 210.0%, and the minimum scale value is 22.5%. Paper 0°...
  • Page 14 Items Item Number Specification value Document [0] : A0 size [1] : A1 [2] : A2 [3] : A3 [4] : A4 [5] : A5 [10] : JIS B0 [11] : JIS B1 [12] : JIS B2 [13] : JIS B3 [14] : JIS B4 [15] : JIS B5 [99] : Auto...
  • Page 15 Items Item Number Specification value Paper supply [0] : Auto tray [1] : Tray 1 [2] : Tray 2 Note [3] : Tray 3  [4] : Tray 4 number [5] : Tray 5 (bypass) of trays [6] : Tray 6 differs [7] : Tray 7 depending...
  • Page 16 Items Item Number Specification value Ejected to [0] : Top output tray/Center tray (lower level) [1] : Side tray Note [2] : Center tray (upper level)  [33] to [42] : Mailbox bin 1 to 10 destinati [68] : Stacker on paper [69] : High capacity stacker tray you...
  • Page 17 Items Item Number Specification value Scale mode [0] : Fixed scale [1] : Arbitrary scale [2] : Entire cut paper Note Fixed scale” refers to the scale automatically  calculated based on the specified “Document size” and “Paper size”, and the printable area for the document size is printed to fit within the printable area of the paper size.
  • Page 18 Items Item Number Specification value Default font [0] : CG Times [1] : CG Times Italic [2] : CG Times Bold [3] : CG Times Italic Bold [4] : Univers Medium [5] : Univers Medium Italic [6] : Univers Bold [7] : Univers Bold Italic [8] : Univers Medium Condensed [9] : Univers Medium Condensed Italic...
  • Page 19 Items Item Number Specification value Default font [30] : Albertus Medium [31] : Albertus Extra Bold [32] : Clarendon Condensed [33] : Coronet [34] : Marigold [35] : Arial [36] : Arial Italic [37] : Arial Bold [38] : Arial Bold Italic [39] : Times New [40] : Times New Italic [41] : Times New Bold...
  • Page 20 Items Item Number Specification value Default [0] : Roman 8 symbol [1] : ISO 8859-1 Latin 1 [2] : ISO 8859-2 Latin 2 [3] : ISO 8859-9 Latin 5 [4] : ISO 8859-10 Latin 6 [5] : PC-8 [6] : PC-8 DN [7] : PC-775 [8] : PC-850 [9] : PC-852...
  • Page 21 Items Item Number Specification value 2 page mode 21 [0] : None [1] : Forward direction [2] : Backward direction Note If horizontal is specified in “Document size”, the result  is the same for both “Forward direction” and “Backward direction”. Blank paper [0] : None ejection...
  • Page 22 Items Item Number Specification value HP-GL mode - [0] : HP-GL [1] : HP-GL/2 Note This affects IW, OW, and UC commands.  If printing HP-GL/2 commands not including BP  commands, specify “HPGL/2”. Hard Clip [0] : Standard [2] : Paper Ejection [0] : OFF command...
  • Page 23 Items Item Number Specification value Form [0] : None composition [1] to [64] : No.1 to No.64 Note Note  This is not  The form name displayed even after the form is reflected deleted after specifying the form. In this case, the form is not composed.
  • Page 24 Items Item Number Specification value Default value [0] to [9999] : 0 to 999.9 mm for user (Short defined side) paper size [0] to [9999] : 0 to 999.9 mm (Long side) Effective [0] : Protocol specification number of [1] : Panel outputs [2] : Command Barcode...

  • Page 25: Direct Print

    Direct Print This function is used to print files directly by using lpr commands, etc. instead of a printer driver. There are two types of PDF direct print, including Adobe genuine PDF direct print and PDF direct print provided by our company (PDF Bridge). Note ®...
  • Page 26 Items Item Number Specification value DocuWorks Print mode [0] : Standard [1] : High speed [2] : High resolution Sort Sort multiple copies by copy (1, 2, 3... 1, 2, 3...). [0] : None [1] : Yes Layout [0] : Auto scale [1] : Catalog (bookbinding) Note [2] : 2 pages...

