FujiFilm Apeos C8180 Reference Manual

FujiFilm Apeos C8180 Reference Manual

Hide thumbs Also See for Apeos C8180:

Advertisement

Quick Links

Apeos™ C8180
Apeos C7580
Apeos C6580
Reference Guide
Appendix
September 2021
GM1042E1-3 Edition1
FUJIFILM Business Innovation Corp.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Apeos C8180 and is the answer not in the manual?

Questions and answers

Related Manuals for FujiFilm Apeos C8180

Summary of Contents for FujiFilm Apeos C8180

  • Page 1 Apeos™ C8180 Apeos C7580 Apeos C6580 Reference Guide Appendix September 2021 GM1042E1-3 Edition1 FUJIFILM Business Innovation Corp.
  • Page 2 Preface A guide describing the emulation mode, direct print, web applications, troubleshooting, etc. This manual may not be edited, modified or copied in whole or part without the written consent  of the publisher. Parts of this manual is subject to change without prior notice. ...
  • Page 3 Appendix Emulation When using the emulation mode, you can get the print results similar to those of other companies' printers. Overview of Emulation Feature This machine is compatible with following emulation mode. Emulation mode Printer to be emulated ESC/P VP-1000 PC-PR201H PC-PR201H HP-CLJ5500 (color), HP-LJ4200 (black and white)
  • Page 4 Print function Emulation mode N Pages Form Barcode ART IV Up to 2048 ESC/P Up to 64 PC-PR201H Up to 64 HP-GL, HP-GL/2 *1 :In case of no storage, there are up to 64. N Pages 2 pages are available. Form You can register standard forms and print the registered forms by synthesizing them into print data.
  • Page 5 Associated Device Menu Log in to Administrator Mode. Emulation mode [Port Settings] [Allocate Memory] [Delete Form] ART IV ESC/P PC-PR201H HP-GL, HP-GL/2 Port Settings Set in > [Device] > [Network Settings] > [Port Settings].  Enable port (USB/LPD/IPP/Port9100/WSD) Launch the port to be used in the emulation mode. Allocate Memory Set in >...

  • Page 6: A3 A4 A5

    Store/Delete Programming Store the current Items details in [Custom Settings] and delete stored memory. Default Programming Set the default values. HP-GL, HP-GL/2 Emulation-specific Matters Printable area  Margin XR Long side Margin YU (Top right X, Top right Y) Short side (Bottom left X, Bottom left Y) (0,0) Paper size...

  • Page 7: Jis B4

     Margin YU Short side Margin XR (Top right X, Top right Y) Long side (Bottom left X, Bottom left Y) (0,0) Paper size Printable area Paper Paper length Coordinate value (1/7200″) size (1/7200″) Margin Printable area Top right corner Margin direction direction...
  • Page 8 Hard Clip Area determined by coordinates is called Hard Clip area. Hard Clip area is determined by the printable area or paper size.  When the size is A3 and the starting point is the bottom left (16798,11876) Width (16442,11520) Length (0,0) Standard origin (0,0) Paper origin...

  • Page 9: Note

    [Zoom Mode] [Paper Size] Document size is determined based on the drawn object area. Sizes to be determined are A sizes (6 types from A0 through A5). [Coordinate Area] Document size is determined based on the starting point of the drawn object area.
  • Page 10 Item combination examples in Auto Layout  [Zoom Mode]: [Paper Size], [Zoom]: ON Image is reduced/enlarged within the printed area and printed. Paper size Printable area Object area determined in “Area Judgement Mode” Drawn object area ( = Print area) ...
  • Page 11  [Zoom Mode]: [Coordinate Area], [Zoom]: ON Image is reduced/enlarged within the printed area and printed. Paper size Printable area Object area determined in “Area Judgement Mode” Drawn object area ( = Print area)  [Zoom Mode]: [Coordinate Area], [Zoom]: OFF Image is printed in the actual size.
  • Page 12  Determination method example If [Auto Layout] = ON, [Original Size] = [Auto Detect], [Zoom Mode] = [Paper Size], [Area Determine Mode] = [IP] and [Paper Margin] = 10 mm, and [Pen Attributes] of [Pen Width] = 0.1 mm IP-8399,-5938,8399,5938; IW-8399,-5938,8399,5938;...

