SUMAKE
1/2" Professional Mini Air Impact Wrench
Specification:
Free Speed
Max. Torque
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-9
PNEUMATIC TOOLS
(Twin Hammer)
ST-C5141
10,000 r/min
450 ft-lb (610 N-m)
4 CFM (113 L/min)
4.9" (125 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.75 lbs (1.25 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound Pressure Level
Load:
3.7 m/s²
Sound power level
Uncertainty
K= 1.5 m/s
²
Noise
Remark
EN ISO 15744
Please always
load: 83 dB(A)
wear ear
protector at
environment
load: 94 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
hearing!
K= 3dB
ST-C5141-S-1506A-JUF
Advertisement
Table of Contents
Related Manuals for Sumake ST-C5141
Summary of Contents for Sumake ST-C5141
- Page 1 Air Hose (I.D.) 3/8” (10 mm) risk of impaired Uncertainty Uncertainty hearing! Air Pressure 90 psi (6.3 bar) K= 1.5 m/s ² K= 3dB Net Weight 2.75 lbs (1.25 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-9 ST-C5141-S-1506A-JUF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 1/2" PROFESSIONAL MINI AIR IMPACT WRENCH (TWIN HAMMER) - COMPOSITE HOUSING Model/ Serial No.：ST-C5141 to which this declaration applies, complies with these normative documents: ...
- Page 3 Coupler hose Leader Water You can adjust the torque by rotating the knob Sumake is a manufacturer and exporter of air hose separation supply which indicated by 1 to 6. “1＂ indicates the tools since established. We have devote all our Tool smallest torque output and “6＂...
- Page 4 ST-C5141 1/2" PROFESSIONAL MINI AIR IMPACT WRENCH (TWIN HAMMER) - COMPOSITE HOUSING PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty C5141-01 Housing C5141-27 C5141-02 Ball Bearing C5141-28 O-Ring C5141-04 Front Plate C5141-29 O-Ring C5141-05 O-Ring C5141-30 Regulator Valve...
- Page 5 IMPACT WRENCH Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 3. If the operator experiences symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensations or stiffness, these warning signs should not be ignored. The operator should tell the employer and consult a qualified health professional. Safety precautions for accessory hazards 1.
- Page 8 General preparation and connection: When using brand-new air hose or air pipe. Blow and clean the inside of air hose or pipe before installation. Keep inside of air hose or air pipe clean to prevent airdrop problem caused by the lots of drain and dust accumulated and possibly make the inside diameter smaller in the long use.