  • Page 27: Web Applications

    Web Applications This function allows you to access Web servers via networks from the browser included with this machine in order to store or display data.  Access an external service and display an external service screen linked with this machine ...
  • Page 28 Select the server number to register. Enter the server URL and tap on [OK]. Note When connecting by specifying the Web browser version for Web Applications, specify the version  between the protocol type (http, https, etc.) and the colon. For example, enter “http-v4:// www.example.com”...
  • Page 29 Note  Even if you specify [No], user ID and password may be required at the time of access.  If [Remote] is set to > [Device] > [Authentication/Accounting] > [Authentication/Security Settings] > [Authentication] > [Authentication/Accounting Settings], the machine accesses to external services using user information authenticated with the machine after selecting [No].
  • Page 30 Booklet Fold Position Adjustment Confirm the printed sample, measure the misalignment between the folding and staple. Enter the misalignment value by referring to the image on the screen and the folding position is adjusted. Fold Position If the page with the line is longer If the page without the line is longer...

  • Page 31: Folding Position Adjustment

    Folding Position Adjustment Confirm the printed sample, measure the misalignment between the folding and staple (for “Booklet Creation + Staple”). Enter the misalignment value by referring to the image on the screen and the folding position is adjusted. How to Enter the Misalignment Fold Position If the page with the line is longer...
  • Page 32 When Adjusting the Fold to the Any Length You need to enter the value calculated based on measured value and the target value. The calculating method is the following. Value to enter (A) = 210 + (“measured value” - “target value”) Value to enter (B) = “measured value”...

  • Page 33: Troubleshooting

    Troubleshooting If you have an EP-BB MFD management service contract, the machine automatically sends an inspection or repair request to our Customer Support Center as needed. A service representative visits you in response to the notification as required. Machine Trouble Symptom Cause/Remedy The machine is not...

  • Page 34: Image Quality Trouble

    Image Quality Trouble Symptom Cause/Remedy Output is too light The paper is not appropriate for the machine. Confirm the paper tray (faded or unclear). setting and load appropriate paper. The paper is damp. Replace the paper. Change the paper type setting and try printing again. No toner may be left in the toner cartridge.
  • Page 35 Symptom Cause/Remedy Printing can be rubbed off The paper type of the selected paper tray is not appropriate. Change with your finger. the paper type setting and try printing again. Toner is not fused to the Some special types of paper cannot be fused. Replace with the paper.
  • Page 36 Symptom Cause/Remedy White patches appear on Change the paper type setting and try printing again. output. Adjust the image transfer in > [Device] > [Maintenance] > [Image Images are partially Quality] > [Adjust Image Transfer] > [Enter Sample Number and blanked-out.
  • Page 37 Symptom Cause/Remedy There is vertical uneven Log in to Administrator Mode and adjust the uneven density in > density against paper feed [Device] > [Maintenance] > [Image Quality] > [Density Uniformity direction. Adjustment]. For logging in to Administrator Mode, refer to “Logging in to Authentication Mode”...

  • Page 38: Trouble During Copying

    Symptom Cause/Remedy The machine does not If the paper guides are not positioned correctly, the machine may not correctly select a paper correctly detect the size of the paper loaded. Adjust the paper guides tray. to the correct positions. Check whether the tray, paper size and paper type settings on the printer driver properties screen and Control Panel are configured correctly.

  • Page 39: Trouble During Printing

    Symptom Cause/Remedy The color of the document Execute [Calibration]. For details, refer to “[Image Quality]” of and of the copy differ. Reference Guide - Operations. Select an image quality type suitable for the document for [Original Type]. Copy black text. If you feel the printout is too light, select [Text] for [Original Type].

