ApeosPro C810
ApeosPro C750
ApeosPro C650
User's Manual
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
Some parts of this manual are subject to change without prior notice.
The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending
on the model, the software, or the OS .
Control Panel
„ Features of Control Panel
Pressing the Home button displays the Home
screen.
1.
Power/Power Saving button
The power switches on.
Note
When
Please wait...
"
chine is warming up. The use of machine is
not available during this time.
If the power does not switch on, confirm
that the power plug is inserted.
2.
NFC touch area
This is an area for you to hold up your NFC-supported
mobile devices over. To communicate interactively, the
NFC function of this machine needs to be enabled.
3.
Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine or the fax is stored in a local folder.
4.
Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
5.
Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping on the authentication
information display area logs out the user, and the state
becomes as unauthenticated.
Reference Guides are available on the official website.
Please go to our website then select your country to proceed.
Search the model name of your machine using the search bar on our official website.
Home Button
is displayed, the ma-
"
https://fujifilm.com/fbglobal/eng/support
[Apps]
5
1
6
[Pause]
2
3
4
6.
Opening menu
Tap this to open the menu for change and check of the
settings of the machine.
Tap on [<] to close the menu.
7.
Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]
: You can tap on any of the application icons
and use its functions.
• [Pins]
: You can execute a job again using Job Direc-
tion History and the job direction history of which pin
is created with [Create Pin] by user. If you create a
pin of the job direction history, you can also directly
activate a job without opening an application.
• [Address]
: You can register addresses and other
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
April 2022 GM1525E2-1 Edition 1
[Pins] [Address]
7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ApeosPro C810 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FujiFilm ApeosPro C810

  • Page 1 ApeosPro C810 Reference Guides are available on the official website. ApeosPro C750 Please go to our website then select your country to proceed. ApeosPro C650 Search the model name of your machine using the search bar on our official website.
  • Page 2 Executing the Job from the Pinned Job „ Switching the Power Off Direction History When the power is switched off, all the machine functions are stopped. On the [Pins] screen, tap on at the right Important side of the pinned job and tap on [Start Do not switch the power off when the machine is in Now].
  • Page 3: Loading Paper

    Loading Paper Pinch the guide clip(s) and adjust to the correct paper size. Important Do not place paper or other objects in the reserved ■ space of the tray. It may cause paper jams or ma- chine malfunction. While the printer is processing a job, do not remove ■...
  • Page 4: Document Feeder

    Copy/Fax/Scan Document Glass Loadable paper Set the document. Paper size (mm) Width: Up to 297 Multiple Length: Up to 432 1 sheet sheets Open the Document Cover, and wipe off any dirt from the Document Glass. Document Feeder Loadable paper Paper size (mm) Width: 84 to 297 Length: 140 to 432...
  • Page 5 On the [Apps] screen, tap on the desired Application icon. Copy Scan Copy As needed, configure the setting items. Enter by the keyboard or by tapping on the Address Book ( ) or Redial ( ) to specify the recipient. Tap on [Start].
  • Page 6: Safety Notes

    Safety Notes „ Electrical Safety WARNING Before using this product, read “Safety Notes” carefully for safety use. This product shall be operated by the power source as indi- cated on the product's data plate. Consult your local power This product and recommended supplies have been tested company to check if your power source meets the require- and found to comply with strict safety requirements includ- ments.
  • Page 7: Minimum Configuration

    „ Machine Installation „ Operational Safety WARNING WARNING Do not locate this product where people might step The operator s product maintenance procedures are ’ on or trip over the power cord. Friction or excessive described in the manuals supplied with this product. pressure may generate heat and eventually cause Do not carry out any other maintenance procedures electric shock or a fire accident.
  • Page 8 Never touch safety interlocks. When a front cover is CAUTION open, safety interlocks become activated to stop the machinery. Do not apply pressure on safety inter- Always follow all warning instructions marked on or locks with a coin or screwdriver. Otherwise, the machinery supplied with this product.
  • Page 9 „ Other WARNING This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. „ Regulation Shielded interface cables must be used with this product to maintain compliance with EMI standard.
  • Page 12 More online support options..TO ACCESS MORE ONILNE SUPPORT OPTIONS Please go to our website, https://fujifilm.com/fbglobal/eng/support and then select your country to proceed. „ Drivers & Utilities ACCESS THE LATEST PRODUCT SUPPORT TOOLS ONLINE Fully tested printer drivers, utilities and software patches are available for our products.
