CIRWATT B 500 2�29�3 - COMMUNICATIONS FAILURE BETWEEN METER AND ANALYSER ����������������������������������������������������������������22 2�29�4 - SUPPLY FAILURE IN AT LEAST ONE PHASE �������������������������������������������������������������������������������������������������23 2�30 - APPLICABLE REGULATIONS ��������������������������������������������������������������������������������������������������������������������������������23 3 - CALCULATIONS IN THE METER �������������������������������������������������������������������������������������������������������������������������������������24 3�1 - EFFECTIVE VOLTAGE �����������������������������������������������������������������������������������������������������������������������������������������������24 3�2 - EFFECTIVE CURRENT ���������������������������������������������������������������������������������������������������������������������������������������������24 3�3 - APPARENT POWER CALCULATION �������������������������������������������������������������������������������������������������������������������������24...
Perform an external visual inspection of the device prior to switching it on. If any problem is noticed upon reception, immediately contact the transport com- pany and/or CIRCUTOR's after-sales service� 2 - PRODUCT DESCRIPTION The CIRWATT Type B is a three-phase static meter for class 1 active energy measurement, according to IEC 62052-11 and IEC 62053-21, and class B active energy measurement according to EN 50470-1 and EN 50470-3, according to RD 244/2016 and measurement of reactive energy class 0.5, 1 or 2 (IEC...
CIRWATT B 500 2�1 - METER VERSIONS The following table shows all the possible options that are available for the CIRWATT Type B. This table is generic, meaning that some versions listed in it may not currently be available Table 3: Meter versions�...
CIRWATT B 500 2�2 - METROLOGY The metrological features for the CIRWATT type B Three-phase (TBT) are: • The current sensor is of the current transformer type. • Range of currents: Table 4: Range of currents� Range of currents Model 505 (... / 5A) Active Class C (0�5s)
CIRWATT B 500 2�5 - BUILD CHARACTERISTICS 2�5�1 - GENERAL The meter has a class-II protective insulating enclosure and double insulation. As specified in Directives 2002/96/EC and 2002/95/EC, none of the materials or substances specified therein are used. The materials used are fire retardant, halogen free and emit low quantities of opaque, toxic or corrosive fumes.
CIRWATT B 500 2�5�6 - TERMINAL COVER (DEPENDING ON VERSION) The meters have an opaque cover over the top of the terminal box and the fixing screws. The meter has a sensor that detects the opening and closing of the terminal cover. This detection is always enabled, even if the meter is not powered.
Page 12
CIRWATT B 500 the active quadrant (Q1,Q2,Q3,Q4) L1+L2+L3+, indicates the presence of voltage on each phase with its corresponding sing of intensity: "+" is used to show the power absorbed from the mains. "–" is used to show the power transferred to the mains.
CIRWATT B 500 2�7 - VERIFICATION PULSES The device has two verification LEDs, one for verifying the active energy and another for the reactive energy. The weight of the LEDS depends on the version of the meter, and is 20,000 imp/kWh (kVArh).
2�12�3 - VERSION WITH LEAKAGE CURRENT MEASUREMENT The meter will have an input for connecting an external transformer of the Circutor WN series, which will allow reading the differential current (leakage) present in the installation.
CIRWATT B 500 2�13 - REAL-TIME CLOCK The meter has a real-time clock capable of keeping the date and time with a drift of less than 0.5 seconds/day, as specified in the UNE EN 61038 standard. The clock maintains this accuracy whether it is powered from the mains or by its own battery.
CIRWATT B 500 2�19�1 - NUMBER AND ALLOCATION OF CONTRACTS The meter has three contracts defined. 2�19�2 - CONTRACT PARAMETERS A parameter is considered to be defined if it has an assigned value, and undefined if it is blank. A parameter that is not used cannot have any value assigned from previous parameterisations, and thus it will remain undefined.
CIRWATT B 500 Type of day The type of day refers to the set of tariff periods allocated to each of the 24 hours in a day. Each type of day is identified using a number starting with 1 and increasing by one for successive types.
CIRWATT B 500 of closing can affect one or more active contracts. An extraordinary immediate closing is automatically done in the following cases: Change in transformation ratio. Affects every contract. Change of power contracted by period. Affects the modified contract.
CIRWATT B 500 If the group of power is modified, it may also be necessary to modify the group of seasons and types of days beforehand, in order to maintain consistency. The groups are: Holidays (up to 15). Power. Automatic billing closing date.