  • Page 13: Table Of Contents

     If [Original Size] is [Auto Detect] and [Zoom Mode] is [Coordinate Area] Reduction rate is determined by the starting point of the drawn object area and paper size. Hard Clip area is [Normal]. Maximum scale value is 210.0%, and the minimum scale value is 22.5%. Paper 0°...

  • Page 14: Document

    Items Item Number Specification value Document [0] : A0 size [1] : A1 [2] : A2 [3] : A3 [4] : A4 [5] : A5 [10] : JIS B0 [11] : JIS B1 [12] : JIS B2 [13] : JIS B3 [14] : JIS B4 [15] : JIS B5 [99] : Auto...
  • Page 15 Items Item Number Specification value Paper supply [0] : Auto tray [1] : Tray 1 [2] : Tray 2 Note [3] : Tray 3  [4] : Tray 4 number [5] : Tray 5 (bypass) of trays [6] : Tray 6 differs [7] : Tray 7 dependin...
  • Page 16 Items Item Number Specification value Ejected to [0] : Top output tray/Center tray (lower level) [1] : Side tray Note [2] : Center tray (upper level)  [33] to [42] : Mailbox bin 1 to 10 destinati [68] : Stacker on paper [69] : High capacity stacker tray you...
  • Page 17 Items Item Number Specification value Scale mode [0] : Fixed scale [1] : Arbitrary scale [2] : Entire cut paper Note Fixed scale” refers to the scale automatically  calculated based on the specified “Document size” and “Paper size”, and the printable area for the document size is printed to fit within the printable area of the paper size.
  • Page 18 Items Item Number Specification value Alphanumeric [0] : Roman font [1] : Sans-serif [0] : Stroke [1] : Roman [2] : Sans-serif Default font [0] : CG Times [1] : CG Times Italic [2] : CG Times Bold [3] : CG Times Italic Bold [4] : Univers Medium [5] : Univers Medium Italic [6] : Univers Bold...
  • Page 19 Items Item Number Specification value Default font [30] : Albertus Medium [31] : Albertus Extra Bold [32] : Clarendon Condensed [33] : Coronet [34] : Marigold [35] : Arial [36] : Arial Italic [37] : Arial Bold [38] : Arial Bold Italic [39] : Times New [40] : Times New Italic [41] : Times New Bold...
  • Page 20 Items Item Number Specification value Default [0] : Roman 8 symbol [1] : ISO 8859-1 Latin 1 [2] : ISO 8859-2 Latin 2 [3] : ISO 8859-9 Latin 5 [4] : ISO 8859-10 Latin 6 [5] : PC-8 [6] : PC-8 DN [7] : PC-775 [8] : PC-850 [9] : PC-852...
  • Page 21 Items Item Number Specification value 2 page mode 21 [0] : None [1] : Forward direction [2] : Backward direction Note If horizontal is specified in “Document size”, the result  is the same for both “Forward direction” and “Backward direction”. Kanji code [0] : Epson [1] : Toshiba...
  • Page 22 Items Item Number Specification value Page length [0] : 11 inches [1] : 12 inches 1 inch [0] : None perforation [1] : Yes skip Note You can have 1 inch between each page.  This specification is enabled only if “No cut sheet ...
  • Page 23 Items Item Number Specification value Ejection [0] : OFF command (SP) [1] : ON Note (SP0  You can specify the command to indicate the end of drawing. Drawing is ended when the command specified here is  received, and paper is ejected. (NR) ...
  • Page 24 Items Item Number Specification value Form [0] : None composition [1] to [64] : No.1 to No.64 Note Note This is not The form name displayed even after the form is   reflected deleted after specifying the form. In this case, the form is not composed.
  • Page 25 Items Item Number Specification value Line end [0] : OFF process [1] : Add LF at the end [2] : Add CR at the beginning [3] : CR-xx Note With “CR-xx”, add LF at the end when CR and add CR ...
  • Page 26 Items Item Number Specification value Pen color Item Number for No.00 is 950. [0] to [255] : 0 to 255 (color) Note  This setting is valid for color printers. Pen intensity - Item Number for No.00 is 950. [0] to [100] : 0 to 100 (intensity) Note This setting is valid for black and white printers.
  • Page 27 Items Items Item Number Specification value DocuWorks Number of [1] to [999] : 1 to 999 outputs Note  If printing using lpr commands, the specification of the number of outputs is made with lpr commands. Due to this, this setting will be invalid. 2 sided [0] : None [1] : Long side binding...
  • Page 28 Web Applications This function allows you to access Web servers via networks from the browser included with this machine in order to store or display data.  Access an external service and display an external service screen linked with this machine ...
  • Page 29 Select the server number to register. Enter the server URL and tap on [OK]. Note When connecting by specifying the Web browser version for Web Applications, specify the version  between the protocol type (http, https, etc.) and the colon. For example, enter “http-v4:// www.example.com”...
  • Page 30 Note  Even if you specify [No], user ID and password may be required at the time of access.  If [Remote] is set to > [Device] > [Authentication/Accounting] > [Authentication/Security Settings] > [Authentication] > [Authentication/Accounting Settings], the machine accesses to external services using user information authenticated with the machine after selecting [No].
  • Page 31 Folding Position Adjustment Confirm the printed sample, measure the misalignment between the folding and staple (for “Booklet Creation + Staple”). Enter the misalignment value by referring to the image on the screen and the folding position is adjusted. How to Enter the Misalignment Fold Position If the page with the line is longer...
  • Page 32 When Adjusting the Fold to the Any Length You need to enter the value calculated based on measured value and the target value. The calculating method is the following. Value to enter (A) = 210 + (“measured value” - “target value”) Value to enter (B) = “measured value”...
  • Page 33 Tel/Fax Switching Kit This is the optional kit to switch telephone and fax receiving automatically. Note  Depending on the connected telephone line and TA, this may not work normally.  When the machine connected to the private branch exchange, confirm whether the electrical specification is same as it of NIPPON TELEGRAPH AND TELEPHONE CORPORATION (NTT).
  • Page 34 Other Settings Fax Transfer Setting When you receive the fax with the telephone, you can transfer to the fax machine by dialing “*” “*” “*” (“*” for three times) with the telephone. Note To use this function, set “Fax transfer setting” in the DIP switch to “Enable”. ...
  • Page 35 DIP switch Function List ※DIP Switch Settings ：ON ：OFF Operation mode setting Number display/modem dial-in setting Ringing time setting Fax transfer setting Voice response setting Function Setting Operation mode Switches the operation mode. setting Fax priority mode Phone priority Phone-only mode mode Ringing time setting For the fax priority mode or the phone priority mode, set the ringing time...
  • Page 36 Basic Operations When Calling from a Telephone or Fax Machine Call from a telephone or fax machine as usual. Note  When the fax machine is in the line, you can hear the busy sound from the handset. After finishing the fax transmission, call again.
  • Page 37 Cautions for the Power Cut  Only the telephone connected to the TEL terminal is available during the power cut The other features cannot work. Troubleshooting If you have an EP-BB MFD management service contract, the machine automatically sends an inspection or repair request to our Customer Support Center as needed.
  • Page 38 Image Quality Trouble Symptom Cause/Remedy Output is too light The paper is not appropriate for the machine. Confirm the paper tray (faded or unclear). setting and load appropriate paper. The paper is damp. Replace the paper. Change the paper type setting and try printing again. No toner may be left in the toner cartridge.
  • Page 39 Symptom Cause/Remedy Printing can be rubbed off The paper type of the selected paper tray is not appropriate. Change with your finger. the paper type setting and try printing again. Toner is not fused to the Some special types of paper cannot be fused. Replace with the paper.
  • Page 40 Symptom Cause/Remedy White patches appear on Change the paper type setting and try printing again. output. Adjust the image transfer in > [Device] > [Maintenance] > [Image Images are partially Quality] > [Adjust Image Transfer] > [Enter Sample Number and blanked-out.
  • Page 41 Symptom Cause/Remedy There is vertical uneven Log in to Administrator Mode and adjust the uneven density in > density against paper feed [Device] > [Maintenance] > [Image Quality] > [Density Uniformity direction. Adjustment (Perpendicular)]. For logging in to Administrator Mode, refer to “Logging in to Authentication Mode”...
  • Page 42 Tray and Paper Feed Problems Symptom Cause/Remedy Paper does not feed Load the paper correctly. Before loading heavy media, such as labels or properly. postcards, or envelopes, fan them well to allow air to enter between Paper jams occur. each sheet. Multiple sheets feed at The paper is damp.
  • Page 43 Symptom Cause/Remedy The copy is dirty. Clean the document cover, document glass, film, or scanner glass. If the document is highly transparent, such as transparencies, place a white sheet of paper on top of the document when scanning. If the document is colored, rough, or a blueprint, the paper’s background color is copied.
