Preface

This manual describes how to install and use 16/24 port
Ethernet switch, TE100-S1616V/TE100-S2424V. It features
16/24 ports that auto negotiate the presence of 10/100Mbps
and full or half-duplex mode. An optional 100BASE-FX
multi-mode or single -mode module enables long-distance
connection. An optional BNC module enables backwards
compatibility.
To get the most out of this manual, you should have an
understanding of networking concepts such as bridging, IEEE
802.3 Ethernet and 100BASE-TX Fast Ethernet, and local area
networks (LAN).
For more information about these topics, please refer to the
Appendices.
In this manual, you will find:
Benefits of Ethernet switches
Features of TE100-S1616V/TE100-S2424V
LED functions illustration
Installation instructions
Configuration instructions for VLAN and port speed
Specifications
Ethernet technology, LAN, and VLAN tutorial information

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TE100-S1616V and is the answer not in the manual?

Questions and answers

Related Manuals for TRENDnet TE100-S1616V

Summary of Contents for TRENDnet TE100-S1616V

  • Page 1: Preface

    -mode module enables long-distance connection. An optional BNC module enables backwards compatibility. To get the most out of this manual, you should have an understanding of networking concepts such as bridging, IEEE 802.3 Ethernet and 100BASE-TX Fast Ethernet, and local area networks (LAN).

  • Page 2: Table Of Contents

    Benefits of Switching................3 TE100-S1616V/TE100-S2424V ............4 Product Features..................5 Packing List...................7 Ports....................10 LED Indicator.................13 Installation..............18 Selecting a Site for the Switch............18 Connecting to Power................20 Connecting to Your Network........20 Optional Module Installation............23 Jumper Settings ................24 Switch Configuration..........26 Setting up Console Port Connection..........27 VLAN ....................31 Port Setting...................35...

  • Page 3: Introduction

    It further eliminates congestion problems inherent to the CSMA/CD protocol and improves predictable response time under heavy network loads. Expensive routing equipment was used in the past to reduce the congestion under heavy loads. The new wave of object-oriented client and server applications demands higher bandwidth and tighter integration of client workstations with servers.

  • Page 4: Te100-S1616V/Te100-S2424V

    10 Base-T Ethernet installed Base. This compatibility ensures a path for users to add, change, and migrate to Fast Ethernet as demands emerge. It also provides a low cost and flexible bandwidth solution directly to local workgroups where the majority of work is generated, reducing the need for expensive network equipment.

  • Page 5: Product Features

    This switch represent the newest generation in Ethernet switching technology by supporting both 10Mbps and 100Mbps speed and half or full duplex transmission modes on the same port. By using standard auto-negotiation, it provides a cost-effective way of integrating legacy 10Mbps segments with 100Mbps Fast Ethernet networks and an ideal solution for extending the distance between two 100Mbps network segments.
  • Page 6 - Supports 2K MAC address - Port based VLAN - Programmable re-configuration for fixed speed and duplex modes - One uplink port activated by the push of a button - Front panel reset button - Front panel status LEDs - Standard 19" rack-mount size...

  • Page 7: Packing List

    Packing List When you unpack this product, you should find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. TE100-S1616V or TE100-S2424V User’s Guide AC power cord Rack Mount Ears with screws Serial Cable User’s Guide...

  • Page 8: Front Panel

    Front Panel The front panel of this switch has 16 or 24 ports, one slot for an optional fiber or BNC module and an array of LED indicators to provide you with instant feedback on the status of the switch.
  • Page 9 User’s Guide...

  • Page 10: Ports

    100 meters with Category 5 unshielded twisted-pair (UTP) cable. A 10BASE-T network may range up to 100 meters with Category 3, 4, or 5 UTP cable. As for the length of fiber link between a switch and a Data Terminal Equipment, it is capable to span at least 2 kilometers (1.24 Mile) using 62.5/125-micron multi-...
  • Page 11 15 kilometers using 9 micron single-mode fiber optic cable. User’s Guide...
  • Page 12 Speed Connector Port Speed Cable Distance Half/Full Duplex 10BASE-T RJ-45 10/20 Category 3, Mbps 4, or 5 UTP meters 100BASE- RJ-45 100/200 Category Mbps meters 100BASE- 100/200 62.5/125 2 km MT-RJ, Mbps micron VF-45 multi-mode fiber 100BASE- 100/200 micron 15 km...