CIRWATT B 500 If more than one contract has been defined and is active and one of them is deleted and the rest are maintained, at the time of deletion, the billing for the contract to be deleted is closed out. From that moment on, the information pertaining to the deleted contract is erased and no information on it can be displayed, except for that pertaining to the closed billing periods that may exist.
CIRWATT B 500 2�27 - DAYLIGHT SAVING TIME The meter – analyser automatically changes the official time. If the device is without power at the time of the change, the change will take place when power is restored and the device is initialised.
CIRWATT B 500 Sealable button Seal transformation relations / programming Manufacturer seal (under the thread cover) Wire cover lid seal Figure 2:Seals� 2�29 - MEASUREMENT VALIDATION CRITERIA The energy, maximeter and excess power records will be invalidated if a series of events occur that indicate that any of their values have been altered.
CIRWATT B 500 2�29�4 - SUPPLY FAILURE IN AT LEAST ONE PHASE The measurement for the period in which the failure occurred is invalidated, IV = 1. 2�30 - APPLICABLE REGULATIONS The CIRWATT Type B is based on the following standards: EN 50470-1:2006 - Electricity metering equipment (a.c.) -- Part 1: General requirements, tests and test...
CIRWATT B 500 The maximum demand between the closing of two billing periods is the maximum value of each of these values averaged every 15 minutes (MD MAXDEM Equation 9: Maximum of maximum demand� 2.8.- Cálculo de energía MAXDEM ...
CIRWATT B 500 B - Separation threshold between low voltage and zero voltage This is the percent of the nominal voltage below which an out-of-range voltage incident is no longer considered, but rather a zero-voltage incident. This value is initially set at 50%.
CIRWATT B 500 4 - OPERATION OF THE METER This section describes the performance of the device from a functional point of view; that is, it explains how to manage all the information it provides, as well as how to configure the system's various fea- tures.
CIRWATT B 500 Total active energy exported: 000121 0.28.0 Total reactive energy quadrant 1: 000093 0.58.0 kVArh Total reactive energy quadrant 2: 000121 0.68.0 kVArh Total reactive energy quadrant 3: 004121 0.78.0 kVArh Total reactive energy quadrant 4: 000422 0.88.0...
Page 30
CIRWATT B 500 Table 5:L1 screen� Screens Text Observations ACTUAL Access the current values of contract 1 CIer 1 Access the closing 1 (most recent) values for contract 1 CIer 2 Access the closing 2 values for contract 1 CIer 3...
Page 31
CIRWATT B 500 Below are the codes for the incremental values: Table 7:Incremental values� Inc Incremental values OBIS 1.1.1 Consumption by tariff period of Active Energy since the close 1.1.2 of the last billing period (if active), including the total (period 1.1.3...
Page 32
CIRWATT B 500 Below are the codes for the variables of the incremental values: Table 9:Incremental values� Inc Incremental values OBIS 1.1.1.1 Consumption by tariff period of Active Energy for the 1.1.2.1 last billing period (if active), including the total (period 1.1.3.1...
Page 33
CIRWATT B 500 The information is displayed exactly the same as on the L12 screen, but the F field will take the value 04 instead of 01. For example: 1.18.1.4 Absolute active energy consumed, for period 1, from close of billing period 4.
Page 34
CIRWATT B 500 Table 10 (Continued): Menu screens� Screens Description Observations INSTANTANEOUS It shows information on the instantaneous values of various U Inst VALUES electrical parameters It shows information on the various parameters of the Co COMMUNICATIONS communications ports It shows information on the different identifiers of the device,...
Page 35
CIRWATT B 500 L42 Screen (INFORMATION: TRANSFORMER RATIOS) This screen shows information on the transformer ratios. It is a DATA screen. Table 13:Transformer ratio screens� Screen OBIS Description PRIMARY CURRENT RATIO: It shows the value of primary current ratio to 1 0.04.2...
Page 36
CIRWATT B 500 L44 Screen (INFORMATION: INSTANTANEOUS VALUES) This screen shows information on the instantaneous values of various electrical parameters Since these data do not correspond to any specific contract, but are general to all of them, the B field takes the value 0.
Page 37
CIRWATT B 500 Table 17:Identifying Screens� Screen OBIS Description LINK ADDRESS 0.00.5 METERING POINT ADDRESS 0.00.6 DATE OF COMMUNICATIONS PROTOCOL VERSION: (DD-MM-YY), displays the 0.00.7 ASDU 142 information of the protocol DEVICE FIRMWARE VERSION: displays the ASDU 142 information of the 0.02.0...
