FujiFilm ApeosPro C810 Reference Manual

Hide thumbs Also See for ApeosPro C810:

Advertisement

Table of Contents

ApeosPro™ C810
ApeosPro C750
ApeosPro C650
Reference Guide
Appendix
April 2021
GM1037E1-1 Edition1
FUJIFILM Business Innovation Corp.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ApeosPro C810 and is the answer not in the manual?

Questions and answers

Related Manuals for FujiFilm ApeosPro C810

Summary of Contents for FujiFilm ApeosPro C810

  • Page 1 ApeosPro™ C810 ApeosPro C750 ApeosPro C650 Reference Guide Appendix April 2021 GM1037E1-1 Edition1 FUJIFILM Business Innovation Corp.
  • Page 2 Preface A guide describing the emulation mode, direct print, web applications, troubleshooting, etc. This manual may not be edited, modified or copied in whole or in part without the written  consent of the publisher. Parts of this manual are subject to change without prior notice. ...
  • Page 3 Appendix Emulation When using the emulation mode, you can get the print results similar to those of other companies' printers. Set in Internet Services. Refer For details, refer to Internet Services help.  Output of Related List Refer For details, refer to “Basic Operations” in Reference Guide - Operations. ...

  • Page 4: Direct Print

    Allocate Memory Set in > [Device] > [App Settings] > [Print Settings] > [Allocate Memory]. Note If storage is attached, the settings cannot be changed.   [ART IV User Defined Memory] This sets capacity of memory used for user definition with ART IV. The maximum settable value varies depending on the amount of free memory.

  • Page 5: Server Setup

    Server Setup Log in to Administrator Mode. Tap on > [Device] > [App Settings] > [Web Applications Setup] > [Server Setup]. Select the server number to register. Enter the server URL and tap on [OK]. Note  When connecting by specifying the Web browser version for Web Applications, specify the version between the protocol type (http, https, etc.) and the colon.
  • Page 6 Specify the following items as necessary. [Server Name] Specify the displayed name for the connection destination. [URL] Server URL is displayed. [Description] Specify the description for the connection destination. [Use User ID] Specify whether or not to use user ID to access external services. Note ...

  • Page 7: Folding Position Adjustment

    Server Certificate Verification Configure the settings to verify the server certificate when connecting with an external server (ASP) in the same manner as the Windows web browser to prevent phishing attacks. To verify a server certificate, the route certificate (CA certificate) for the route certificate agency issuing the server certificate is used.
  • Page 8 How to Enter the Misalignment Fold Position If the page with the arrow is longer If the page without the arrow is longer ・ ・ Select [Left Side of Fold is Longer] Select [Right Side of Fold is Longer] and enter the amount of and enter the amount of misalignment.
  • Page 9 Fold the sample and the align the positions of printed -> and the counter part of the image on the screen, and the misalignment value among front edge, mountain part and the rear edge of the folded paper. Enter the misalignment value of “+” and “-” (depending on the misalignment direction) by referring to the image on the screen and the mountain folding position is adjusted.
  • Page 10 When Adjusting the Fold to the Any Length You need to enter the value calculated based on measured value and the target value. The calculating method is the following. Value to enter (A) = 210 + (“measured value” - “target value”) Value to enter (B) = “measured value”...

  • Page 11: Operation Mode Setting

    Tel/Fax Switching Kit Note  Depending on the connected telephone line and TA, this may not work normally. When the machine connected to the private branch exchange, confirm whether the electrical  specification is same as it of NIPPON TELEGRAPH AND TELEPHONE CORPORATION (NTT). If it is different from NTT, the function may not work normally.
  • Page 12 Note  To use this function, set “Fax transfer setting” in the DIP switch to “Enable”. This function is available only when you receive a call from the other party.   If the telephone tries to transfer to the fax machine when it starts sending, the beep sounds and the line is cut without transferring.
  • Page 13 Function Setting Operation mode Switches the operation mode. setting Fax priority mode Phone priority Phone-only mode mode Ringing time setting For the fax priority mode or the phone priority mode, set the ringing time when receiving a call. 18 seconds 12 seconds 24 seconds 30 seconds...

  • Page 14: Basic Operations

    Basic Operations When Calling from a Telephone or Fax Machine Call from a telephone or fax machine as usual. Note  When the fax machine is in the line, you can hear the busy sound from the handset. After finishing the fax transmission, call again.

  • Page 15: Problem Solving

    Problem Solving Troubleshooting If you have an EP-BB MFD management service contract, the machine automatically sends an inspection or repair request to your local representative as needed. A service representative visits you in response to the notification as required. Machine Trouble Symptom Cause/Remedy The machine is not...