  • Page 13: Led Indicator

    LED Indicator The array of LED indicators on the front panel conveys status and configuration information to help you monitor and trouble-shoot the switch. RESET POWER 24 port 10/100 switch 10 11 12 13 14 15 16 LNK/ACT FDX/COL EXTENSION SLOT...
  • Page 14 Figure 3: LED Indicator User’s Guide...
  • Page 15 1X to 16X on TE100-S1616V or three segments of eight ports numbered from 1X to 24X on TE100-S2424V. The LEDs are located at the left side of each segment, display status for each respective port. Consult the following chart for clarification.
  • Page 16 Affects port 16X on TE100-S1616V or port 24X on TE100-S2424V only. ? Optional Module LEDs Status A set of three LEDs displays the status of the optional modular port. Consult the following chart for clarification. Table 2: Optional module port status...
  • Page 17 10Mbps: The port has established a Steady valid network connection 10/RX Flashing The port is receiving data The connection is in full duplex Steady FDX/COL mode Flashing The port is receiving data User’s Guide...

  • Page 18: Installation

    (3V/M) field strength. Make sure that the switch receives adequate ventilation. Do not block the ventilation holes on the side of the switch or the fan exhaust port on the rear of the switch. The power outlet should be within 1.8Meter of the switch.
  • Page 19 User’s Guide...

  • Page 20: Connecting To Power

    Connecting to Power Connect the supplied AC power cord to the receptacle on the back of the switch, and then plug the cord into a standard AC outlet with a voltage range from 100 to 240 VAC. Turn the switch on by flipping the ON/OFF switch on the rear of the unit to the I (ON) position.
  • Page 21 When the uplink button is pressed down, port 16X on TE100- S1616V or port 24X on TE100-S2424V can be used to connect to any regular port of another hub or switch using a regular straight through twisted pair cable. To connect two regular RJ -45 ports between any switches or hubs, you need a cross-wire cable.
  • Page 22 Category 5 shielded twisted-pair or unshielded twisted-pair (STP/UTP) cable for 100BASE-TX, or Category 3, 4, or 5 STP/UTP cable for 10BASE-T. User’s Guide...

  • Page 23: Optional Module Installation

    SC, ST, MT-RJ or VF-45 connector. The optional module should be inserted into the extension slot located at the right side of the switch. Port 16X (for TE100- S1616V) or port 20X (for TE100-S2424V) will be automatically disabled when optional module is installed.

  • Page 24: Jumper Settings

    Figure 4: Removal of cover plate Figure 5: Module being installed Jumper Settings The module arrives with pre-set jumpers and should not be reset. User’s Guide...
  • Page 25 Figure 6: Proper jumper settings for fiber module (BNC connection does not have a jumper) User’s Guide...

  • Page 26: Switch Configuration

    A serial cable is provided with the switch. Use it to connect the console port at the back of the switch and a COM port on the computer. Information on next page explains steps for setting up the console port connection.

  • Page 27: Setting Up Console Port Connection

    Check the switch, cables, and computer; make sure they are functioning properly before the configuration. Attach a PC or any VT100 compatible terminal to the console port on the back of the switch (see figure 7) using the following settings: Terminal type VT100...
  • Page 28 Figure 7: Console Port After DOS or Hyper Terminal programs have been set up properly, turn on the switch, use terminal program to connect to the switch and press any key to view the main menu shown below: 24-port 10/100 Base Ethernet Switch...
  • Page 29 FLW = Flow Control This main menu shows you the default configuration of the switch. By default, all ports are set at auto-negotiation, flow control on, and all ports are grouped into V1 (VLAN group 1). These are the valid commands:...
  • Page 30 Abort the menu at any time Note: [Esc] will not function when you are in the Trunking Menu. In the Trunking setup menu, you must select trunk “a” or “b”. To cancel the trunking selection, select “D” at main menu to restore to default settings.

  • Page 31: Vlan

    The resulting security is yet another reason to use VLAN. This switch is able to support up to four port-based Virtual LAN (VLAN) domains. Follow these steps to assign ports to a VLAN group.
  • Page 32 Only one VLAN group can be defined at a time. Repeat the steps until all ports are assigned to at least one VLAN group. Though each VLAN grouping does not need to be utilized, each port must be assigned to at least one VLAN group. Hit the [ESC] key when done.
  • Page 33 Note: Until assigned, the menu displays **error** for each unassigned port. While any port is in the **error** status, the [ ESC] key will not return the screen to the main menu. Assign each port to a VLAN grouping prior to exiting program.
  • Page 34 View the results on the following illustration. 24-port 10/100 Base Ethernet Switch VLAN Port List V1, 1,2,3,8,10,14,15,17,18,19,20,22,24 V2, 1,4,5,6,8,12,13,19,21,23 V3, 1,7,9,11,16,19,21,23 V4 < empty > Port Mode VLAN Port Mode FLW VLAN Auto V1 V2 V3 Auto Auto Auto Auto...

  • Page 35: Port Setting

    When connecting the Switch to legacy networking equipments, it may be necessary to disable auto-negotiation and flow control. This can be done by selecting “M” at the terminal mode main menu and then select the desire port speed, duplex mode, and flow control on /off.
  • Page 36 The sending station will wait the requested time before sending more data. The receiving station can also send a frame back to the source with a time-to-wait of zero and instruct the source to begin sending data again.
  • Page 37 100HD 100Mbps at half duplex mode 10FD 10Mbps at full duplex mode 10HD 10Mbps at half duplex mode User’s Guide...
  • Page 38 Example: Enter [M] Select port 6 Select communication media 5 View the results on the following illustration. 24-port 10/100 Base Ethernet Switch VLAN Port List V1, 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24 V2 < empty > V3 < empty> V4 < empty > Port Mode...
  • Page 39 Auto Auto Auto Auto V2 V3 Auto Auto VLAN/Mode/Trunking/Default (V/M/D) ? User’s Guide...
  • Page 40 20 (for TE100-S2424V) will be automatically disabled. However, on the switch configuration program, port #16 or #20 will show status of the optional module. The port setting for the optional module is slightly different from the regular port.

  • Page 41: Trunking

    Trunking is a method of physically links several ports together to act as a single port with higher bandwidth. This switch offers you the choices of 2 ports or 4 ports trunking. Follow these steps to configure trunking. Enter [T] Select [A] for 2-port trunking or select [B] for 4-port trunking View the results on the following illustration.

  • Page 42: Networking Examples

    Auto Auto Auto Auto Auto Auto Auto Auto Auto Auto Networking Examples 200Mbps 10Mbps Full-duplex Full-duplex Fast Ethernet Half-duplex Fast Ethernet Server Ethernet Printer server Workstation Workstation Figure 8: High-speed connections for a small workgroup User’s Guide...
  • Page 43 10Base-T Hub 10Mbps 200Mbps 200Mbps 100Mbps 100Mbps 10Mbps 100Base-TX Hub 10Base-T Hub Server 1 Server 2 Figure 9: Collapsed backbone for workgroups User’s Guide...
  • Page 44 User’s Guide...

  • Page 45: User's Guide

    100Base-TX Hub 10Base-T Hub 10Mbps 100Mbps 10Mbps 100Mbps 10Base-T Hub 100Base-TX Hub Figure 10: Bridging existing hub-based 100BASE-TX and 10BASE-T network User’s Guide...

  • Page 46: Specifications

    16/24 10/100-BASE-T/TX 200Mbps full-duplex Speed 100BASE-FX: 100Mbps half-duplex 200Mbps full-duplex 100BASE-TX: 100Mbps half-duplex 10BASE-TX: 20Mbps full-duplex 10Mbps half-duplex Performance 148,800bps forwarding rate per port for 100Mbps. Power, Link, Activity, 100Mbps, Full-duplex, Indicators Collision Module 100/TX, 10/RX, FDX/COL Indicators User’s Guide...
  • Page 47 Dimensions 440 X 205 X 45 mm Rackmount Size 17.3 X 8.1 X 1.8 inch Rackmount Size Weight 2.8kg 6.2lb Power Input 100 ~ 250 Vac, 47/63 Hz, 2 A Power 20 W Consumption Operating 0° ~ 40°C Temperature 32° ~ 104°F...

  • Page 48: Appendix A - Connector Pinouts

    Appendix A - Connector Pinouts Pin arrangement of RJ-45 connectors Figure 11: RJ-45 Connector and Cable Pins The following table lists the pinout of 10/100BASE-T/TX ports Table 4: Connector Pin-Out Regular Ports Uplink port Input Receive Data + Output Transmit Data +...

  • Page 49: Appendix B - Introduction To Lan & Ethernet Technologies

    LAN connects personal computers, file servers, printers, etc. together within a geographical area, usually a single building. Multiple, widely dispersed LAN systems are referred to as a wide area network (WAN).
  • Page 50 More than 80 percent of all LANs utilize Ethernet technology. The Institute of Electrical and Electronic Engineers (IEEE) standardized Ethernet in IEEE 802.3, which provides for configuration rules, interaction requirements, types of media, and data rate. User’s Guide...
  • Page 51 For networks that need higher transmission speeds, a faster speed was developed and IEEE next established IEEE 802.3u, raising the Ethernet speed from 10 Mbps to 100 Mbps. Thus, fast Ethernet arose and users quickly began converting from 10Mbps to 100Mbps.
  • Page 52 One of the earlier connection solutions for Ethernet, a hub (also called a repeater) operates by broadcasting data to all ports simultaneously, only to repeat it when it is not received. The hub works through a “shared network” with all of the nodes in the network segment sharing the same collision domain.
  • Page 53 The store-and forward switch eliminates redundant or corrupted packets, thus increasing the efficiency of the network transmission. User’s Guide...

  • Page 54: Appendix C - Vlans

    Virtual local area network (VLAN) is a network configuration in which nodes are grouped into logical, rather than physical networks. Figure 12 & 13 below shows the difference between LAN and VLAN. The segmentation in VLAN creates secured areas where...
  • Page 55 VLAN 1 VLAN 2 Figure 13: VLAN Segmentation User’s Guide...