Page 38
CIRWATT B 500 4�2�2�3 - L5 Screen (QUALITY) This screen is used to access information involving quality aspects of the supply voltage. It is a MENU screen. CALidAd Gives access to other dependent MENU screens, as shown below: Table 20:Quality screens�...
Page 39
CIRWATT B 500 Table 22:No voltage screens� Screen OBIS Description ZERO VOLTS ON ALL PHASES: Duration in minutes in the current year 1242.0 NO VOLTAGE 1: Duration in minutes in the current year 3242.0 NO VOLTAGE 2: Duration in minutes in the current year 5242.0...
CIRWATT B 500 L64 screen (MANUF. INFO: STATUS) This screen shows the most critical alarms on the meter. L65 screen (MANUF. INFO: CRC) This screen shows the meter's CRC code. 4�2�3 - SPECIAL FUNCTIONS The sealable button and/or the wire cover sensor will be used to access the Special Functions.
Page 41
CIRWATT B 500 dESAct CiErr 4�2�3�2 - Special programming menu Allows changing those parameters that require breaking the seal on the sealable key. Such is the case with transformer ratios or the integration period for load curves. 4�2�3�3 -Reset Menu All programmed parameters and stored data are deleted.
CIRWATT B 500 CONTADOR TRIFÁSICO ESTÁNDAR CIRWATT B 5 - COMMUNICATIONS CONTADOR TRIFÁSICO ESTÁNDAR CIRWATT 4.- COMUNICACIONES 4.- COMUNICACIONES The meter can have several communication channels depending on the model, as described below: El contador puede disponer de varios canales de comunicación según modelo cuy descripción es la siguiente:...
CIRWATT B 500 CONTADOR TRIFÁSICO ESTÁNDAR CIRWATT B CONTADOR TRIFÁSICO ESTÁNDAR CIRWATT B Figure 7: RS-485 connector 4.3.- Comunicación Ethernet 4.3.- Comunicación Ethernet 5�3 - ETHERNET COMMUNICATIONS Este tipo de comunicación crea una red interna con comunicaciones vía IP. Se pueden Este tipo de comunicación crea una red interna con comunicaciones vía IP.
CIRWATT B 500 6 - EXPANSION MODULES The option exists to implement different communication modules, which are connected as described in the table below: Expansion modules Figure 9: Expansion modules� Table 24:Expansion modules� Expansion modules Ground leakage 2 Digital inputs and 4 ...
CIRWATT B 500 7 - PARAMETERISATION AND READING SOFTWARE Every meter has an optical communications channel and optionally RS-232, RS-485 or ETHERNET communication ports. The optical interface meets the electrical and mechanical specifications of the IEC62056-21 standard. To communicate, the correct analyser address and the password must be entered.
CIRWATT B 500 8 - INSTALLATION AND START-UP 8�1 - INSTALLING THE DEVICE The meter has been designed as per the DIN 43857 standard, which specifies the dimensions and the mounting points. The meter is designed to be installed indoors, inside its associated enclosure.
La garantía CIRCUTOR tiene duración de dos años desde la fecha de compra y se limita al reembolso del precio de compra, reparación gratuita o la sustitución del equipo defectuoso que sea devuelto a servicio postventa de CIRCUTOR dentro del periodo de garantía.
CIRWATT B 500 9 - TECHNICAL FEATURES Power Supply Mode Self-powered Rated voltage 3 x 57(100) ... 3 x 230(400) V ± 20% Tolerance Consumption < 2 W, 10 VA Frequency 50 or 60 Hz Operating temperature -25 ºC ... +70 ºC...
Page 50
CIRWATT B 500 Leakage current (depending on version) Type Suitable for use with Circutor WN transformers Measurement of leakage current detected by the WN with a cadence Operational of 1 second Electrical characteristics Maximum current: 300 mA + 20% overload...
CIRWATT B 500 10 - MAINTENANCE AND TECHNICAL SERVICE In the case of any query in relation to device operation or malfunction, please contact the CIRCUTOR S�A�U� Technical Support Service. Technical Assistance Service Vial Sant Jordi, s/n, 08232 - Viladecavalls (Barcelona) Tel: 902 449 459 (Spain) / +34 937 452 919 (outside of Spain) email: sat@circutor.com...