  • Page 40: Trouble During Faxing

    Symptom Cause/Remedy Printing takes too much The receiving buffer capacity may be insufficient. When printing high time. resolution documents, reduce the memory size of unused items in [Allocate Memory] on the Control Panel to increase the receiving buffer capacity. Increasing the receiving buffer capacity may improve the print processing speed.
  • Page 41 Symptom Cause/Remedy Unable to communicate The machine is equipped with multiple connectors to which to connect (general fax). phone lines. Communication is enabled only when the phone line is connected to the correct connector. When the cable connection is correct, the On-hook feature allows you to call via general lines. Use a telephone near the machine to check whether you can make a phone call.
  • Page 42 Symptom Cause/Remedy Unable to communicate The machine cannot print received documents when no paper is set. (general fax). Paper is jammed. Follow the instructions displayed on the Control Panel to remove the jammed paper. The machine cannot receive a fax in the Administrator Mode. Exit the Administrator Mode.
  • Page 43 Symptom Cause/Remedy Unable to communicate Set a correct IP address, subnet mask, and gateway address in the (IP fax (SIP)). machine. Set a correct SIP address in the machine. Set a correct IP address of the SIP server in the machine. Confirm with your network administrator whether the SIP server is operating correctly.
  • Page 44 Symptom Cause/Remedy Unable to communicate Register the correct VoIP gateway on the machine. (IP fax (SIP) via VoIP Confirm with your network administrator whether the VoIP gateway is gateway). working properly. Confirm with your network administrator whether the VoIP gateway settings are correct.

  • Page 45: Trouble During Scanning

    Symptom Cause/Remedy The one-page document You can set the machine to process the received documents by using a is received split into combination of the Auto Reduce on Receipt feature and a border limit multiple pages. value for page splitting. According to the setting combination specified, the received document is printed as follows.
  • Page 46 Symptom Cause/Remedy Unable to send data over Specify [Server] correctly. the network. Specify [Save Location] correctly. When [SMB] is selected, correctly specify [Share Name]. The login name is not entered correctly. Check the login name you enter. The password is not entered correctly. Check the password you enter. The time set on the machine does not agree with that of Windows, when transmission is performed to Windows OS.
  • Page 47 Error Code Remedy Check if the LDAP server used for Login to Remote Accounts is set up correctly. Check that [Attribute of Entered User Name] or [Attribute of Login User Name] is correct. 016, 018, 032, 048, 049, Check the user ID and password and then enter them again. 150, 151 Check if the LDAP server used for Login to Remote Accounts is set up correctly.
  • Page 48 Error Code Remedy Request to your system administrator to check the authentication settings. Change the user ID. 801, 802 Contact your local representative. 1002, 3061 Log out with the Log In/Out button and try again. 3060, 3065 Wait for a while, and then try again. 3062 Log out, hold up the Smart Card, and launch the Smart Card Registration.

  • Page 49: Setting Restore Tool

    Setting Restore Tool This function is used to backup setting data, etc. in computers connected through networks in case data is lost due to the machine's storage malfunction. Download the setting restore tool from our official website. https://fujifilm.com/fbglobal/eng/support 2.8 Setting Restore Tool...

  • Page 50: Job History

    This product contains software consented based on OSS licenses, such as GNU Library General Public License 2.0. If you wish to obtain the source code for the target software based on the OSS license, you can do so from the site below. https://www.fujifilm.com/fb/etc/oss/mfp/apeos_c7070/v1_0 2.10 Job History ...
  • Page 51 SIQA_sheet_A3_simplex...
  • Page 52 SIQA_sheet_A3_simplex...
  • Page 53 SIQA_sheet_A3_duplex...
  • Page 54 SIQA_sheet_A3_duplex...
  • Page 55 SIQA_sheet_11x17_simplex...
  • Page 56 SIQA_sheet_11x17_simplex...
  • Page 57 SIQA_sheet_11x17_duplex...
  • Page 58 SIQA_sheet_11x17_duplex...

This manual is also suitable for:
