Summary of Contents for Bosch MIC550 IR

  • Page 1 MIC Series 550 MIC550, MIC550 IR...
  • Page 2 Operation Manual...

  • Page 3: Table Of Contents

    13.3 Controlling the Camera 13.3.1 Basic Keyboard Operation 13.3.2 Navigating the On-Screen Display (OSD) Menus 13.3.3 Keyboard Commands, Bosch Protocol 13.3.4 Keyboard Commands, Pelco Protocol 13.3.5 Special Preset Commands, Pelco Protocol 13.4 About Setting the Camera Address via FastAddress 13.5 FastAddress, Bosch Protocol Bosch Security Systems, Inc.
  • Page 4 MIC Series 550 13.6 FastAddress, Pelco Protocols 13.7 Setting Passwords 13.7.1 Special Passwords 13.7.2 Setting Passwords, Bosch Protocol On-Screen Display (OSD) Menus (Bosch Protocol) 14.1 Camera Setup Menu 14.2 Lens Setup Menu 14.3 PTZ Setup Menu 14.4 Display Setup Menu 14.5...

  • Page 5: Safety

    Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.

  • Page 6: Important Notices

    – Do not point the camera at the sun. Bosch Security Systems will not be liable for any damage to cameras that have been pointed directly at the sun. –...
  • Page 7 Please dispose of these devices at your local communal waste collection point or at a recycling center. Environmental statement - Bosch has a strong commitment towards the environment. This unit has been designed to respect the environment as much as possible.
  • Page 8 The power supplies have an IP65 rating and are suitable for outside installation; however, for security reasons, Bosch recommends that they are installed in a suitable equipment cabinet. The camera is sealed to IP68 and can be used safely in damp environments or outdoors, as long as the base cable connector is suitably sealed.
  • Page 9 Commission fédérale des communications des États-Unis (FCC). Ces contraintes sont destinées à fournir une protection raisonnable contre les interférences nuisibles quand l'appareil est utilisé dans une installation commerciale. Cette appareil génère, utilise et émet Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 10: Customer Support And Service

    REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT. Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Service Centers...
  • Page 11 MIC Series 550 Safety | en More Information For more information please contact the nearest Bosch Security Systems location or visit www.boschsecurity.com Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 12: Unpacking

    Verify that all the parts listed in the Parts List below are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. – Do not use this product if any component appears to be damaged. Please contact Bosch Security Systems in the event of damaged goods. –...

  • Page 13: Additional Tools Required

    Power Supply Unit (PSU) for MIC IR cameras MIC-IR-115PSU-UL, MIC-IR-24PSU-UL Additional Tools Required The following table lists additional tools (not supplied by Bosch) that are or may be required to install a MIC camera: Quantity Part 13 mm wrench for the mounting bolts...

  • Page 14: Product Description

    Washer kit for IR models, containing mounting bracket and nozzle. (The washer pump drive card is built into the power supply for IR models.) MIC-BP3 Bosch Biphase converter card for MIC power supplies without an available expansion slot. MIC-BP4 Bosch Biphase converter card for MIC power supplies with an available expansion slot.

  • Page 15: Electrical Connections

    25 m between the MIC camera and the MIC power supply. For installations that require the camera to be more than 25 m from the power supply, Bosch recommends that a 2 m cable be connected to a junction box (Exd rated for MIC440) from which telemetry, video, and power can be broken out into separate cables and appropriate wiring used to extend the distance to suit.
  • Page 16 Half Duplex Tx/Rx A Full Duplex Rx B+ Telemetry I/O to RS-422/485 White Half Duplex Tx/Rx B Power Input 2 Low Voltage Power Input Green Power Input 1 Low Voltage Power Input 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 17: Overview Of Installation Steps

    (NEC)), Canadian Electrical Code, Part I (also called CE Code or CSA C22.1), ® and all applicable local codes. Bosch Security Systems, Inc. accepts no liability for any damages or losses caused by incorrect or improper installation. To install your MIC camera, follow these steps in sequence.

  • Page 18: Select The Mounting Location And Orientation

    MIC Series cameras are designed for easy installation in various locations such as directly onto buildings and dedicated CCTV poles. Bosch sells a complete series of mounting brackets designed to allow the camera to achieve the optimal field of view.
  • Page 19 1 mounting plate], Shallow Conduit Adapter (MIC-SCA), and Wall Mount Bracket (MIC-WMB)) Figure 6.2: Typical wall mount (from left: Wall Mount Bracket (MIC-WMB), Shallow Conduit Adapter (MIC- SCA), and Spreader Plate (MIC-SPR)) Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 20: Select The Mounting Location

    Figure 6.3: Typical corner mount (from left: Wall Mount Bracket (MIC-WMB), Shallow Conduit Adapter (MIC-SCA), and Corner Mount Bracket (MIC-CMB)) Warning! To minimize the potential for corrosion on the housing, use only Bosch hardware and mounts. Select the Mounting Location 1. Select the mounting location.

