Summary of Contents for TRENDnet TE100-S5
- Page 1 Switch 10/100Mbps à 5 ports (TE100-S5) Switch 10/100Mbps à 8 ports (TE100-S8) Ÿ Guide d'installation rapide (1) Ÿ Quick Installation Guide (3) Ÿ Technical Specifications [5] Ÿ Dépannage (6) Ÿ Troubleshooting [7) 1.22...
-
Page 2: Contenu De L'emballage
Ÿ Vérifiez la présence d'une source de ventilation adéquate autour du Switch pour une dissipation efficace de la chaleur Ÿ Ne placez pas d'objets lourds sur le Switch 2. Installation du matériel 1. Branchez le transformateur au TE100-S5/TE100-S8 ainsi qu’à une prise de courant. - Page 3 2. Branchez un câble réseau Cat.5, Cat.5e ou Cat.6 RJ-45 de l'ordinateur vers un port Ethernet disponible du TE100-S5/TE100-S8. 3. LEDs Puissance Ÿ Vert : Sous tension Ÿ Eteint : Hors tension Link/ACT Ÿ Vert (Fixe) : La connexion pour le port est de 100/200 Mbps (Half/Full) ou 10/20Mbps (Half/Full) Ÿ...
-
Page 4: Package Contents
Make sure that there is proper heat dissipation from the switch and adequate ventilation around the switch Ÿ Do not place heavy objects on the switch 2. Hardware Installation 1. Connect the Power Adapter to the TE100-S5/TE100-S8 and then to a power outlet. - Page 5 2. Connect a CAT-5, CAT-5e or CAT-6 RJ-45 network cable from the computer to an available Ethernet port on the TE100-S5/TE100-S8. 3. LEDs Power Ÿ Green: Power is on Ÿ Not Illuminated: Power is off Link/ACT Ÿ Green (Solid): Connection for the port is 100/200Mbps (half/full) or 10/20Mbps (half/full) Ÿ...
-
Page 6: Technical Specifications
Technical Specifications TE100-S5 TE100-S8 Standard IEEE 802.3 10Base-T Ÿ IEEE 802.3u 100Base-TX Ÿ IEEE 802.3x Flow Control Ÿ Network Media Ethernet: Cat. 5 up to 100m Ÿ Fast Ethernet: Cat. 5, 5e, 6 up to 100m Ÿ Ethernet: 10Mbps/20Mbps (Half/Full-Duplex) Ÿ... -
Page 7: Dépannage
1. Les voyants ne s'allument pas lorsque le Switch est branché sur le secteur. 1. Vérifiez que l'adaptateur d'alimentation externe du TE100-S5/TE100-S8 est bien branché à la prise de courant. 2. Vérifiez également que la prise murale est sous tension 2. -
Page 8: Troubleshooting
Troubleshooting 1. After connecting the Switch to a power outlet, the LEDs do not turn on. 1. Check the connection of the power adapter to the TE100-S5/TE100-S8 and the power outlet. 2. Check that the power outlet is receiving power. - Page 10 TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment.
- Page 11 ("LGPL"). Go to http://www.trendnet.com/gpl or http://www.trendnet.com Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt or http://www.gnu.org/licenses/lgpl.txt for specific terms of...
- Page 12 TRENDnet 20675 Manhattan Place Torrance, CA 90501. USA Copyright ©2011. All Rights Reserved. TRENDnet.