  • Page 16: Image Quality Trouble

    Image Quality Trouble Symptom Cause/Remedy Output is too light The paper is not appropriate for the machine. Confirm the paper tray (faint/unclear) setting and load appropriate paper. The paper is damp. Replace the paper. Change the paper type setting and try printing again. No toner may be left in the toner cartridge.
  • Page 17 Symptom Cause/Remedy Printing can be rubbed off The paper type of the selected paper tray is not appropriate. Change with your finger. the paper type setting and try printing again. Toner is not fused to the Some special types of paper cannot be fused. Replace with the paper.
  • Page 18 Symptom Cause/Remedy White patches appear on Change the paper type setting and try printing again. output. Images are partially blanked-out. Toner is scattered around images. Images are bluish. Text is smeared. The paper is not appropriate for the machine. Load appropriate paper. The paper is damp.
  • Page 19 Symptom Cause/Remedy There is vertical uneven Log in to Administrator Mode and adjust the uneven density in > density against paper feed [Device] > [Maintenance] > [Image Quality] > [Density Uniformity direction. Adjustment (Perpendicular)]. For logging in to Administrator Mode, refer to “Logging in to Authentication Mode”...

  • Page 20: Trouble During Copying

    Tray and Paper Feed Problems Symptom Cause/Remedy Paper does not feed Load the paper correctly. Before loading heavy media, such as labels or properly. postcards, or envelopes, fan them well to allow air to enter between Paper jams occur. each sheet. Multiple sheets feed at The paper is damp.

  • Page 21: Trouble During Printing

    Symptom Cause/Remedy The copy is dirty. Clean the document cover, document glass, film, or scanner glass. If the document is highly transparent, such as transparencies, place a white sheet of paper on top of the document when scanning. If the document is colored, rough, or a blueprint, the paper’s background color is copied.

  • Page 22: Trouble During Faxing

    Symptom Cause/Remedy Printing takes too much The receiving buffer capacity may be insufficient. When printing high time. resolution documents, reduce the memory size of unused items in [Allocate Memory] on the Control Panel to increase the receiving buffer capacity. Increasing the receiving buffer capacity may improve the print processing speed.
  • Page 23 Symptom Cause/Remedy Unable to communicate The data cannot be sent if the fax machine of the recipient is turned (general fax). off, is set to manual receiving mode, or does not support G3 reception. Paper might have run out or the memory might be full on the recipient’s machine.
  • Page 24 Symptom Cause/Remedy Unable to communicate When a reception password has been set, the machine accepts only (general fax). data or polling fax sent with the correct reception password in F code. The machine is in manual receiving mode. Cancel the manual reception, or set the fax receiving mode to automatic receiving.
  • Page 25 Symptom Cause/Remedy Unable to communicate The machine cannot receive a fax in the Administrator Mode. Exit the (IP fax (SIP)). Administrator Mode. When a reception password has been set, the machine accepts only data or polling fax sent with the correct reception password in F code. Unable to communicate Register the correct VoIP gateway on the machine.

  • Page 26: Trouble During Scanning

    Symptom Cause/Remedy The one-page document You can set the machine to process the received documents by using a is received split into combination of the Auto Reduce on Receipt feature and a border limit multiple pages. value for page splitting. According to the setting combination specified, the received document is printed as follows.
  • Page 27 Symptom Cause/Remedy Unable to send data over Specify [Server] correctly. the network. Specify [Save Location] correctly. When [SMB] is selected, correctly specify [Share Name]. The login name is not entered correctly. Check the login name you enter. The password is not entered correctly. Check the password you enter. The time set on the machine does not agree with that of Windows, when transmission is performed to Windows OS.
  • Page 28 Symptom Cause/Remedy You cannot calling when The telephone and the fax machine connected to this machine is in use. hearing the busy tone Operate after using the telephone and the fax machine. during calling. You cannot calling when While this machine response automatically (maximum for 10 hearing no sound during seconds), busy tone does not sound.

  • Page 29: Setting Restore Tool

    This function is used to backup setting data, etc. in computers connected through networks in case data is lost due to the machine's storage malfunction. Download the setting restore tool from our official website. https://www.fujifilm.com/fb/ License This product contains open source software, for which third parties own the rights (hereinafter referred to as “OSS”).
  • Page 30 SIQA̲sheet1̲A3...
  • Page 31 SIQA̲sheet1̲A3...
  • Page 32 SIQA̲sheet1̲11×17...
  • Page 33 SIQA̲sheet1̲11×17...