  • Page 21: Select The Mounting Orientation

    If the camera is installed in a highly exposed location where lightning strikes may occur, then Bosch recommends installing a separate lightning conductor within 0.5 m (1.6 ft) of the camera and at least 1.5 m (4.9 ft) higher than the camera. A good earth bonding connection to the camera housing itself will provide protection against damage from secondary strikes.

  • Page 22: Mount The Camera

    Screw the cable connector sleeve onto the plug until it is secured firmly (approximately four (4) turns from the start of thread engagement). 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 23: Earthing The Camera

    The PSU "Earth Link" may be used for this purpose. – If dual earthing is unavoidable, then a video isolation transformer should be fitted between the two earths. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 24: Finalize Camera Mounting

    The upright unit can be mounted either with the camera ball up or down. So that the picture from a camera installed with the camera ball down appears properly, rotate the camera tilt axis 180°. For more information, see Configuring the Camera for Inverted Operation. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 25: Cant The Camera

    180° around. The top part of the camera will now be at a 45° angle (canted). Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...
  • Page 26 Do not stand the canted (45°) MIC Series 550 / MIC Series 550 IR camera upright (on the camera base or, if mounted to a DCA, with the DCA base upright)! It is unstable unless properly mounted. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 27: Reverse The Rain Shield For Inverted Operation

    Two screws are on the left of the rain shield; two screws are on the right of the rain shield. Figure 11.2: Screw removal Reverse the rain shield. Reattach the rain shield to the camera face. Figure 11.3: Inverted rain shield installed on camera Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 28: Install The Mic (Standard) Psu

    Use only the power supply specified for your specific model of camera. Bosch provides a range of power supply units (PSUs) for MIC Series cameras. These units have a variety of common voltages and provide all the connections needed for power, telemetry and video.

  • Page 29: About The Mic Shielded Composite Cable

    25 m between the MIC camera and the MIC power supply. For installations that require the camera to be more than 25 m from the power supply, Bosch recommends that a 2 m cable be connected to a junction box (Exd rated for MIC440) from which telemetry, video, and power can be broken out into separate cables and appropriate wiring used to extend the distance to suit.

  • Page 30: Alarm Inputs

    8-input alarm card is installed. MIC PSU 8-input Alarm Card Number of Number of (MIC-ALM)? Alarm Inputs Alarm Outputs MIC-24PSU-2, MIC-115PSU-2, MIC-240PSU-2 Table 12.3: Number of alarm inputs and outputs in MIC PSUs 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 31: Simultaneous Ip And Analog Video/Control ("Hybrid" Operation)

    Connection between BNC T-connector and Bilinx-based control (head-end) system Connection between Bilinx-based control (head-end) system and Local Area Network (LAN) (or the "cloud") Connection between the Local Area Network (LAN) and PC connected to video monitor Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 32: Getting Started

    The MIC Series 550 / MIC Series 550 IR supports two communication protocols (Biphase and RS-485), and both Bosch and Pelco D and P (keyboard) controller protocols that allow you to send commands to the camera and to receive information from the camera.

  • Page 33: Powering On

    120 Ω Caution! Bosch recommends that multiple RS-485 connections be arranged as a connected series of point-to-point (multidropped) nodes, as a line or as a bus. It is not recommended to arrange RS-485 connections as a star, ring, or as a multiple-connected network. Star and ring topologies may cause signal reflections or excessively low or high termination impedance.

  • Page 34: Navigating The On-Screen Display (Osd) Menus

    Note: To select the Exit Menu item from anywhere in the current menu, use the Zoom command. 13.3.3 Keyboard Commands, Bosch Protocol Keyboard control commands are composed of a sequence of three (3) inputs with the following convention: 1) a Function key + 2) a Command number key(s) + 3) the Enter key.

  • Page 35: Keyboard Commands, Pelco Protocol

    For example, the keyboard command to make the camera pan 360º continuously is: ON-1-ENTER (Press the ON key, then press the number 1 key, and then press ENTER.) Refer to Keyboard Commands (Bosch Protocol) By Number for a complete list of commands. 13.3.4...

  • Page 36: Special Preset Commands, Pelco Protocol

    Starts an AutoScan. Notice! Some Pelco controllers do not support all of the preset command numbers. Refer to the documentation of the specific Pelco controller for supported preset commands. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 37: About Setting The Camera Address Via Fastaddress

    FastAddress is stored in nonvolatile memory and does not change if the power is turned off or if the default settings are restored. 13.5 FastAddress, Bosch Protocol In Bosch protocol, there are three (3) FastAddress commands: – ON-999-ENTER: Displays and programs all cameras without an address in the system. Notice! If a keyboard is set to a camera number that already has an address, that camera also responds to this command.

  • Page 38: Setting Passwords

    9999 Disables all security and allows all users to access locked commands. 13.7.2 Setting Passwords, Bosch Protocol To set or change a password (locked command): Press OFF-90-ENTER to turn off the command lock. Press SET-802-ENTER to access the password menu.

  • Page 39: On-Screen Display (Osd) Menus (Bosch Protocol)

    On-Screen Display (OSD) Menus (Bosch Protocol) This chapter identifies and describes each OSD menu option, as well as the default setting for each option, for Bosch protocol. For step-by-step instructions, see Common User Commands (unlocked) and Advanced Features. To open the main Setup Menu in Bosch protocol: (locked commands) Press OFF-90-ENTER to turn off the command lock.
  • Page 40 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 Setup Menu Choices: Menu Description Exit Exits the menu. Camera Setup Accesses adjustable camera settings such as: white balance, gain, sharpness, sync, line lock, backlight, shutter, and night mode.

  • Page 41: Camera Setup Menu

    MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en 14.1 Camera Setup Menu The Camera Setup Menu contains settings that can be changed/customized for the optical (visible) camera. Camera Setup Exit... * White Bal: EXT ATW * Gain Control:...
  • Page 42 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 White Bal Maintains proper color reproduction (white balance) as the color temperature of a scene changes (for example, from daylight to fluorescent lighting). Option Description Extended ATW (Default setting) Adjusts camera color using extended range.

  • Page 43: Lens Setup Menu

    MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en Sets the limit for sensitivity when the shutter speed is set to Auto SensUP. Options: 2x, 4x, 7.5x, 15x (default setting). Night Mode Selects night mode (B/W) to enhance lighting in low light scenes. Options: ON, OFF, AUTO (default setting).
  • Page 44 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 Auto Focus Automatically focuses on the subject in the center of the screen. Options: Option Description CONSTANT Auto Focus is always active, even while the camera is moving. MANUAL Auto Focus is inactive;...

  • Page 45: Ptz Setup Menu

    MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en 14.3 PTZ Setup Menu The PTZ Setup Menu contains pan/tilt/zoom settings that can be changed/customized. PTZ Setup Exit... * Autopan: 30 deg/sec * Tour 1 Period: 5 sec * Tour 2 Period:...
  • Page 46 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 Inactivity Selects the mode to which the camera reverts after the period of inactivity set in the inactivity period. Options: Option Description Scene 1 Returns to Preset 1. Prev Aux Returns to previous activity, such as Aux commands 1, 2, 7, 8, 50, or 52.

  • Page 47: Display Setup Menu

    MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en 14.4 Display Setup Menu The Display Setup Menu contains display settings that can be changed/customized. Display Setup Exit... * Title OSD: MOMENTARY * Camera OSD: Display Adjust * Azimuth: * Compass: Sector Blanking...
  • Page 48 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 Option Description Moves screen title up. Down Moves screen title down. Brighter Brightens the intensity of the on-screen text. Darker Darkens the intensity of the on-screen text. Azimuth Display azimuth/elevation values. Options: ON, OFF (default setting). For more details, refer to Azimuth, Elevation, and Compass Directions, page 76.

  • Page 49: Communication Setup Menu

    MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en 14.5 Communication Setup Menu The Communication Setup Menu contains baud rate and Bilinx control settings. Communication Setup Exit... * AutoBaud: * Baud Rate: 9600 Bilinx Restore Defaults * = Factory Setting...

  • Page 50: Alarm Setup

    | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 14.6 Alarm Setup The Alarm Setup Menu contains alarm inputs, outputs and rules. Notice! The maximum number of Alarm Inputs is eight (8), available only on the Alarm and Washer Pump Drive Card (MIC-ALM) (sold separately).
  • Page 51 MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en Multi Alarm Setup Allows setup of multiple alarms. Options: On; Off. Checkbox button to "Select." Inputs Setup Submenu Choices: Inputs Setup Defines physical inputs or events and commands that can be used in a rule. There are twelve (12) alarm inputs available.
  • Page 52 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 Outputs Setup Submenu Outputs Setup... Exit... 1. NONE 2. NONE 3. NONE 4. NONE 5. NONE 6. NONE 7. NONE 8. NONE 9. NONE 10. NONE 11. NONE 12. NONE...
  • Page 53 MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en Outputs Setup Submenu Choices: Outputs Setup Defines physical outputs and keyboard commands for use in a rule. Outputs 1–2 Defines a physical output: N.O. (Normally Open circuit) (default setting) or N.C. (Normally closed circuit).
  • Page 54 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 Rule Setup Submenu Notice! You can program a total of twelve rules. You must define the inputs and outputs before you program a rule. See Alarm Setup, page 50, to configure alarm inputs and outputs.
  • Page 55 MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en Rule Setup Submenu Choices: Rule Setup Displays the status of rules and lets you add new rules or modify an existing rule. Rule 1-12 Displays the status of a rule on the right side of the menu. Rule status options:...

  • Page 56: Language Menu

    | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 14.7 Language Menu The Language Menu contains a list of languages in which the on-screen menus are available. Language Exit... English Spanish French German Portuguese Polish Italian Dutch Russian...

  • Page 57: Diagnostics Menu

    MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en 14.8 Diagnostics Menu The Diagnostics menu contains a list of diagnostic tools and events. Most of these menu items are display items only; you cannot select different values to change.
  • Page 58 | On-Screen Display (OSD) Menus (Bosch Protocol) MIC Series 550 Internal Temp. Displays the current temperature of the camera, in degress Fahrenheit and in degrees Celsius. High Temp Events Displays the number of times that the threshold of high temperature was exceeded.
  • Page 59 MIC Series 550 On-Screen Display (OSD) Menus (Bosch Protocol) | en Alarm Status Exit... Alarm Input 1 Open Alarm Input 2 Open Alarm Input 3 Open Alarm Input 4 Open Alarm Input 5 Open Alarm Input 6 Open Alarm Input 7...

  • Page 60: On-Screen Display (Osd) Menus (Pelco Protocol)

    Camera Setup PTZ Setup Edit Password *FastAddress: Not Set Advanced Software Version Ack and Reset Alarms Restore All Settings Reset All Memory * = Factory Setting Focus / Iris: Select 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.
  • Page 61 Clears all settings, including scene shots, tours, and recordings stored in the camera memory. Notice! If commands are locked and you press Focus or Iris, the camera displays the on-screen message: “Command is Locked.” Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 62: Bosch Menu

    | On-Screen Display (OSD) Menus (Pelco Protocol) MIC Series 550 15.1 Bosch Menu The Bosch Menu allows full access to the main Setup Menu and all camera configuration settings. Pelco menu Bosch menu Setup Menu Setup Menu Exit... Command Lock: Exit...

  • Page 63: Camera Setup

    INTERMITTENT: Wipes twice, then turns off after 15 seconds. ONE SHOT: Wipes five times, then turns off. WASH WIPE: Wiper washes and wipes. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 64: Ptz Setup

    * Tour 2 Period: 5 sec * Scan Speed 30 deg/sec Edit Presets... * Limit Stops: * Recording: “A” * Autopivot: * = Factory Setting Focus / Iris: Select 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.
  • Page 65 Selects record Pattern 1 or “A” or “B” “A” 2, if normal pattern command does not respond. AutoPivot Follows a subject while ON or OFF beneath the camera, without inverting the picture. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 66: Aux Setup Menu

    The AUX Setup menu provides an area to remain Aux commands. AUX Setup Exit... * WASH WIPE * Alarm Output 2: * Not Set Not Set Not Set Not Set * = Factory Setting Focus / Iris: Select 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 67: Other Menus

    Restores all settings to their original factory default settings. Reset All Memory Restores all settings to their original factory default settings and clears all user programmed settings such as preset scenes and recordings. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 68: Common User Commands

    | Common User Commands MIC Series 550 Common User Commands This chapter details common user commands. See Keyboard Commands (Bosch Protocol) By Number, page 81 for a complete list of commands. 16.1 Programming the Inactivity Operation You can program the MIC camera to change its operating mode automatically after a period of inactivity.

  • Page 69: Configuring Preposition Tours

    Press ON-50-ENTER to begin continuous playback. Press OFF-50-ENTER or move the joystick to stop playback. To Record Tour B: Press ON-101-ENTER to start recording the tour. Press OFF-101-ENTER to stop the tour. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...
  • Page 70 | Common User Commands MIC Series 550 To play back Recorded Tour B: Press ON-52-ENTER to begin continuous playback. Press OFF-52-ENTER or move the joystick to stop playback. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 71: Remapping Aux Commands (Pelco Protocol, Firmware Version 2.10 And Higher)

    Aux 2 command. 16.8 Using the Wiper/Washer (Pelco Protocol) To activate the washer/wiper in Pelco protocol, follow these steps: Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 72: Using The Wiper/Washer (Bosch Protocol)

    Freeze Frame on Preposition in the PTZ Setup menu. 16.9 Using the Wiper/Washer (Bosch Protocol) The "predefined position" for the wash/wipe function is preset 62. The installer must define preset 62 (preferably where the washer nozzle is located and can direct washer fluid towards the camera window) before using the wiper/washer function.

  • Page 73: Configuring Settings For Ir Illumination

    IR Illuminator = Auto – IR Focus Correction = Off This combination of settings causes a blurred view at wide angle. (When zoomed in (at TELE angle), the view is focused.) Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 74: Advanced Features

    Set the first input to Alarm Input 1. Set the first output to OSD. Set the second output to Shot 7. Set the third output to Transmit. Enable the Alarm Rule: Highlight Enabled and select YES. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 75: Pre-Position Tour

    Masks can be programmed with three, four, or five corners each. Each mask can appear in black, white, or blurred. Blurred is useful when privacy is an issue, but determining the presence of motion is still required. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 76: Image Stabilization

    – In Pelco Mode, open the Pelco Main menu, open the Bosch menu, select the Display Setup menu, and then select Privacy Masking. To setup a privacy mask, follow the on- screen menu instructions.

  • Page 77: Setting The Azimuth Zero Point

    Azimuth Zero point. Caution! Bosch recommends that only the installer calibrate the Azimuth Zero point. A recalibration to the Azimuth Zero point may cause inaccurate compass headings. To set the Azimuth Zero point: Determine the North compass heading, then move the camera to that position.

  • Page 78: Maintenance And Troubleshooting

    No User-serviceable Parts Except for the external wiper blade, the device contains no user-serviceable parts. Contact your local Bosch service center for device maintenance and repair. In the event of failure, the device should be removed from site for repair.
  • Page 79 – Check that the maximum Ethernet cable distance has not been exceeded. If O.K., then: – Restore all camera settings. Background is too bright to see Turn on backlight compensation. subject. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...

  • Page 80: Technical Data

    | Technical data MIC Series 550 Technical data For product specifications, see the datasheet for your camera, available on the appropriate product pages of the Online Product Catalog at www.boschsecurity.com. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.

  • Page 81: Appendices

    MIC Series 550 Appendices | en Appendices 20.1 Keyboard Commands (Bosch Protocol) By Number 20.1.1 Commands, Optical Camera Locked Functio Command Command Description n Key On/Off Scan 360° / Auto Pan (Continuous) Activates/deactivates Autopan without limits. On/Off Autopan (within Limits) Activates/deactivates Autopan between limits.
  • Page 82 IR illumination is present. On/Off Alarm Rule Activation/Deactivation On–Enables all alarm rules. Off–Disables all alarm rules. Re-initialize Camera Performs camera/lens re-initialization functions. On/Off Digital Zoom Lock Turns digital zoom on and off. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.
  • Page 83 Off - Switches view to optical camera. Factory P/T Home Position Recalibrates home position; can be used as an Alarm Output. On/Off Record A Activates/deactivates recording A. On/Off Record B Activates/deactivates recording B. Bosch Security Systems, Inc. Operation Manual 2014.11 | 3.2 | F.01U.239.454...
  • Page 84 Enters the Standard Tour Scene menu. Shot Edit Tour 2 (Custom) Enters the Custom Tour Scene menu. Set/ 901-999 Adds/Removes a Preposition Shot Set ###–Adds preset. Shot from Tour 1 Shot ###–Removes preset. 2014.11 | 3.2 | F.01U.239.454 Operation Manual Bosch Security Systems, Inc.
  • Page 86 Bosch Security Systems, Inc. 1706 Hempstead Road Bosch Sicherheitssysteme GmbH Lancaster, PA, 17601 Robert-Bosch-Ring 5 85630 Grasbrunn www.boschsecurity.com Germany © Bosch Security Systems, Inc., 2016 www.boschsecurity.com...
