TE100-S16plus
16-port 10/100Mbps NWay Switch (Rack Mount)
TRENDnet's TE100-S16plus is a high performance, auto-
sensing 16-port NWay rack-mountable Fast Ethernet Switch.
It is designed to eliminate unnecessary traffic and relieve
congestion on critical network paths. With 10/100Mbps NWay
technology, the TE100-S16plus automatically negotiates
between 10Base-T and 100Base-TX network speeds, as well
as half and full duplex modes. The TE100-S16plus also has a
module bay for optional multimode SC type fiber module that
allows connection to another fiber device up to 2Km away (in
full-duplex mode). Supporting "Port Trunking" and Quality of
Service (QoS), TRENDnet's TE100-S16plus is the perfect
solution for network backbone and multimedia applications.
FEATURES
16 10/100Mbps NWay half/full duplex MDI-X ports
One Uplink port (shared) with port 8
Integrate address Look-Up Engine, supports up to 16K
absolute MAC address
Support three QoS levels; checked via IP Header, 802.1Q
VLAN Tag, and/or selected per-port basis
Supports trunking function; max. of 8 trunk ports are
available with max. 1.6Gbps trunking bandwidth
512KB internal RAM for frame buffering § Wire-speed
filtering/forwarding rates
IEEE 802.3x flow control for full-duplex mode; Back
pressure flow control for half-duplex mode
Store-and-forward switching method
Extensive front-panel diagnostic LEDs
One module bay for optional one-port 100Base-FX
multimode SC type fiber connection
5 Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Performance:
Port Trunking function creates up to
1.6Gb fat pipe between two Switches.
QoS Support improves network
multimedia applications' performance.
Expandability:
Optional 100Base-FX module links to
other fiber device up to 2Km (full-
duplex).
Flexibility:
The NWay ports automatically
negotiate between 10Base-T and
100Base-TX network speeds as well
as between half- and full-duplex
modes.
Cost Effectiveness:
Provide 10/100Mbps of Fast Ethernet
at an affordable rate.
Performance:
Top performance at an affordable
price.
TE100-S16plus (11-17-2002)