  • Page 44 Symptom Cause/Remedy Printing takes too much The receiving buffer capacity may be insufficient. When printing high time. resolution documents, reduce the memory size of unused items in [Allocate Memory] on the Control Panel to increase the receiving buffer capacity. Increasing the receiving buffer capacity may improve the print processing speed.
  • Page 45 Symptom Cause/Remedy Unable to communicate The machine is equipped with multiple connectors to which to connect (general fax). phone lines. Communication is enabled only when the phone line is connected to the correct connector. When the cable connection is correct, the On-hook feature allows you to call via general lines. Use a telephone near the machine to check whether you can make a phone call.
  • Page 46 Symptom Cause/Remedy Unable to communicate The contract with NTT for the modem dial-in is required to use the (general fax). modem dial-in distribution feature. The machine cannot receive a fax when switched off. Switch the machine power on. The machine cannot print received documents when no paper is set. Paper is jammed.
  • Page 47 Symptom Cause/Remedy Unable to communicate Set a correct IP address, subnet mask, and gateway address in the (IP fax (SIP)). machine. Set a correct SIP address in the machine. Set a correct IP address of the SIP server in the machine. Confirm with your network administrator whether the SIP server is operating correctly.
  • Page 48 Symptom Cause/Remedy Unable to communicate Register the correct VoIP gateway on the machine. (IP fax (SIP) via VoIP Confirm with your network administrator whether the VoIP gateway is gateway). working properly. Confirm with your network administrator whether the VoIP gateway settings are correct.
  • Page 49 Symptom Cause/Remedy The one-page document You can set the machine to process the received documents by using a is received split into combination of the Auto Reduce on Receipt feature and a border limit multiple pages. value for page splitting. According to the setting combination specified, the received document is printed as follows.
  • Page 50 Symptom Cause/Remedy Unable to send data over Specify [Server] correctly. the network. Specify [Save Location] correctly. When [SMB] is selected, correctly specify [Share Name]. The login name is not entered correctly. Check the login name you enter. The password is not entered correctly. Check the password you enter. The time set on the machine does not agree with that of Windows, when transmission is performed to Windows OS.
  • Page 51 Symptom Cause/Remedy You cannot call from a The telephone line is not connected to the LINE terminal of this telephone or fax machine. machine. Connected to the LINE terminal of this machine. The telephone line may have been unplugged. Confirm whether it is connected correctly.
  • Page 52 Symptom Cause/Remedy Even if you dial “*” “*” “*” “Fax transfer setting” is set to “Disabled”. (The factory default is with the telephone, the “Disabled”.) Specify “Enabled”. fax is not transferred to The dial type is set to “DP”. Dial “*” “*” “*” (“*” for three times) after the fax machine.
  • Page 53 Error Code Remedy 081, 091 Check if the LDAP server used for Login to Remote Accounts is set up correctly. Check the Active Directory server is powered on. Check the Active Directory settings. Check that the device is connected to a network. 110, 202, 704 Register again from the beginning.
  • Page 54 Updatings for Add-on Application Trouble Message Measure Unable to connect to A communication error occurred when connecting to the server using server the Internet. Check the following items. Check network settings LAN cable connection  Some services cannot be DNS server address settings ...
  • Page 55 This function is used to backup setting data, etc. in computers connected through networks in case data is lost due to the machine's storage malfunction. Download the setting restore tool from our official website. https://www.fujifilm.com/fb/ License This product contains open source software, for which third parties own the rights (hereinafter referred to as “OSS”).
  • Page 56 2.10 Job History  The page count obtained in the job history and the meters and counters on the machine may not match. Use the acquired data as a guide.  The job history may be lost due to troubles of the machine or due to storage replacement or initialization.
  • Page 57 SIQA_sheet_A3_simplex...
  • Page 58 SIQA_sheet_A3_simplex...
  • Page 59 SIQA_sheet_A3_duplex...
  • Page 60 SIQA_sheet_A3_duplex...
  • Page 61 SIQA_sheet_11x17_simplex...
  • Page 62 SIQA_sheet_11x17_simplex...
  • Page 63 SIQA_sheet_11x17_duplex...
  • Page 64 SIQA_sheet_11x17_duplex...
